60
GB
Before connecting the cords, be sure to
disconnect the AC power cord.
To enjoy TV multi channel
surround sound broadcasting
You can listen to TV multi channel surround
sound broadcasting from the speakers
connected to the receiver.
Connect the OPTICAL output jack of the TV
to the OPTICAL IN jack of the receiver.
a)
Connect at least one of the audio cords (B or C).
Connecting a TV and other
components
VIDEO
OUT
SAT IN
DVD IN VIDEO 1 IN MONITOR OUT
VIDEO
IN
AUDIO
OUT
AUDIO
IN
VIDEO
IN
AUDIO
IN
VIDEO
IN
AUDIO
IN
AUDIO
OUT
SUBWOOFER
Y
P
B /
C B
P R /
C R
SURROUND
FRONT: ONLY FOR SS-MSP5000
CENTER: ONLY FOR SS-CNP5000
SURROUND: ONLY FOR SS-SRP5000
SURROUND BACK CENTER
LRLR
FRONT
L
R
SPEAKERS
AM
ANTENNA
L
R
L
R
ININOUT
SAT DVD VIDEO 1
VIDEO
OUT
MONITOR
COMPONENT VIDEO
DIGITAL
(ASSIGNABLE)
OPTICAL
OPTICAL
SAT
IN
DVD
IN
COAXIAL
IN
DMPORT
DC5V
0.7A MAX
HDMI
OUT
TV
SAT IN DVD IN BD IN
TV
SA-CD / CD / CD-R
Satellite tuner/Set-top box
A HDMI cable (not supplied)
We recommend that you use a Sony HDMI cable.
B Optical digital cord (not supplied)
a)
C Audio cord (not supplied)
a)
DVD player Blu-ray disc player
Audio/video
signals
Audio/video
signals
Audio/video
signals
Audio signals
TV, etc.
Audio/video
signals
AA A
ACB
