Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
SECTION 9
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
• Abbreviation
CND : Canadian model
AUS : Australian model
G : German model
AED : North European model
EA : Saudi Arabia model
MY : Malaysia model
SP : Singapore model
TH : Thai model
TW : Taiwan model
KR : Korea model
When indicating parts by reference number,
please include the board name.
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
MX : Mexican model
AR : Argentina model
1-675-911-11 ADDRESS SENSOR BOARD
**********************
< IC >
IC711 8-749-016-76 IC RPI-321
< RESISTOR >
R711 1-247-876-11 CARBON 75K 5% 1/4W
R712 1-249-409-11 CARBON 220 5% 1/4W F
R713 1-249-429-11 CARBON 10K 5% 1/4W
< SWITCH >
S711 1-771-821-11 SWITCH, PUSH (1 KEY)(UP DOWN)
**************************************************************
A-4428-042-A AMP BOARD, COMPLETE (AED,AEP,G,UK,CIS)
********************
A-4428-052-A AMP BOARD, COMPLETE (US)
********************
A-4428-064-A AMP BOARD, COMPLETE
(AR,AUS,E,EA,KR,MX,MY,SP,TW)
********************
A-4428-252-A AMP BOARD, COMPLETE (CND)
********************
A-4428-590-A AMP BOARD, COMPLETE (TH)
********************
< CAPACITOR >
C501 1-126-964-11 ELECT 10uF 20.00% 50V
(EXCEPT US,CND)
C501 1-128-582-11 ELECT 10uF 20.00% 100V
(US,CND)
C502 1-162-290-31 CERAMIC 470PF 10% 50V
C503 1-162-282-31 CERAMIC 100PF 10% 50V
C504 1-128-551-11 ELECT 22uF 20.00% 25V
(EXCEPT US,CND)
C504 1-126-965-11 ELECT 22uF 20.00% 50V
(US,CND)
C507 1-136-495-11 MYLAR 0.068uF 5.00% 50V
C508 1-136-495-11 MYLAR 0.068uF 5.00% 50V
C509 1-126-965-11 ELECT 22uF 20.00% 50V
(AED,AEP,CIS,CND,G,UK)
C509 1-128-560-11 ELECT 22uF 20.00% 100V
(US,AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
C511 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C512 1-162-294-31 CERAMIC 0.001uF 10% 50V
(AED,AEP,CIS,G,UK)
C513 1-162-294-31 CERAMIC 0.001uF 10% 50V
(AED,AEP,CIS,G,UK)
C541 1-136-165-00 MYLAR 0.1uF 5.00% 50V
(AED,AEP,CIS,CND,G,UK)
C541 1-130-777-00 MYLAR 0.1uF 10.00% 100V
(US,AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
C542 1-135-515-11 ELECT 3300uF 20% 50V
(AED,AEP,CIS,CND,G,UK)
C542 1-135-516-11 ELECT 3300uF 20% 63V
(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW,US)
C543 1-164-159-11 CERAMIC 0.1uF 50V
C545 1-128-549-11 ELECT 3300uF 20.00% 35V
C551 1-126-964-11 ELECT 10uF 20.00% 50V
(EXCEPT US,CND)
C551 1-128-582-11 ELECT 10uF 20.00% 100V
(US,CND)
C552 1-162-290-31 CERAMIC 470PF 10% 50V
C553 1-162-282-31 CERAMIC 100PF 10% 50V
C554 1-128-551-11 ELECT 22uF 20.00% 25V
(EXCEPT US,CND)
C554 1-126-965-11 ELECT 22uF 20.00% 50V
(US,CND)
C557 1-136-495-11 MYLAR 0.068uF 5.00% 50V
C558 1-136-495-11 MYLAR 0.068uF 5.00% 50V
C559 1-126-965-11 ELECT 22uF 20.00% 50V
(AED,AEP,CIS,CND,G,UK)
C559 1-128-560-11 ELECT 22uF 20.00% 100V
(US,AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
C591 1-136-165-00 MYLAR 0.1uF 5.00% 50V
(AED,AEP,CIS,CND,G,UK)
C591 1-130-777-00 MYLAR 0.1uF 10.00% 100V
(US,AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
C592 1-135-515-11 ELECT 3300uF 20% 50V
(AED,AEP,CIS,CND,G,UK)
C592 1-135-516-11 ELECT 3300uF 20% 63V
(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW,US)
< CONNECTOR >
CN502 1-778-981-21 CONNECTOR, BOARD TO BOARD 13P
CN503 1-778-981-21 CONNECTOR, BOARD TO BOARD 13P
CN504 1-785-314-11 PIN, CONNECTOR (STRAIGHT) 2P
(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
