102
Input/Output connectors
Audio/Video output
10-pin connector
Video signal: 1 Vp-p, 75 Ω (ohms)
Luminance signal: 1 Vp-p, 75 Ω (ohms)
Chrominance signal: 0.286 Vp-p, 75 Ω
(ohms)
Audio signal: 327 mV (at load
impedance 47 kΩ (kilohms)), Output
impedance with less than 2.2 kΩ
(kilohms)
COMPONENT OUT jack
Y: 1 Vp-p, 75 Ω (ohms)
P
B/PR, CB/CR: ± 350 mV, 75 Ω (ohms)
HDMI OUT jack
TypeA (19-pin)
Headphone jack (HDR-HC7)
Stereo minijack (Ø 3.5 mm)
LANC jack
Stereo mini-minijack (Ø 2.5 mm)
USB jack
mini-B
MIC (PLUG IN POWER) jack
(HDR-HC7)
Stereo minijack (Ø 3.5 mm)
HDV/DV jack
i.LINK Interface (IEEE1394, 4-pin
connector S100)
LCD screen
6.9 cm (2.7 type, aspect ratio 16:9)
Total dot number
211 200 (960 × 220)
General
Power requirements
DC 6.8 V/7.2 V (battery pack)
DC 8.4 V (AC Adaptor)
Average power consumption
HDR-HC5:
During camera recording using the
viewfinder with normal brightness:
HDV recording 3.8 W
DV recording 3.5 W
During camera recording using the
LCD with normal brightness:
HDV recording 4.1 W
DV recording 3.8 W
HDR-HC7:
During camera recording using the
viewfinder with normal brightness:
HDV recording 4.2 W
DV recording 4.0 W
During camera recording using the
LCD with normal brightness:
HDV recording 4.5 W
DV recording 4.3 W
Operating temperature
0 °C to + 40 °C (32 °F to 104 °F)
Storage temperature
-20 °C to + 60 °C (-4 °F to + 140 °F)
Dimensions (approx.)
HDR-HC5:
82 × 82 × 134 mm
(3 1/4 × 3 1/4 × 5 3/8 in.) (w/h/d)
including the projecting parts
82 × 82 × 134 mm
(3 1/4 × 3 1/4 × 5 3/8 in.) (w/h/d)
including the projecting parts with the
supplied battery pack NP-FH60
attached
HDR-HC7:
82 × 82 × 138 mm
(3 1/4 × 3 1/4 × 5 1/2 in.) (w/h/d)
including the projecting parts
82 × 82 × 138 mm
(3 1/4 × 3 1/4 × 5 1/2 in.) (w/h/d)
including the projecting parts with the
supplied battery pack NP-FH60
attached
Specifications (Continued)
