HBD-DZ170/DZ171/DZ175/DZ310/DZ510/DZ610/DZ810
4
• Abbreviation
CND : Canadian model
E3 : 240V AC area in E model
E12 : 220 – 240V AC area in E model
E15 : Iranian model
E32 : 110 – 240V AC area in E model
EA : Saudi Arabia model
SP : Singapore model
Model Part No.
DZ175: US model
4-159-511-1[]
DZ175: CND model
4-159-511-2[]
DZ170: US model
4-159-511-3[]
DZ171: US model
4-159-511-4[]
DZ310: E12 model
4-159-511-6[]
DZ310: E3 model
4-159-511-7[]
DZ310: SP model
4-159-511-9[]
DZ310: E32 model
4-159-512-3[]
DZ510: E12 model
4-159-512-8[]
DZ610: E12 model
4-159-513-0[]
DZ610: E3 model
4-159-513-1[]
DZ610: E15 model
4-159-513-2[]
DZ610: SP model
4-159-513-4[]
DZ810: E12 model
4-159-514-1[]
DZ810: E3 model
4-159-514-2[]
DZ810: E15, EA models
4-159-514-3[]
DZ810: SP model
4-159-514-4[]
DZ810: E32 model
4-159-514-7[]
MODEL IDENTIFICATION
– Back Panel –
Parts No.
(When letters/numbers appear in the
display)
When the self-diagnosis function is activated to
prevent the system from malfunctioning, a 5-
character service number (e.g., C 13 50) with a
combination of a letter and 4 digits appears on
the TV screen or front panel display. In this case,
check the following table.
When the version number
appears on the TV screen
When you turn on the system, the version
number [VER.X.XX] (X is a number) may
appear on the TV screen. Although this is not a
malfunction and for Sony service use only,
normal system operation will not be possible.
Turn off the system, and then turn on the system
again to operate.
Self-diagnosis Function
First 3
characters of
the service
number
Cause and/or corrective action
C 13 The disc is dirty.
,Clean the disc with a soft cloth
(page 63).
E XX
(XX is a
number)
To prevent a malfunction, the
system has performed the self-
diagnosis function.
,Contact your nearest Sony
dealer or local authorized Sony
service facility and give the 5-
character service number.
Example: E 61 10
C:13:50
VER.X.XX
