Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
94
HCD-C5
< CONNECTOR >
∗ CN901 1-770-732-11 CONNECTOR, BOARD TO BOARD 15P
CN902 1-778-241-11 CONNECTOR, BOARD TO BOARD 5P
CN991 1-564-321-00 PIN, CONNECTOR 2P
∗ CN992 1-564-321-21 PIN, CONNECTOR 2P
∗ CN995 1-564-511-11 PLUG, CONNECTOR 8P
< DIODE >
D906 8-719-991-33 DIODE 1SS133T-77
D921 8-719-200-82 DIODE 11ES2-TA1B
D961 8-719-200-82 DIODE 11ES2-TA1B
D962 8-719-200-82 DIODE 11ES2-TA1B
D963 8-719-200-82 DIODE 11ES2-TA1B
D964 8-719-200-82 DIODE 11ES2-TA1B
D971 8-719-200-82 DIODE 11ES2-TA1B
D972 8-719-200-82 DIODE 11ES2-TA1B
D973 8-719-200-82 DIODE 11ES2-TA1B
D974 8-719-200-82 DIODE 11ES2-TA1B
D975 8-719-982-24 DIODE MTZJ-T-77-33A
D976 8-719-921-40 DIODE MTZJ-T-77-4.7A
D981 8-719-028-23 DIODE D3SBA20-4101
D982 8-719-200-82 DIODE 11ES2-TA1B
D983 8-719-200-82 DIODE 11ES2-TA1B
D984 8-719-200-82 DIODE 11ES2-TA1B
D985 8-719-200-82 DIODE 11ES2-TA1B
D991 8-719-991-33 DIODE 1SS133T-77
D992 8-719-991-33 DIODE 1SS133T-77
D993 8-719-991-33 DIODE 1SS133T-77
< BRACKET >
EB901 4-924-906-21 BRACKET (MT)
EB902 4-924-906-21 BRACKET (MT)
< IC >
IC901 8-759-231-57 IC TA7810S
IC902 8-759-701-75 IC NJM7805FA
IC903 8-759-450-49 IC uPC2907HF
IC904 8-759-701-75 IC NJM7805FA
IC905 8-759-701-75 IC NJM7805FA
IC906 8-759-686-72 IC uPC29L04J-T
IC907 8-759-647-11 IC uPC2905HF
< LINE FILTER >
0 LF991 1-419-625-11 COIL, LINE FILTER
< TRANSISTOR >
Q971 8-729-141-83 TRANSISTOR 2SB1375
Q991 8-729-120-28 TRANSISTOR 2SC1623-T1-L5L6
< RESISTOR >
0 R971 1-219-153-11 FUSIBLE 10 5% 1/4W
R972 1-260-103-11 CARBON 2.2K 5% 1/2W
R973 1-249-429-11 CARBON 10K 5% 1/4W
R974 1-249-413-11 CARBON 470 5% 1/4W
R975 1-249-413-11 CARBON 470 5% 1/4W
0 R981 1-219-120-81 FUSIBLE 0.15 5% 1/4W
0 R982 1-240-877-11 FUSIBLE 0.15 5% 1/2W
R991 1-249-429-11 CARBON 10K 5% 1/4W
R992 1-216-833-11 METAL CHIP 10K 5% 1/16W
R993 1-249-413-11 CARBON 470 5% 1/4W
R994 1-249-413-11 CARBON 470 5% 1/4W
R995 1-216-055-11 METAL CHIP 1.8K 5% 1/10W
R995 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R996 1-247-791-91 CARBON 22 5% 1/4W
< RELAY >
0 RY991 1-755-276-11 RELAY, POWER
< TRANSFORMER >
0 T901 1-437-243-11 TRANSFORMER, POWER (SUB) (AEP,UK,AUS)
0 T901 1-437-245-11 TRANSFORMER, POWER (SUB) (HK,KR)
∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗
1-682-099-11 SW BOARD
∗∗∗∗∗∗∗∗∗
< SWITCH >
S1 1-786-214-11 SWITCH (DETECTION)
(Disc IN/8cm Disc Detect)
S2 1-786-212-11 SWITCH (DETECTION)
(12cm Disc/12cm Disc Eject End Detect)
S3 1-786-213-11 SWITCH (DETECTION)
(Disc Existence, Chaking, Releasing Detect)
S4 1-786-214-11 SWITCH (DETECTION)
(8cm Disc Eject End Detect)
∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗
A-4427-413-A UCOM BOARD, COMPLETE (AUS,HK,KR)
A-4476-947-A UCOM BOARD, COMPLETE (AEP,UK)
∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗∗
∗ 4-363-146-00 HEAT SINK, V.OUT
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< LITHIUM BATTERY >
BT921 1-528-938-11 BATTERY, LITHIUM ION SECONDARY
< CAPACITOR >
C201 1-126-176-11 ELECT 220uF 20% 10V
C202 1-119-774-11 ELECT 100uF 20.00% 16V
C203 1-164-159-11 CERAMIC 0.1uF 50V
C204 1-104-665-11 ELECT 100uF 20.00% 10V
C206 1-119-941-11 ELECT 470uF 20.00% 6.3V
C208 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C211 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C212 1-162-294-31 CERAMIC 0.001uF 10% 50V
C213 1-162-294-31 CERAMIC 0.001uF 10% 50V
C216 1-126-786-11 ELECT 47uF 20.00% 16V
C222 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C223 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C224 1-136-165-00 FILM 0.1uF 5.00% 50V
C225 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C226 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
POWER SW UCOM
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
Ver 1.1 2001.09
