Command List (5/6)
Command Set Command Command Packet Comments
CAM_PrivacyZone Non_InterlockMask 8x 01 04 6F mm
0p 0p 0q 0q 0r 0r 0s 0s FF
mm: Non_Interlock Mask Settings
pp: X, qq: Y, rr: W, ss: H
CenterLineOff 8x 01 04 7C 03 FF Center Line Display Off
CenterLineOn 8x 01 04 7C 04 FF Center Line Display On
CAM_IDWrite — 8x 01 04 22 0p 0q 0r 0s FF pqrs: Camera ID (=0000h to FFFFh)
CAM_MD On 8x 01 04 1B 02 FF Motion Detection On/Off
Off 8x 01 04 1B 03 FF
Function Set 8x 01 04 1C 0m 0n 0p 0q 0r 0s FF m: Display mode
n: Detection Frame Set (00h to 0Fh)
pq: Threshold Level (00h to FFh)
rs: Interval Time set (00h to FFh)
Window Set 8x 01 04 1D 0m pp 0q rr 0s FF m: Select Detection Frame (0, 1, 2, 3)
pp: Start Horizontal Position (00h to 10h)
q: Start Vertical Position (00h to 0Eh)
rr: Stop Horizontal Position (01h to 11h)
s: Stop Vertical Position (01h to 0Fh)
Alarm (Reply) y0 07 04 1B 0p FF p: Detection Frame Number
CAM_Continuous
ZoomPosReply
On 8x 01 04 69 02 FF Zoom Position data Continuous Output On/Off
Off 8x 01 04 69 03 FF
(Reply) y0 07 04 69 0p 0p 0q 0q 0q 0q FF pp: D-Zoom Position
* 00: When Zoom Mode is Combine
qqqq: Zoom Position
CAM_ZoomPos
ReplyIntervalTimeSet
— 8x 01 04 6A 00 00 0p 0p FF pp: Interval Time [V cycle]
CAM_Continuous
FocusPosReply
On 8x 01 04 16 02 FF Focus Position data Continuous Output On/Off
Off 8x 01 04 16 03 FF
(Reply) y0 07 04 16 00 00 0p 0p 0p 0p FF pppp: Focus Position
CAM_FocusPosReply
IntervalTimeSet
— 8x 01 04 1A 00 00 0p 0p FF pp: Interval Time [V cycle]
CAM_RegisterValue — 8x 01 04 24 mm 0p 0p FF mm: Register No. (=00h to 7Fh)
pp: Register Value (=00h to FFh)
CAM_ChromaSuppress — 8x 01 04 5F pp FF pp: Chroma Suppress setting level
00: Off
01h to 03h: On (3 levels). Effect increases as the level number
increases.
CAM_ColorGain Direct 8x 01 04 49 00 00 00 0p FF p: Color Gain Setting 0h to Eh
CAM_ColorHue Direct 8x 01 04 4F 00 00 00 0p FF p: Color Hue Setting 0h to Eh
CAM_GammaOffset Direct 8x 01 04 1E 00 00 00 0s 0t 0u FF s: Polarity offset (0 is plus, 1 is minus)
tu: Offset s=0 (00h to 40h)
Offset s=1 (00h to 40h)
