HBD-DZ170/DZ171/DZ175/DZ310/DZ510/DZ610/DZ810
SECTION 7
ELECTRICAL PARTS LIST
ENCODER BOARD
***************
< CAPACITOR >
C5029 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5030 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< DIODE >
D5004 6-502-469-01 LED SLI-325URT31WR (REC TO USB)
< TRANSISTOR >
Q5002 8-729-028-96 TRANSISTOR DTC114EUA-T106
< RESISTOR >
R5013 1-216-811-11 METAL CHIP 150 5% 1/10W
R5025 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5026 1-216-837-11 METAL CHIP 22K 5% 1/10W
R5027 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R5028 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
< SWITCH >
S5001 1-762-875-21 SWITCH, KEYBOARD (REC TO USB)
< ROTARY ENCODER >
S5002 1-480-136-11 ENCODER, ROTARY (12 TYPE)
(MASTER VOLUME)
*************************************************************
A-1746-404-A FL BOARD, COMPLETE
(DZ310/DZ510/DZ610/DZ810)
A-1746-473-A FL BOARD, COMPLETE (DZ170/DZ171/DZ175)
******************
< CAPACITOR >
C5001 1-100-909-11 CERAMIC CHIP 10uF 10% 6.3V
C5003 1-126-382-11 ELECT 100uF 20% 16V
C5004 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5005 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C5006 1-163-037-11 CERAMIC CHIP 0.022uF 10% 50V
C5007 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C5008 1-119-943-11 ELECT 47uF 20% 50V
C5009 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C5010 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5011 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C5012 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C5013 1-126-157-11 ELECT 10uF 20% 16V
C5014 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5022 1-126-157-11 ELECT 10uF 20% 16V
C5023 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5026 1-115-156-11 CERAMIC CHIP 1uF 10V
C5027 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
< CONNECTOR >
* CN5001 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P
CN5002 1-779-552-21 CONNECTOR, FFC (LIF (NON-ZIF)) 15P
(DZ310/DZ510/DZ610/DZ810)
CN5005 1-779-550-21 CONNECTOR, FFC (LIF (NON-ZIF)) 13P
(DZ170/DZ171/DZ175)
CN5006 1-564-718-11 PIN, CONNECTOR (SMALL TYPE) 2P
(DZ170/DZ171/DZ175)
CN5007 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
(DZ310/DZ510/DZ610/DZ810)
< DIODE >
D5001 6-500-848-01 DIODE MC2840-T112-1
D5002 6-500-848-01 DIODE MC2840-T112-1
D5003 6-501-729-01 DIODE MAZ8051GLLS0
D5005 6-501-817-01 DIODE MA2J1110GLS0
D5006 6-500-848-01 DIODE MC2840-T112-1
< IC >
IC5001 6-702-302-01 IC TK11133CSCL-G
IC5002 6-713-497-01 IC HT16515
IC5003 6-600-767-01 IC PNA4823M02S0 (IR)
< JUMPER RESISTOR >
JR5001 1-216-296-11 SHORT CHIP 0
< COIL >
L5001 1-410-671-31 INDUCTOR 47uH
L5002 1-410-671-31 INDUCTOR 47uH
L5003 1-410-671-31 INDUCTOR 47uH
< FLUORESCENT INDICATOR TUBE >
ND5001 1-483-107-21 FLUORESCENT INDICATOR TUBE
< TRANSISTOR >
Q5001 6-550-065-01 TRANSISTOR CPH5504-TL-E
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
ENCODER
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• CAPACITORS
uF: μF
• COILS
uH: μH
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
Les composants identifi és par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce por-
tant le numéro spécifi é.
FL
The components identifi ed by mark 9 con-
tain confi dential information.
Strictly follow the instructions whenever the
components are repaired and/or replaced.
Les composants identifi és par la marque
9 contiennent des informations confi den-
tielles.
Suivre scrupuleusement les instructions
chaque fois qu’un composant est remplacé
et / ou réparé.
• Abbreviation
CND : Canadian model
E3 : 240V AC area in E model
E12 : 220 – 240V AC area in E model
E15 : Iranian model
E32 : 110 – 240V AC area in E model
EA : Saudi Arabia model
SP : Singapore model
