Command List
FCB-EV7520A(GB) D-023-100-11(1)
38
Command List (4/6)
Command Set Command Command Packet Comments
CAM_MinShutter On 8x 01 04 12 02 FF pq: Minimum Shutter Position (05h to 14h)
Off 8x 01 04 12 03 FF
Limit 8x 01 04 13 00 00 0p 0q FF
CAM_PictureFlip On 8x 01 04 66 02 FF E-Flip On/Off
Off 8x 01 04 66 03 FF
CAM_ICR On 8x 01 04 01 02 FF ICR Mode On/Off
Off 8x 01 04 01 03 FF
CAM_AutoICR On 8x 01 04 51 02 FF Auto ICR Mode On/Off
Off 8x 01 04 51 03 FF
Threshold 8x 01 04 21 00 00 0p 0q FF
pq: ICR On  Off Threshold Level
CAM
_AutoICRAlarmReply
On 8x 01 04 31 02 FF Auto ICR switching Alarm On/Off
Off 8x 01 04 31 03 FF
(Reply) y0 07 04 31 02 FF
ICR Off  On
y0 07 04 31 03 FF
ICR On
 Off
CAM_Stabilizer On 8x 01 04 34 02 FF Stabilizer On/Off/HOLD
Off 8x 01 04 34 03 FF
Hold 8x 01 04 34 00 FF
CAM_Memory Reset 8x 01 04 3F 00 0p FF p: Memory Number (=0h to Fh)
Set 8x 01 04 3F 01 0p FF
Recall 8x 01 04 3F 02 0p FF
CAM_Custom Reset 8x 01 04 3F 00 7F FF Starts up in this mode when the power is turned on.
Set 8x 01 04 3F 01 7F FF
Recall 8x 01 04 3F 02 7F FF
CAM_MemSave Write 8x 01 04 23 0X 0p 0q 0r 0s FF X: 00h to 07h (Address), total 16 byte
pqrs: 0000h to FFFFh (Data)
CAM_Display On 8x 01 04 15 02 FF
(8x 01 06 06 02 FF)
Display On/Off
Off 8x 01 04 15 03 FF
(8x 01 06 06 03 FF)
On/Off 8x 01 04 15 10 FF
(8x 01 06 06 10 FF)
CAM_MultiLineTitle Title Set1 8x 01 04 73 1L 00 nn pp
qq 00 00 00 00 00 00 FF
L: Line Number, nn: H-position
pp: Color, qq: Blink
Title Set2 8x 01 04 73 2L mm nn pp
qq rr ss tt uu vv ww FF
L: Line Number,
mnpqrstuvw: Setting of characters (1 to 10)
Title Set3 8x 01 04 73 3L mm nn pp
qq rr ss tt uu vv ww FF
L: Line Number,
mnpqrstuvw: Setting of characters (11 to 20)
Title Clear 8x 01 04 74 1p FF Title Setting clear (p: 0h to Ah, F= all lines)
On 8x 01 04 74 2p FF Title display On/Off (p: 0h to Ah, F= all lines)
Off 8x 01 04 74 3p FF
CAM_Mute On 8x 01 04 75 02 FF Muting On/Off
Off 8x 01 04 75 03 FF
On/Off 8x 01 04 75 10 FF
CAM_PrivacyZone SetMask 8x 01 04 76 mm nn
0r 0r 0s 0s FF
mm: Mask Settings
nn 00: Modify, 01: New
rr: W, ss: H
Display 8x 01 04 77 pp pp pp pp FF Mask Display On/Off
pp pp pp pp: Mask Settings (0: Off, 1: On)
SetMaskColor 8x 01 04 78 pp pp pp pp
qq rr FF
pp pp pp pp: Mask Color Settings
qq: Color Setting when 0 is selected
rr: Color Setting when 1 is selected
SetPanTiltAngle 8x 01 04 79 0p 0p 0p
0q 0q 0q FF
Pan/Tilt Angle Settings
ppp: Pan, qqq: Tilt
SetPTZMask 8x 01 04 7B mm 0p 0p 0p
0q 0q 0q 0r 0r 0r 0r FF
Pan/Tilt/Zoom Settings for Mask
ppp: Pan, qqq: Tilt, rrrr: Zoom, mm: Mask Settings
