47
CX-LFA660/LFA770
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
Q119 6-550-311-01 TRANSISTOR 2SD2642
Q120 6-550-311-01 TRANSISTOR 2SD2642
Q121 8-729-600-22 TRANSISTOR 2SA1235-F
Q123 8-729-021-88 TRANSISTOR 2SA1587-BL (TE85L)
Q124 8-729-021-88 TRANSISTOR 2SA1587-BL (TE85L)
Q127 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q128 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q250 6-550-317-01 TRANSISTOR 2SD0814A0LS0
Q251 8-729-021-88 TRANSISTOR 2SA1587-BL (TE85L)
Q280 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q281 8-729-021-88 TRANSISTOR 2SA1587-BL (TE85L)
Q282 8-729-120-28 TRANSISTOR 2SC1623-L5L6
< RESISTOR >
R025 1-247-879-91 CARBON 100K 5% 1/4W
R028 1-216-813-11 METAL CHIP 220 5% 1/10W
R029 1-216-841-11 METAL CHIP 47K 5% 1/10W
R056 1-216-805-11 METAL CHIP 47 5% 1/10W
R057 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R058 1-216-833-11 METAL CHIP 10K 5% 1/10W
R059 1-216-813-11 METAL CHIP 220 5% 1/10W
R060 1-216-817-11 METAL CHIP 470 5% 1/10W
R103 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R104 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R105 1-216-838-11 METAL CHIP 27K 5% 1/10W
R106 1-216-838-11 METAL CHIP 27K 5% 1/10W
R107 1-216-809-11 METAL CHIP 100 5% 1/10W
R108 1-216-809-11 METAL CHIP 100 5% 1/10W
R109 1-216-821-11 METAL CHIP 1K 5% 1/10W
R110 1-216-821-11 METAL CHIP 1K 5% 1/10W
R111 1-216-820-11 METAL CHIP 820 5% 1/10W
R112 1-216-820-11 METAL CHIP 820 5% 1/10W
R113 1-249-435-11 CARBON 33K 5% 1/4W
(660)
R113 1-249-436-11 CARBON 39K 5% 1/4W
(770)
R114 1-249-435-11 CARBON 33K 5% 1/4W
(660)
R114 1-249-436-11 CARBON 39K 5% 1/4W
(770)
R115 1-249-421-11 CARBON 2.2K 5% 1/4W
R116 1-249-421-11 CARBON 2.2K 5% 1/4W
R117 1-216-833-11 METAL CHIP 10K 5% 1/10W
R118 1-216-833-11 METAL CHIP 10K 5% 1/10W
R119 1-216-809-11 METAL CHIP 100 5% 1/10W
R120 1-216-809-11 METAL CHIP 100 5% 1/10W
R121 1-216-809-11 METAL CHIP 100 5% 1/10W
R122 1-216-809-11 METAL CHIP 100 5% 1/10W
R123 1-249-421-11 CARBON 2.2K 5% 1/4W
R124 1-249-421-11 CARBON 2.2K 5% 1/4W
R125 1-247-831-91 CARBON 1K 5% 1/4W
R126 1-247-831-91 CARBON 1K 5% 1/4W
R127 1-216-805-11 METAL CHIP 47 5% 1/10W
R128 1-216-805-11 METAL CHIP 47 5% 1/10W
0 R129 1-216-361-31 METAL OXIDE 0.22 5% 2W
(660)
0 R129 1-245-545-11 METAL OXIDE 0.22 5% 3W
(770)
0R130 1-216-361-31 METAL OXIDE 0.22 5% 2W
(660)
0R130 1-245-545-11 METAL OXIDE 0.22 5% 3W
(770)
0R131 1-216-361-31 METAL OXIDE 0.22 5% 2W
(660)
0R131 1-245-545-11 METAL OXIDE 0.22 5% 3W
(770)
0R132 1-216-361-31 METAL OXIDE 0.22 5% 2W
(660)
0R132 1-245-545-11 METAL OXIDE 0.22 5% 3W
(770)
R133 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R134 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R135 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
R136 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
R137 1-216-809-11 METAL CHIP 100 5% 1/10W
R138 1-216-809-11 METAL CHIP 100 5% 1/10W
R139 1-216-864-11 SHORT CHIP 0
R140 1-216-864-11 SHORT CHIP 0
R141 1-216-821-11 METAL CHIP 1K 5% 1/10W
R142 1-216-821-11 METAL CHIP 1K 5% 1/10W
R143 1-216-833-11 METAL CHIP 10K 5% 1/10W
R144 1-216-833-11 METAL CHIP 10K 5% 1/10W
R145 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R146 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R147 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R148 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R149 1-216-845-11 METAL CHIP 100K 5% 1/10W
R150 1-216-833-11 METAL CHIP 10K 5% 1/10W
R151 1-216-864-11 SHORT CHIP 0
R152 1-216-864-11 SHORT CHIP 0
R153 1-216-857-11 METAL CHIP 1M 5% 1/10W
R154 1-216-841-11 METAL CHIP 47K 5% 1/10W
R155 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R156 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R157 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R158 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R165 1-216-821-11 METAL CHIP 1K 5% 1/10W
R166 1-216-821-11 METAL CHIP 1K 5% 1/10W
R171 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R172 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R173 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R174 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R175 1-216-815-11 METAL CHIP 330 5% 1/10W
R176 1-216-815-11 METAL CHIP 330 5% 1/10W
R177 1-216-835-11 METAL CHIP 15K 5% 1/10W
R178 1-216-835-11 METAL CHIP 15K 5% 1/10W
R181 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R182 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R221 1-216-845-11 METAL CHIP 100K 5% 1/10W
R222 1-216-845-11 METAL CHIP 100K 5% 1/10W
R223 1-216-838-11 METAL CHIP 27K 5% 1/10W
R224 1-216-838-11 METAL CHIP 27K 5% 1/10W
R270 1-216-833-11 METAL CHIP 10K 5% 1/10W
R271 1-216-833-11 METAL CHIP 10K 5% 1/10W
R272 1-216-841-11 METAL CHIP 47K 5% 1/10W
R273 1-216-833-11 METAL CHIP 10K 5% 1/10W
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
