Additional Information
Specifications
Amplifier section
Power Output
Models of area code SP, AU, E51
Stereo mode output (rated) (6 ohms, 1 kHz,
THD 1%)
90 W + 90 W
1)
Surround mode output (reference)
2)
RMS output
FRONT: 185 W per channel
1)
(with SS-MSP5000)
CENTER: 185 W
1)
(with SS-CNP5000)
SURROUND: 185 W per channel
1)
(with SS-SRP5000)
SURROUND BACK:
185 W per channel
1)
(with SS-SRP5000)
1)
Measured under the following conditions:
2)
Reference power output for front, center, surround
and surround back speakers. Depending on the
sound field settings and the source, there may be
no sound output.
Inputs
Analog Sensitivity: 800 mV/
50 kohms
Digital (Coaxial) Impedance: 75 ohms
Outputs (Analog)
AUDIO OUT Voltage: 800 mV/10
kohms
SUBWOOFER Voltage: 2 V/1 kohms
Tone
Gain levels
±6 dB, 1 dB step
Reproduction frequency range:
28 – 20,000 Hz
FM tuner section
Tuning range 87.5 - 108.0 MHz
Antenna FM wire antenna
Antenna terminals 75 ohms, unbalanced
Intermediate frequency
10.7 MHz
AM tuner section
Tuning range
Models of area code SP, AU
With 9-kHz tuning scale:
531 – 1,602 kHz
Models of area code E51
With 10-kHz tuning scale:
530 – 1,610 kHz
3)
With 9-kHz tuning scale:
531 – 1,602 kHz
3)
Antenna Loop antenna
Intermediate frequency
450 kHz
3)
You can change the AM tuning scale to 9 kHz or
10 kHz. After tuning in any AM station, turn off
the receiver. While holding down TUNING
MODE, press ?/1. All preset stations will be
erased when you change the tuning scale. To reset
the scale to 10 kHz (or 9 kHz), repeat the
procedure.
Video section
Inputs/Outputs
Video: 1 Vp-p, 75 ohms
COMPONENT VIDEO:
Y: 1 Vp-p, 75 ohms
P
B/CB: 0.7 Vp-p, 75 ohms
P
R/CR: 0.7 Vp-p, 75 ohms
80 MHz HD Pass Through
Area code Power requirements
SP, AU, E51 240 V AC, 50 Hz
continued
