57
CX-LFA660/LFA770
Ref. No. Part No. Description Remark
< TRANSFORMER >
0 PT251 1-439-735-11 TRANSFORMER, POWER
< RESISTOR >
R225 1-216-821-11 METAL CHIP 1K 5% 1/10W
R226 1-216-821-11 METAL CHIP 1K 5% 1/10W
R227 1-216-837-11 METAL CHIP 22K 5% 1/10W
< RELAY >
0 RY251 1-755-334-11 RELAY, AC POWER
************************************************************
MISCELLANEOUS
**************
5 1-787-194-11 FAN, DC
6 1-827-731-11 WIRE (FLAT TYPE) (11 CORE) (AUS)
6 1-828-984-11 WIRE (FLAT TYPE) (15 CORE) (EXCEPT AUS)
7 1-693-626-11 TUNER (FM/AM) (EXCEPT AUS)
7 1-693-628-21 TUNER (FM/AM) (AUS)
69 1-829-031-11 WIRE (FLAT TYPE) (25 CORE)
70 1-829-012-11 WIRE (FLAT TYPE) (21 CORE)
76 1-828-007-11 WIRE (FLAT TYPE) (8 CORE)
77 1-796-351-51 MECHANISM, SINGLE CASSETTE
(CMAL1Z240A)
101 1-469-636-11 CORE, FERRITE (ESD-R-25SD)
0 104 1-696-848-12 CORD, POWER (AUS)
0 104 1-769-744-52 CORD, POWER (AEP, UK)
0 108 1-770-019-51 ADAPTOR, CONVERSION PLUG (UK)
156 1-828-290-11 WIRE (FLAT TYPE) (5 CORE)
0 202 8-820-244-01 OPTICAL PICK-UP (KSM-215DCP/C2NP)
203 1-827-992-11 WIRE (FLAT TYPE) (16 CORE)
204 1-828-659-11 WIRE (FLAT TYPE) (27 CORE)
M001 1-763-967-11 MOTOR, DC (LOADING)
0 PT252 1-443-407-11 TRANSFORMER, POWER (770)
0 PT252 1-443-408-11 TRANSFORMER, POWER (660)
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
