Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
95
HCD-C5
C231 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C241 1-127-820-11 CERAMIC 4.7uF 16V
C243 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C244 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C294 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C501 1-126-916-11 ELECT 1000uF 20.00% 6.3V
C502 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C503 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C504 1-126-160-11 ELECT 1uF 20% 50V
C505 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C506 1-164-159-11 CERAMIC 0.1uF 50V
C507 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C509 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C510 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C535 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C536 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C911 1-164-159-11 CERAMIC 0.1uF 50V
C941 1-126-964-11 ELECT 10uF 20.00% 50V
C942 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C943 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
∗ CN201 1-784-738-11 CONNECTOR, FFC 16P
CN202 1-784-780-11 CONNECTOR, FFC 19P
CN203 1-764-698-11 SOCKET, CONNECTOR (NON ZIF)19P
CN204 1-568-844-11 CONNECTOR, FFC 29P
CN205 1-766-956-11 CONNECTOR, BOARD TO BOARD 15P
∗ CN206 1-774-813-11 CONNECTOR, BOARD TO BOARD 7P
CN207 1-774-136-11 CONNECTOR, ROUND TYPE 6P
CN208 1-774-281-11 CONNECTOR (DIN) 8P
CN209 1-774-281-11 CONNECTOR (DIN) 8P
CN212 1-506-469-11 PIN, CONNECTOR 4P
< DIODE >
D214 8-719-988-61 DIODE 1SS355TE-17
D221 8-719-988-61 DIODE 1SS355TE-17
D222 8-719-988-61 DIODE 1SS355TE-17
D232 8-719-988-61 DIODE 1SS355TE-17
D513 8-719-988-61 DIODE 1SS355TE-17
D910 8-719-921-40 DIODE MTZJ-T-77-4.7B
D923 8-719-991-33 DIODE 1SS133T-77
D924 8-719-991-33 DIODE 1SS133T-77
D925 8-719-988-61 DIODE 1SS355TE-17
D926 8-719-988-61 DIODE 1SS355TE-17
D927 8-719-988-61 DIODE 1SS355TE-17
D941 8-719-988-61 DIODE 1SS355TE-17
D942 8-719-988-61 DIODE 1SS355TE-17
D943 8-719-988-61 DIODE 1SS355TE-17
< TERMINAL >
EPT101 1-537-770-21 TERMINAL BOARD, GROUND
< CONDUCTOR / COIL >
FB201 1-216-864-11 METAL CHIP 0 5% 1/16W
FB202 1-216-864-11 METAL CHIP 0 5% 1/16W
FB205 1-216-864-11 METAL CHIP 0 5% 1/16W
FB211 1-412-473-21 INDUCTOR 0uH
FB212 1-216-864-11 METAL CHIP 0 5% 1/16W
FB213 1-216-864-11 METAL CHIP 0 5% 1/16W
FB214 1-216-864-11 METAL CHIP 0 5% 1/16W
FB222 1-216-864-11 METAL CHIP 0 5% 1/16W
FB537 1-414-813-21 EMI FERRITE (SMD)
< IC >
IC212 8-759-683-99 IC BA8274F-E2
IC221 8-749-017-36 IC TORX-179
IC222 8-759-548-57 IC SN74LV00ANSR
IC501 6-800-396-01 IC uPD703032AYGF-M01-3BA
IC941 8-759-637-58 IC PST592C-T
< CONDUCTOR >
JR200 1-216-864-11 METAL CHIP 0 5% 1/16W
JR203 1-216-864-11 METAL CHIP 0 5% 1/16W
JR205 1-216-864-11 METAL CHIP 0 5% 1/16W
JR208 1-216-864-11 METAL CHIP 0 5% 1/16W
JR209 1-216-864-11 METAL CHIP 0 5% 1/16W
JR210 1-216-864-11 METAL CHIP 0 5% 1/16W
JR212 1-216-864-11 METAL CHIP 0 5% 1/16W
JR213 1-216-864-11 METAL CHIP 0 5% 1/16W
JR214 1-216-864-11 METAL CHIP 0 5% 1/16W
JR215 1-216-864-11 METAL CHIP 0 5% 1/16W
JR216 1-216-864-11 METAL CHIP 0 5% 1/16W
JR217 1-216-864-11 METAL CHIP 0 5% 1/16W
JR219 1-216-864-11 METAL CHIP 0 5% 1/16W
JR225 1-216-864-11 METAL CHIP 0 5% 1/16W
JR226 1-216-864-11 METAL CHIP 0 5% 1/16W
JR227 1-216-864-11 METAL CHIP 0 5% 1/16W
< CONDUCTOR >
L551 1-216-864-11 METAL CHIP 0 5% 1/16W
L552 1-216-864-11 METAL CHIP 0 5% 1/16W
< TRANSISTOR >
Q202 8-729-424-08 TRANSISTOR UN2111-TX
Q211 8-729-025-28 TRANSISTOR 2SK1828TE85L
Q212 8-729-025-28 TRANSISTOR 2SK1828TE85L
Q221 8-729-120-28 TRANSISTOR 2SC1623-T1-L5L6
Q222 8-729-120-28 TRANSISTOR 2SC1623-T1-L5L6
Q223 8-729-120-28 TRANSISTOR 2SC1623-T1-L5L6
Q224 8-729-120-28 TRANSISTOR 2SC1623-T1-L5L6
Q232 8-729-120-28 TRANSISTOR 2SC1623-T1-L5L6
Q911 8-729-421-22 TRANSISTOR UN2211-TX
Q912 8-729-040-20 TRANSISTOR RT1P137L-TP
Q941 8-729-120-28 TRANSISTOR 2SC1623-T1-L5L6
< RESISTOR >
R212 1-249-429-11 CARBON 10K 5% 1/4W
R213 1-216-833-11 METAL CHIP 10K 5% 1/16W
R214 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R215 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R217 1-216-833-11 METAL CHIP 10K 5% 1/16W
R218 1-216-845-11 METAL CHIP 100K 5% 1/16W
R219 1-249-417-11 CARBON 1K 5% 1/4W
R221 1-249-413-11 CARBON 470 5% 1/4W
R222 1-216-809-11 METAL CHIP 100 5% 1/16W
R224 1-216-853-11 METAL CHIP 470K 5% 1/16W
UCOM
