Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HBD-DZ170/DZ171/DZ175/DZ310/DZ510/DZ610/DZ810
76
< RESISTOR >
R5001 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R5002 1-216-839-11 METAL CHIP 33K 5% 1/10W
R5003 1-216-805-11 METAL CHIP 47 5% 1/10W
R5004 1-216-805-11 METAL CHIP 47 5% 1/10W
R5005 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R5006 1-216-813-11 METAL CHIP 220 5% 1/10W
R5007 1-216-813-11 METAL CHIP 220 5% 1/10W
R5008 1-216-813-11 METAL CHIP 220 5% 1/10W
R5009 1-216-813-11 METAL CHIP 220 5% 1/10W
R5010 1-216-813-11 METAL CHIP 220 5% 1/10W
R5011 1-216-813-11 METAL CHIP 220 5% 1/10W
R5012 1-216-844-11 METAL CHIP 82K 5% 1/10W
R5014 1-216-821-11 METAL CHIP 1K 5% 1/10W
R5015 1-216-809-11 METAL CHIP 100 5% 1/10W
R5016 1-216-809-11 METAL CHIP 100 5% 1/10W
R5017 1-216-809-11 METAL CHIP 100 5% 1/10W
R5018 1-216-805-11 METAL CHIP 47 5% 1/10W
R5019 1-216-835-11 METAL CHIP 15K 5% 1/10W
R5020 1-216-834-11 METAL CHIP 12K 5% 1/10W
R5023 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R5024 1-216-837-11 METAL CHIP 22K 5% 1/10W
< TRANSFORMER >
T5001 1-443-645-11 TRANSFORMER, DC CONVERTER
*************************************************************
A-1746-407-A IO BOARD, COMPLETE (DZ310/DZ510)
A-1746-494-A IO BOARD, COMPLETE (DZ170/DZ171/DZ175)
A-1746-535-A IO BOARD, COMPLETE (DZ610)
A-1746-740-A IO BOARD, COMPLETE (DZ810)
******************
< CAPACITOR >
C4001 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4002 1-126-933-11 ELECT 100uF 20% 16V
C4006 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4007 1-126-933-11 ELECT 100uF 20% 16V
C4009 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C4016 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4018 1-126-916-11 ELECT 1000uF 20% 6.3V
C4019 1-126-965-91 ELECT 22uF 20% 50V
C4021 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C4023 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4025 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4026 1-126-933-11 ELECT 100uF 20% 16V
C4027 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C4028 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C4030 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C4031 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C4032 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C4033 1-104-662-91 ELECT 22uF 20% 25V
C4035 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C4036 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C4038 1-104-662-91 ELECT 22uF 20% 25V
C4040 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C4041 1-104-662-91 ELECT 22uF 20% 25V
C4042 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C4043 1-104-662-91 ELECT 22uF 20% 25V
C4045 1-126-957-11 ELECT 0.22uF 20% 50V
(DZ310/DZ510/DZ610/DZ810)
C4046 1-126-933-11 ELECT 100uF 20% 16V
C4047 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4049 1-126-960-11 ELECT 1uF 20% 50V
(DZ310/DZ510/DZ610/DZ810)
C4050 1-114-813-11 CERAMIC CHIP 1uF 10% 16V
C4051 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(DZ310/DZ510/DZ610/DZ810)
C4052 1-126-933-11 ELECT 100uF 20% 16V
(DZ310/DZ510/DZ610/DZ810)
C4053 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4054 1-114-813-11 CERAMIC CHIP 1uF 10% 16V
C4055 1-104-662-91 ELECT 22uF 20% 25V
C4056 1-104-662-91 ELECT 22uF 20% 25V
C4061 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
(DZ310/DZ510/DZ610/DZ810)
C4062 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
(DZ310/DZ510/DZ610/DZ810)
C4063 1-126-964-11 ELECT 10uF 20% 50V
(DZ310/DZ510/DZ610/DZ810)
C4064 1-126-933-11 ELECT 100uF 20% 16V
C4065 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
(DZ310/DZ510/DZ610/DZ810)
C4067 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4070 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
(DZ310/DZ510/DZ610/DZ810)
C4071 1-126-963-11 ELECT 4.7uF 20% 50V
(DZ310/DZ510/DZ610/DZ810)
C4075 1-126-963-11 ELECT 4.7uF 20% 50V
(DZ310/DZ510/DZ610/DZ810)
C4076 1-126-964-11 ELECT 10uF 20% 50V
(DZ310/DZ510/DZ610/DZ810)
C4077 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
(DZ310/DZ510/DZ610/DZ810)
C4078 1-126-933-11 ELECT 100uF 20% 16V
(DZ310/DZ510/DZ610/DZ810)
C4079 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(DZ310/DZ510/DZ610/DZ810)
C4081 1-126-963-11 ELECT 4.7uF 20% 50V
(DZ310/DZ510/DZ610/DZ810)
C4084 1-126-916-11 ELECT 1000uF 20% 6.3V
< CONNECTOR >
CN4002 1-779-277-11 CONNECTOR, FFC (LIF (NON-ZIF)) 9P
CN4004 1-779-285-11 CONNECTOR, FFC (LIF (NON-ZIF)) 17P
(DZ170/DZ171/DZ175)
CN4005 1-779-287-11 CONNECTOR, FFC (LIF (NON-ZIF)) 19P
(DZ310/DZ510/DZ610/DZ810)
CN4007 1-564-706-11 PIN, CONNECTOR (SMALL TYPE) 4P
(DZ170/DZ171/DZ175)
CN4008 1-564-707-11 PIN, CONNECTOR (SMALL TYPE) 5P
(DZ310/DZ510/DZ610/DZ810)
CN4010 1-784-770-11 CONNECTOR, FFC 9P
< DIODE >
D4002 6-500-848-01 DIODE MC2840-T112-1
D4006 6-501-728-01 DIODE MAZ8051G0LS0
(DZ310/DZ510/DZ610/DZ810)
< IC >
IC4000 6-710-470-01 IC MM1758AFBE
IC4001 6-705-337-01
IC TK11150CSCL-G
FL IO
