Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HBD-DZ170/DZ171/DZ175/DZ310/DZ510/DZ610/DZ810
78
C5107 1-126-157-11 ELECT 10uF 20% 16V
C5108 1-126-157-11 ELECT 10uF 20% 16V
C5109 1-126-157-11 ELECT 10uF 20% 16V
C5112 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C5116 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C5117 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C5118 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C5119 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C5120 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C5121 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C5122 1-162-925-11 CERAMIC CHIP 68PF 5% 50V
C5123 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
C5124 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C5125 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5126 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5127 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5128 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5129 1-124-584-00 ELECT 100uF 20% 6.3V
C5130 1-124-584-00 ELECT 100uF 20% 10V
C5131 1-124-589-11 ELECT 47uF 20% 16V
< DIODE >
D5101 6-500-848-01 DIODE MC2840-T112-1
< FERRITE BEAD >
FB5101 1-500-236-22 BEAD, FERRITE (CHIP) (1608)
FB5102 1-500-236-22 BEAD, FERRITE (CHIP) (1608)
FB5103 1-500-236-22 BEAD, FERRITE (CHIP) (1608)
< IC >
IC5101 8-759-100-96 IC uPC4558G2
IC5102 8-759-100-96
IC uPC4558G2
< JACK >
J5101 1-819-878-31 JACK (A.CAL MIC)
J5102 1-819-878-31 JACK (AUDIO IN)
< TRANSISTOR >
Q5101 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
(DZ310/DZ510/DZ610/DZ810)
Q5102 8-729-028-73 TRANSISTOR DTA114EUA-T106
(DZ310/DZ510/DZ610/DZ810)
< RESISTOR >
R5101 1-216-833-11 METAL CHIP 10K 5% 1/10W
(DZ310/DZ510/DZ610/DZ810)
R5105 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R5106 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R5107 1-216-821-11 METAL CHIP 1K 5% 1/10W
R5108 1-216-845-11 METAL CHIP 100K 5% 1/10W
R5109 1-216-845-11 METAL CHIP 100K 5% 1/10W
R5110 1-216-845-11 METAL CHIP 100K 5% 1/10W
R5111 1-216-817-11 METAL CHIP 470 5% 1/10W
R5112 1-216-817-11 METAL CHIP 470 5% 1/10W
R5113 1-216-817-11 METAL CHIP 470 5% 1/10W
R5115 1-216-864-11 SHORT CHIP 0
R5116 1-216-837-11 METAL CHIP 22K 5% 1/10W
R5117 1-216-837-11 METAL CHIP 22K 5% 1/10W
R5118 1-216-835-11 METAL CHIP 15K 5% 1/10W
R5119 1-216-837-11 METAL CHIP 22K 5% 1/10W
R5120 1-216-821-11 METAL CHIP 1K 5% 1/10W
R5121 1-216-821-11 METAL CHIP 1K 5% 1/10W
R5122 1-216-837-11 METAL CHIP 22K 5% 1/10W
R5123 1-216-821-11 METAL CHIP 1K 5% 1/10W
R5124 1-216-857-11 METAL CHIP 1M 5% 1/10W
R5125 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R5126 1-216-821-11 METAL CHIP 1K 5% 1/10W
R5127 1-216-821-11 METAL CHIP 1K 5% 1/10W
R5128 1-216-821-11 METAL CHIP 1K 5% 1/10W
R5129 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R5130 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R5131 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R5132 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R5134 1-216-821-11 METAL CHIP 1K 5% 1/10W
R5135 1-216-864-11 SHORT CHIP 0 (DZ170/DZ171/DZ175)
*************************************************************
A-1746-218-A KEY-SW BOARD, COMPLETE
***********************
< CONNECTOR >
* CN5201 1-580-055-21 PIN, CONNECTOR (SMD) 2P
CN5202 1-580-057-11 PIN, CONNECTOR (SMD) 4P
< RESISTOR >
R5201 1-216-821-11 METAL CHIP 1K 5% 1/10W
R5202 1-216-809-11 METAL CHIP 100 5% 1/10W
R5203 1-216-821-11 METAL CHIP 1K 5% 1/10W
R5204 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
< SWITCH >
S5201 1-786-650-21 SWITCH, TACTILE (x)
S5202 1-786-650-21 SWITCH, TACTILE (N)
S5203 1-786-650-21 SWITCH, TACTILE (Z)
S5204 1-786-650-21 SWITCH, TACTILE (FUNCTION)
*************************************************************
JACK KEY-SW
