Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
61
R844 1-216-097-91 RES-CHIP 100K 5% 1/10W
(EXCEPT US,CND)
R845 1-216-121-91 RES-CHIP 1M 5% 1/10W
(EXCEPT US,CND)
R851 1-260-304-51 CARBON 10 5% 1/2W
(AED,AEP,CIS,G,UK)
R852 1-260-304-51 CARBON 10 5% 1/2W
(AED,AEP,CIS,G,UK)
R861 1-216-049-91 RES-CHIP 1K 5% 1/10W
R862 1-216-073-00 METAL CHIP 10K 5% 1/10W
R863 1-216-089-91 RES-CHIP 47K 5% 1/10W
R864 1-216-049-91 RES-CHIP 1K 5% 1/10W
R865 1-216-049-91 RES-CHIP 1K 5% 1/10W
R866 1-216-019-00 METAL CHIP 56 5% 1/10W
R868 1-215-891-11 METAL OXIDE 680 5% 2W
R869 1-215-891-11 METAL OXIDE 680 5% 2W
R912 1-216-295-91 SHORT 0
R961 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
R962 1-216-089-91 RES-CHIP 47K 5% 1/10W
(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
R963 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
R964 1-216-089-91 RES-CHIP 47K 5% 1/10W
(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
R965 1-216-089-91 RES-CHIP 47K 5% 1/10W
(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
R966 1-216-019-00 METAL CHIP 56 5% 1/10W
R967 1-216-025-91 RES-CHIP 100 5% 1/10W
(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
< COMPOSITION CIRCUIT BLOCK >
RB641 1-234-457-11 ENCAPSULATED COMPONENT
< VARIABLE RESISTOR >
RV301 1-241-764-11 RES, ADJ, CARBON 10K
RV302 1-241-762-11 RES, ADJ, CARBON 2.2K
RV303 1-241-762-11 RES, ADJ, CARBON 2.2K
RV304 1-241-768-11 RES, ADJ, CARBON 220K
RV351 1-241-764-11 RES, ADJ, CARBON 10K
RV352 1-241-762-11 RES, ADJ, CARBON 2.2K
RV353 1-241-762-11 RES, ADJ, CARBON 2.2K
RV354 1-241-768-11 RES, ADJ, CARBON 220K
RV611 1-238-601-11 RES, ADJ, CARBON 22K
< RELAY >
RY801 1-755-373-11 RELAY
< TRANSFORMER >
T301 1-423-980-11 TRANSFORMER, BIAS OSCILLATION
T601 1-435-195-11 TRANSFORMER, DISCRIMINATOR
T602 1-234-477-11 ENCAPSULATED COMPONENT
(AED,AEP,CIS,G,UK)
< TERMINAL >
TM601 1-694-555-11 TERMINAL BOARD (4P) (FM/AM)
(US,CND,AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
TM601 1-694-556-21 TERMINAL BOARD (ANT.PAL)(FM/AM)
(AED,AEP,CIS,G,UK)
TM801 1-694-635-11 TERMINAL BOARD (4P) (SPEAKER)
< VIBRATOR >
X401 1-567-098-41 VIBRATOR, CRYSTAL(32.768 KHz)
X402 1-781-107-21 VIBRATOR, SERAMIC(16 MHz )
X651 1-760-549-31 VIBRATOR, CRYSTAL(4.5 MHz)
< VIBRATOR >
XT681 1-579-900-21 VIBRATOR, CRYSTAL(4.332 MHz)
(AED,AEP,CIS,G,UK)
**************************************************************
1-675-910-11 MOTOR BOARD
*************
< CAPACITOR >
C721 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
< CONNECTOR >
CN721 1-770-516-31 CONNECTOR, FFC 8P
CN722 1-785-330-11 PIN, CONNECTOR (LIGHT ANGLE)4P
< SWITCH >
S701 1-771-822-11 SWITCH, LEVER (SLIDE)
**************************************************************
A-4428-055-A PANEL BOARD, COMPLETE
(AED,AEP,CND,G,UK,US,CIS)
**********************
A-4428-066-A PANEL BOARD, COMPLETE
(AR,AUS,E,EA,KR,MX,MY,SP,TW)
**********************
A-4428-593-A PANEL BOARD, COMPLETE (TH)
**********************
4-224-584-01 HOLDER (FL)
< CAPACITOR >
C601 1-124-589-11 ELECT 47uF 20% 16V
C602 1-126-163-11 ELECT 4.7uF 20% 50V
C603 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C604 1-162-294-31 CERAMIC 0.001uF 10% 50V
C605 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C607 1-124-589-11 ELECT 47uF 20% 16V
C608 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C609 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C610 1-126-157-11 ELECT 10uF 20% 16V
(AR,AUS,E,EA,KR,MX,MY,SP,TH,TW)
C611 1-126-157-11 ELECT 10uF 20% 16V
C612 1-162-303-11 CERAMIC 0.0033uF 30.00% 16V
C613 1-126-157-11 ELECT 10uF 20% 16V
C614 1-126-157-11 ELECT 10uF 20% 16V
C615 1-126-163-11 ELECT 4.7uF 20% 50V
C616 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C617 1-162-306-11 CERAMIC 0.01uf 30.00% 16V
C620 1-126-157-11 ELECT 10uF 20% 16V
C631 1-162-294-31 CERAMIC 0.001uF 10% 50V
C632 1-162-294-31 CERAMIC 0.001uF 10% 50V
C633 1-164-159-11 CERAMIC 0.1uF 50V
MAIN MOTOR PANEL
