8
HCD-AZ2D/AZ5D
S-MASTER BOARD SERVICE POSITION
• In checking the S-MASTER board, prepare extension jig (Part No. J-2501-082-A: 1.25mm pitch, 9 cores, length 300mm).
MAIN board
(CN102)
S-MASTER board
(CN502)
Connect extension jig (J-2501-082-A) to the
S-MASTER board (CN502) and MAIN board (CN102).
