Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HBD-DZ170/DZ171/DZ175/DZ310/DZ510/DZ610/DZ810
7777
JACK
IC4003 8-759-430-37 IC MC14052BDTR2
IC4004 6-706-078-01 IC M62429FP-TP (DZ310/DZ510/DZ610/DZ810)
IC4005 6-712-744-01 IC TK11190CSCL-G
IC4006 6-713-989-01 IC NJM2783V(TE2) (DZ310/DZ510/DZ610/DZ810)
< JACK >
J4000 1-822-283-1
1 JACK, PIN 3P (COMPONENT VIDEO OUT)
J4001 1-822-280-11 JACK, PIN 3P (VIDEO OUT,
TV/CABLE (AUDIO IN R/L))
(DZ170/DZ171/DZ175)
J4001 1-822-280-11 JACK, PIN 3P (VIDEO OUT, TV (AUDIO IN R/L))
(DZ310/DZ510/DZ610/DZ810)
< COIL >
L4000 1-469-525-91 INDUCTOR 10uH
L4001 1-469-525-91 INDUCTOR 10uH
(DZ310/DZ510/DZ610/DZ810)
< TRANSISTOR >
Q4006 6-552-200-01 FET RT3N22M-T111-1
Q4007 6-552-200-01 FET RT3N22M-T111-1
(DZ310/DZ510/DZ610/DZ810)
< RESISTOR >
R4013 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R4015 1-216-833-11 METAL CHIP 10K 5% 1/10W
R4016 1-218-285-11 METAL CHIP 75 5% 1/10W
R4017 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R4018 1-216-864-11 SHORT CHIP 0
R4020 1-218-285-11 METAL CHIP 75 5% 1/10W
R4024 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R4027 1-218-285-11 METAL CHIP 75 5% 1/10W
R4028 1-216-864-11 SHORT CHIP 0
R4030 1-218-285-11 METAL CHIP 75 5% 1/10W
R4031 1-218-827-11 METAL CHIP 150 0.5% 1/10W
R4032 1-216-821-11 METAL CHIP 1K 5% 1/10W
R4033 1-216-845-11 METAL CHIP 100K 5% 1/10W
R4034 1-216-841-11 METAL CHIP 47K 5% 1/10W
R4035 1-216-837-11 METAL CHIP 22K 5% 1/10W
R4036 1-216-841-11 METAL CHIP 47K 5% 1/10W
R4037 1-216-845-11 METAL CHIP 100K 5% 1/10W
R4038 1-216-841-11 METAL CHIP 47K 5% 1/10W
R4041 1-216-837-11 METAL CHIP 22K 5% 1/10W
R4042 1-216-841-11 METAL CHIP 47K 5% 1/10W
R4046 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R4047 1-216-841-11 METAL CHIP 47K 5% 1/10W
R4048 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R4049 1-216-841-11 METAL CHIP 47K 5% 1/10W
R4050 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R4051 1-216-841-11 METAL CHIP 47K 5% 1/10W
R4053 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R4054 1-216-841-11 METAL CHIP 47K 5% 1/10W
R4055 1-216-864-11 SHORT CHIP 0
R4056 1-216-864-11 SHORT CHIP 0 (DZ310/DZ510/DZ610/DZ810)
R4057 1-216-864-11 SHORT CHIP 0 (DZ310/DZ510/DZ610/DZ810)
R4058 1-216-864-11 SHORT CHIP 0
R4060 1-216-833-11 METAL CHIP 10K 5% 1/10W
(DZ310/DZ510/DZ610/DZ810)
R4062 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
(DZ310/DZ510/DZ610/DZ810)
R4063 1-216-864-11 SHORT CHIP 0
R4064 1-216-833-11 METAL CHIP 10K 5% 1/10W
R4065 1-216-864-11 SHORT CHIP 0
R4066 1-216-833-11 METAL CHIP 10K 5% 1/10W
R4067 1-216-821-11 METAL CHIP 1K 5% 1/10W
R4068 1-216-821-11 METAL CHIP 1K 5% 1/10W
R4069 1-216-821-11 METAL CHIP 1K 5% 1/10W
R4070 1-216-809-11 METAL CHIP 100 5% 1/10W
(DZ310/DZ510/DZ610/DZ810)
R4071 1-216-809-11 METAL CHIP 100 5% 1/10W
(DZ310/DZ510/DZ610/DZ810)
R4072 1-216-833-11 METAL CHIP 10K 5% 1/10W
(DZ310/DZ510/DZ610/DZ810)
R4073 1-216-833-11 METAL CHIP 10K 5% 1/10W
R4074 1-216-833-11 METAL CHIP 10K 5% 1/10W
R4075 1-216-833-11 METAL CHIP 10K 5% 1/10W
R4076 1-216-833-11 METAL CHIP 10K 5% 1/10W
(DZ310/DZ510/DZ610/DZ810)
R4077 1-216-833-11 METAL CHIP 10K 5% 1/10W
R4079 1-216-833-11 METAL CHIP 10K 5% 1/10W
(DZ310/DZ510/DZ610/DZ810)
R4080 1-216-845-11 METAL CHIP 100K 5% 1/10W
R4081 1-216-845-11 METAL CHIP 100K 5% 1/10W
R4082 1-216-845-11 METAL CHIP 100K 5% 1/10W
R4083 1-216-845-11 METAL CHIP 100K 5% 1/10W
R4084 1-216-833-11 METAL CHIP 10K 5% 1/10W
(DZ310/DZ510/DZ610/DZ810)
R4085 1-216-864-11 SHORT CHIP 0 (DZ310/DZ510/DZ610/DZ810)
R4086 1-216-864-11 SHORT CHIP 0 (DZ310/DZ510/DZ610/DZ810)
R4087 1-216-864-11 SHORT CHIP 0
R4088 1-216-864-11 SHORT CHIP 0
R4089 1-216-864-11 SHORT CHIP 0
R4090 1-216-841-11 METAL CHIP 47K 5% 1/10W
(DZ310/DZ510/DZ610/DZ810)
R4091 1-216-821-11 METAL CHIP 1K 5% 1/10W
(DZ310/DZ510/DZ610/DZ810)
R4092 1-216-864-11 SHORT CHIP 0
R4093 1-216-864-11 SHORT CHIP 0
R4094 1-216-864-11 SHORT CHIP 0
R4095 1-216-864-11 SHORT CHIP 0
R4096 1-216-864-11 SHORT CHIP 0
R4097 1-216-857-11 METAL CHIP 1M 5% 1/10W
(DZ310/DZ510/DZ610/DZ810)
R4100 1-216-833-11 METAL CHIP 10K 5% 1/10W
(DZ310/DZ510/DZ610/DZ810)
R4105 1-216-839-11 METAL CHIP 33K 5% 1/10W
(DZ310/DZ510/DZ610/DZ810)
R4106 1-216-834-11 METAL CHIP 12K 5% 1/10W
(DZ310/DZ510/DZ610/DZ810)
R4107 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(DZ310/DZ510/DZ610/DZ810)
0 R4113 1-215-865-11 METAL OXIDE 220 5% 1W F
(DZ310/DZ510/DZ610/DZ810)
R4115 1-216-864-11 SHORT CHIP 0
*************************************************************
JACK BOARD
***********
< CAPACITOR >
C5101 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C5102 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C5103 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C5104 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C5106 1-124-584-00 ELECT 100uF 20% 6.3V
