Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
53
1-676-220-11 HEAD (A) BOARD
**************
< CONNECTOR >
* CN1 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
**************************************************************
1-676-221-11 HEAD (B) BOARD
**************
CN2 1-564-722-11 PIN, CONNECTOR (SMALL TYPE) 6P
**************************************************************
A-2007-838-A LEAF SW BOARD, COMPLETE
***********************
< CAPACITOR >
C1001 1-107-716-11 ELECT 33uF 20.00% 10V
< CONNECTOR >
CN1001 1-568-860-21 SOCKET, CONNECTOR 17P
< DIODE >
D1001 8-719-911-19 DIODE 1SS133T-72
D1002 8-719-911-19 DIODE 1SS133T-72
< IC >
IC1001 8-749-016-76 IC RPI-321
IC1002 8-749-016-76 IC RPI-321
< TRANSISTOR >
Q1001 8-729-029-56 TRANSISTOR DTA144ESA-TP
< RESISTOR >
R1001 1-249-409-11 CARBON 220 5% 1/4W F
R1002 1-249-409-11 CARBON 220 5% 1/4W F
R1003 1-249-414-11 CARBON 560 5% 1/4W F
R1004 1-247-834-11 CARBON 1.3K 5% 1/4W
R1005 1-247-818-11 CARBON 300 5% 1/4W
R1006 1-247-864-11 CARBON 24K 5% 1/4W
R1007 1-247-780-00 CARBON 7.5 5% 1/4W
R1008 1-249-417-11 CARBON 1K 5% 1/4W F
< VARIABLE RESISTOR >
RV1001 1-241-785-11 RES, ADJ, CARBON 10K
RV1002 1-241-785-11 RES, ADJ, CARBON 10K
< SWITCH >
S1001 1-570-953-11 SWITCH, PUSH (1 KEY)(A PLAY)
S1002 1-570-953-11 SWITCH, PUSH (1 KEY)(B PLAY)
S1003 1-771-333-11 SWITCH, LEAF (A HALF)
S1004 1-771-536-11 SWITCH, LEAF (A 120/70)
S1005 1-771-536-11 SWITCH, LEAF (REC A)
S1006 1-771-333-11 SWITCH, LEAF (B HALF)
S1008 1-771-536-11 SWITCH, LEAF (B 120/70)
S1009 1-771-536-11 SWITCH, LEAF (REC B)
**************************************************************
A-4428-038-A MAIN BOARD, COMPLETE (AED,AEP,G,UK,CIS)
*********************
A-4428-046-A MAIN BOARD, COMPLETE (US,CND)
*********************
A-4428-060-A MAIN BOARD, COMPLETE (MY,SP,TW)
*********************
A-4428-256-A MAIN BOARD, COMPLETE (AUS)
*********************
A-4428-258-A MAIN BOARD, COMPLETE (E)
*********************
A-4428-262-A MAIN BOARD, COMPLETE (KR)
*********************
A-4428-265-A MAIN BOARD, COMPLETE (EA)
*********************
A-4428-598-A MAIN BOARD, COMPLETE (TH)
*********************
A-4428-733-A MAIN BOARD, COMPLETE (AR,MX)
*********************
4-224-796-21 HEAT SINK (B)
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C101 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C102 1-126-961-11 ELECT 2.2uF 20.00% 50V
C103 1-126-964-11 ELECT 10uF 20.00% 50V
C104 1-126-964-11 ELECT 10uF 20.00% 50V
C105 1-126-964-11 ELECT 10uF 20.00% 50V
C107 1-136-167-00 MYLAR 0.15uF 5.00% 50V
(US,CND)
C107 1-136-164-00 MYLAR 0.082uF 5.00% 50V
(EXCEPT US,CND)
C108 1-136-167-00 MYLAR 0.15uF 5.00% 50V
(US,CND)
C108 1-136-164-00 MYLAR 0.082uF 5.00% 50V
(EXCEPT US,CND)
C109 1-163-019-00 CERAMIC CHIP 0.0068uF 10% 50V
C110 1-163-019-00 CERAMIC CHIP 0.0068uF 10% 50V
C111 1-163-018-00 CERAMIC CHIP 0.0056uF 5% 50V
C112 1-126-961-11 ELECT 2.2uF 20.00% 50V
C113 1-126-957-11 ELECT 0.22uF 20.00% 50V
(AR,AUS,E,EA,KR,MX,MY,SP,TW)
C115 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C116 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C117 1-126-964-11 ELECT 10uF 20.00% 50V
C118 1-126-961-11 ELECT 2.2uF 20.00% 50V
(EXCEPT US,CND)
C121 1-126-964-11 ELECT 10uF 20.00% 50V
(AR,AUS,E,EA,KR,MX,MY,SP,TW)
C122 1-126-964-11 ELECT 10uF 20.00% 50V
(AR,AUS,E,EA,KR,MX,MY,SP,TW)
C123 1-126-964-11 ELECT 10uF 20.00% 50V
(AR,AUS,E,EA,KR,MX,MY,SP,TW)
C124 1-163-038-91 CERAMIC CHIP 0.1uF 25V
(EXCEPT US,CND)
C125 1-126-964-11 ELECT 10uF 20.00% 50V
(AR,AUS,E,EA,KR,MX,MY,SP,TW)
C131 1-136-169-00 MYLAR 0.22uF 5.00% 50V
C132 1-126-964-11 ELECT 10uF 20.00% 50V
C133 1-126-924-11 ELECT 330uF 20.00% 6.3V
C134 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C135 1-126-964-11 ELECT 10uF 20.00% 50V
C140 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C141 1-126-964-11 ELECT 10uF 20.00% 50V
HEAD (A) HEAD (B) LEAF SW MAIN
