46
CX-LFA660/LFA770
SECTION 9
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS
uF: µF
• COILS
uH: µH
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . , uPA. . , µPA. . ,
uPB. . : µPB. . , uPC. . , µPC. . ,
uPD. . : µPD. .
When indicating parts by reference number,
please include the board name.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
AMP
•Abbreviation
AUS:Australian model
A-1054-464-A AMP BOARD, COMPLETE (770)
A-1056-986-A AMP BOARD, COMPLETE (660)
*************************
< CAPACITOR >
C014 1-126-933-11 ELECT 100uF 20% 16V
C016 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C028 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C029 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C034 1-126-947-11 ELECT 47uF 20% 35V
C040 1-104-665-11 ELECT 100uF 20% 25V
C097 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C101 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C102 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C103 1-126-960-11 ELECT 1uF 20% 50V
C104 1-126-960-11 ELECT 1uF 20% 50V
C107 1-126-947-11 ELECT 47uF 20% 35V
C108 1-126-947-11 ELECT 47uF 20% 35V
C111 1-126-967-11 ELECT 47uF 20% 50V
C112 1-126-967-11 ELECT 47uF 20% 50V
C113 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C114 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C117 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C118 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C119 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C120 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C121 1-126-960-11 ELECT 1uF 20% 50V
C122 1-126-960-11 ELECT 1uF 20% 50V
C123 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C124 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C125 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C126 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C127 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C128 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C129 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C130 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C145 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C146 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C240 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C270 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C271 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C272 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C280 1-104-662-91 ELECT 22uF 20% 25V
< DIODE >
D021 8-719-048-55 DIODE MTZJ-T-77-10C
D030 8-719-991-33 DIODE 1SS133T-77
D101 8-719-991-33 DIODE 1SS133T-77
D102 8-719-991-33 DIODE 1SS133T-77
D103 8-719-991-33 DIODE 1SS133T-77
D104 8-719-991-33 DIODE 1SS133T-77
D105 8-719-991-33 DIODE 1SS133T-77
D106 8-719-991-33 DIODE 1SS133T-77
D107 8-719-991-33 DIODE 1SS133T-77
D108 8-719-991-33 DIODE 1SS133T-77
D111 8-719-991-33 DIODE 1SS133T-77
D112 8-719-991-33 DIODE 1SS133T-77
D113 8-719-970-83 DIODE HSS82-TJ
D114 8-719-970-83 DIODE HSS82-TJ
D249 8-719-991-33 DIODE 1SS133T-77
D250 8-719-991-33 DIODE 1SS133T-77
< EARTH TERMINAL >
* EP002 1-537-738-21 TERMINAL, EARTH
< IC >
IC001 8-759-071-48 IC TA7807S
< SHORT >
JR103 1-216-864-11 SHORT CHIP 0
< TRANSISTOR >
Q006 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q011 8-729-024-93 TRANSISTOR 2SB1565E
Q012 8-729-036-89 TRANSISTOR KTC3198GR-AT
Q101 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q102 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q103 8-729-021-88 TRANSISTOR 2SA1587-BL (TE85L)
Q104 8-729-021-88 TRANSISTOR 2SA1587-BL (TE85L)
Q105 8-729-021-88 TRANSISTOR 2SA1587-BL (TE85L)
Q106 8-729-021-88 TRANSISTOR 2SA1587-BL (TE85L)
Q107 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q108 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q109 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q110 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q111 8-729-045-02 TRANSISTOR KTC3200GR-AT
Q112 8-729-045-02 TRANSISTOR KTC3200GR-AT
Q113 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q114 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q117 6-550-309-01 TRANSISTOR 2SB1686
Q118 6-550-309-01 TRANSISTOR 2SB1686
