9
6
Cut the fourteen melted-connection points with a cutting plier.
Note: When attching the panel board,
refer to "Service Note" on page 4.
8
Panel board
1
Knob (Volume)
2
Hexagon nut
3
Bracket (Volume)
5
4
Ring (Vol)
7
Six claws
8
Two screws
(+BVTT 4
×
6)
3
Two screws
(+BVTP 3
×
10)
6
Five screws
(+BVTP 3
×
10)
5
Five screws
(+BVTP 3
×
10
7
Panel, back
9
Two screws (+BVTT 4
×
6)
qa
Trans board
4
Sub-trans
board
q;
Trans
1
Connector (CN975)
2
Connector (CN974)
3-5. PANEL BOARD
3-6. SUB-TRANS BOARD AND TRANS BOARD
