Command List (6/6)
Command Set Command Command Packet Comments
CAM_ContrastAdjLevel Direct 8x 01 05 5D 01 0p 0q FF pq: 00h to FFh
00h to 7Fh: The smaller the value is, the lower the contrast
becomes.
80h (Initial setting): No contrast adjustment
81h to FFh: The larger the value is, the higher the contrast
becomes.
CAM_ExExpComp Reset 8x 01 04 1F 0E 00 00 FF Exposure compensation reset
Up 8x 01 04 1F 0E 02 pp FF Exposure compensation up
pp: Step number
pp=00h to 7Fh (However, 00h is the same operation as 01h.)
Down 8x 01 04 1F 0E 03 pp FF Exposure compensation down
pp: Step number
pp=00h to 7Fh (However, 00h is the same operation as 01h.)
Direct 8x 01 04 1F 4E 00 00 0p 0q FF Set the exposure compensation to the specified level
pq: Level
pq=00h to FFh
CAM_ExAperture Reset 8x 01 04 1F 02 00 00 FF Aperture control reset
Up 8x 01 04 1F 02 02 pp FF Aperture control up
pp: Step number
pp=00h to 7Fh (However, 00h is the same operation as 01h.)
Down 8x 01 04 1F 02 03 pp FF Aperture control down
pp: Step number
pp=00h to 7Fh (However, 00h is the same operation as 01h.)
Direct 8x 01 04 1F 42 00 00 0p 0q FF Set the aperture control to the specified level
pq: Level
pq=00h to FFh
CAM_ExAutoICR Threshold
(On→Off)
8x 01 04 1F 21 00 00 0p 0q FF pq: ICR On→Off threshold level when Auto ICR
pq=00h to FFh
On Level 8x 01 04 1F 21 01 00 0r 0s FF pq: ICR Off→On threshold level when Auto ICR
pq=00h to 1Ch
CAM_ExColorGain Direct 8x 01 04 1F 49 00 00 0p 0q FF Color Gain Setting
pq: Gain setting level
pq=00h to FFh
CAM_ExColorHue Direct 8x 01 04 1F 4F 00 00 0p 0q FF Color Hue Setting
pq: Phase setting level
pq=00h to FFh
CAM_HLC Parameter Set 8x 01 04 14 0p 0q FF p: HLC level (0: Off, 1: Low, 2: Mid, 3: High)
q: HLC mask level (0: Off, 1: Low, 2: Mid, 3: High)
CAM_FlickerReduction ON 8x 01 04 32 02 FF Flicker reduction ON/OFF
OFF 8x 01 04 32 03 FF
