Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
93
HCD-C5
C655 1-162-286-31 CERAMIC 220PF 10.00% 50V
C656 1-162-286-31 CERAMIC 220PF 10.00% 50V
C657 1-162-286-31 CERAMIC 220PF 10.00% 50V
C658 1-162-286-31 CERAMIC 220PF 10.00% 50V
C659 1-162-286-31 CERAMIC 220PF 10.00% 50V
C660 1-162-286-31 CERAMIC 220PF 10.00% 50V
C661 1-162-286-31 CERAMIC 220PF 10.00% 50V
C662 1-162-286-31 CERAMIC 220PF 10.00% 50V
C664 1-124-247-11 ELECT 10uF 20.00% 35V
C665 1-124-589-11 ELECT 47uF 20% 16V
< CONNECTOR >
∗ CN601 1-784-738-11 CONNECTOR, FFC 16P
< DIODE >
D601 8-719-300-71 DIODE SEL2210R-TP3 (?/1)
D602 8-719-072-76 DIODE SEL5E23C-TP15 (FUNCTIONz)
D603 8-719-072-76 DIODE SEL5E23C-TP15 (VOL +)
D604 8-719-072-76 DIODE SEL5E23C-TP15 (VOL –)
D605 8-719-072-76 DIODE SEL5E23C-TP15 (CDZ)
D606 8-719-072-76 DIODE SEL5E23C-TP15 (u)
D607 8-719-072-76 DIODE SEL5E23C-TP15 (x)
D608 8-719-072-76 DIODE SEL5E23C-TP15 (>)
D609 8-719-072-76 DIODE SEL5E23C-TP15 (.)
D610 8-719-072-76 DIODE SEL5E23C-TP15 (MDZ)
< FILTER >
FL601 1-518-755-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC601 8-759-297-23 IC M66004M8FP-200D
IC602 8-759-827-69 IC NJL63H400A-1 (g)
< TRANSISTOR >
Q601 8-729-120-28 TRANSISTOR 2SC3052EF-T1-LEF
Q602 8-729-120-28 TRANSISTOR 2SC3052EF-T1-LEF
Q604 8-729-120-28 TRANSISTOR 2SC3052EF-T1-LEF
< RESISTOR >
R601 1-249-441-11 CARBON 100K 5% 1/4W
R602 1-249-441-11 CARBON 100K 5% 1/4W
R603 1-249-417-11 CARBON 1K 5% 1/4W
R604 1-249-417-11 CARBON 1K 5% 1/4W
R607 1-249-441-11 CARBON 100K 5% 1/4W
R608 1-216-838-11 METAL CHIP 27K 5% 1/16W
R609 1-216-821-11 METAL CHIP 1K 5% 1/16W
R610 1-216-821-11 METAL CHIP 1K 5% 1/16W
R611 1-216-821-11 METAL CHIP 1K 5% 1/16W
R612 1-216-821-11 METAL CHIP 1K 5% 1/16W
R614 1-216-813-11 METAL CHIP 220 5% 1/16W
R615 1-216-813-11 METAL CHIP 220 5% 1/16W
R616 1-216-813-11 METAL CHIP 220 5% 1/16W
R617 1-216-813-11 METAL CHIP 220 5% 1/16W
R618 1-216-809-11 METAL CHIP 100 5% 1/16W
R619 1-216-813-11 METAL CHIP 220 5% 1/16W
R620 1-216-813-11 METAL CHIP 220 5% 1/16W
R621 1-216-813-11 METAL CHIP 220 5% 1/16W
R622 1-216-813-11 METAL CHIP 220 5% 1/16W
R623 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R624 1-249-433-11 CARBON 22K 5% 1/4W
R639 1-216-797-11 METAL CHIP 10 5% 1/16W
R640 1-249-413-11 CARBON 470 5% 1/4W
R641 1-216-819-11 METAL CHIP 680 5% 1/16W
R642 1-216-821-11 METAL CHIP 1K 5% 1/16W
R643 1-216-817-11 METAL CHIP 470 5% 1/16W
R644 1-216-819-11 METAL CHIP 680 5% 1/16W
R645 1-216-821-11 METAL CHIP 1K 5% 1/16W
R646 1-216-817-11 METAL CHIP 470 5% 1/16W
R647 1-216-819-11 METAL CHIP 680 5% 1/16W
R648 1-216-821-11 METAL CHIP 1K 5% 1/16W
< SWITCH >
S602 1-762-875-21 SWITCH, KEYBOARD
(REC/REC IT/CD SYNC NORMAL)
S603 1-762-875-21 SWITCH, KEYBOARD (VOL –)
S604 1-762-875-21 SWITCH, KEYBOARD (VOL +)
S605 1-762-875-21 SWITCH, KEYBOARD (FUNCTIONz)
S606 1-762-875-21 SWITCH, KEYBOARD (?/1)
S607 1-762-875-21 SWITCH, KEYBOARD (CDZ)
S608 1-762-875-21 SWITCH, KEYBOARD (u)
S609 1-762-875-21 SWITCH, KEYBOARD (x)
S610 1-762-875-21 SWITCH, KEYBOARD (CD SYNC HIGH)
S611 1-762-875-21 SWITCH, KEYBOARD (MDZ)
S612 1-762-875-21 SWITCH, KEYBOARD (./m/TUNING–)
S613 1-762-875-21 SWITCH, KEYBOARD (>/M/TUNING+)
∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗
A-4427-414-A POWER BOARD, COMPLETE (HK,KR)
A-4476-948-A POWER BOARD, COMPLETE (AEP,UK,AUS)
∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗
< CAPACITOR >
C902 1-126-767-11 ELECT 1000uF 20.00% 16V
C903 1-126-964-11 ELECT 10uF 20.00% 50V
C904 1-126-916-11 ELECT 1000uF 20.00% 6.3V
C905 1-126-964-11 ELECT 10uF 20.00% 50V
C906 1-126-926-11 ELECT 1000uF 20.00% 10V
C907 1-126-964-11 ELECT 10uF 20.00% 50V
C908 1-126-935-11 ELECT 470uF 20.00% 10V
C909 1-126-964-11 ELECT 10uF 20.00% 50V
C910 1-126-916-11 ELECT 1000uF 20.00% 6.3V
C912 1-126-916-11 ELECT 1000uF 20.00% 6.3V
C914 1-126-935-11 ELECT 470uF 20.00% 10V
C922 1-126-933-11 ELECT 100uF 20.00% 16V
C961 1-136-165-00 FILM 0.1uF 5.00% 50V
C962 1-126-944-11 ELECT 3300uF 20.00% 25V
C971 1-136-165-00 FILM 0.1uF 5.00% 50V
C974 1-126-968-11 ELECT 100uF 20.00% 50V
C975 1-126-964-11 ELECT 10uF 20.00% 50V
C976 1-126-964-11 ELECT 10uF 20.00% 50V
C981 1-136-165-00 FILM 0.1uF 5.00% 50V
C982 1-136-165-00 FILM 0.1uF 5.00% 50V
C983 1-135-933-11 ELECT 22000uF 20% 16V
C984 1-128-548-11 ELECT 4700uF 20.00% 25V
0 C991 1-113-925-11 CERAMIC 0.01uF 20.00% 250V
C992 1-126-963-11 ELECT 4.7uF 20.00% 50V
PANEL POWER
Ver 1.1 2001.09
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
