Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
47
HCD-CP300
H/PDISK SENSOR DRIVERCONTROL
R826 1-216-819-11 METAL CHIP 680 5% 1/16W
R827 1-216-821-11 METAL CHIP 1K 5% 1/16W
R828 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
R829 1-216-824-11 METAL CHIP 1.8K 5% 1/16W
R830 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R835 1-216-845-11 METAL CHIP 100K 5% 1/16W
R836 1-216-845-11 METAL CHIP 100K 5% 1/16W
R837 1-216-845-11 METAL CHIP 100K 5% 1/16W
R838 1-216-845-11 METAL CHIP 100K 5% 1/16W
R839 1-216-845-11 METAL CHIP 100K 5% 1/16W
R840 1-216-845-11 METAL CHIP 100K 5% 1/16W
R841 1-216-845-11 METAL CHIP 100K 5% 1/16W
R842 1-216-845-11 METAL CHIP 100K 5% 1/16W
R851 1-249-411-11 CARBON 330 5% 1/4W
R852 1-216-041-00 METAL CHIP 470 5% 1/10W
R855 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R856 1-216-817-11 METAL CHIP 470 5% 1/16W
R859 1-216-818-11 METAL CHIP 560 5% 1/16W
R885 1-249-411-11 CARBON 330 5% 1/4W
R899 1-216-818-11 METAL CHIP 560 5% 1/16W
< VARIABLE RESISTOR >
RV801 1-473-392-11 ENCODER, ROTARY(VOLUME)
RV802 1-418-859-11 ENCODER, ROTARY(TREBLE)
RV803 1-418-859-11 ENCODER, ROTARY(BASS)
RV804 1-476-704-11 ENCODER, ROTARY(FUNCTION)
< SWITCH >
S801 1-786-220-11 KEY BOARD SWITCH(CD u)
S802 1-786-220-11 KEY BOARD SWITCH(CD ./m)
S803 1-786-220-11 KEY BOARD SWITCH(PLAY MODE)
S804 1-786-220-11 KEY BOARD SWITCH(REPEAT)
S811 1-786-220-11 KEY BOARD SWITCH(TAPE A M)
S812 1-786-220-11 KEY BOARD SWITCH(TAPE A m)
S813 1-786-220-11 KEY BOARD SWITCH(TAPE A B)
S814 1-786-220-11 KEY BOARD SWITCH(TAPE A x)
S815 1-786-220-11 KEY BOARD SWITCH(DSG)
S817 1-786-220-11 KEY BOARD SWITCH(CD SYNC)
S818 1-786-220-11 KEY BOARD SWITCH(TAPE REC z)
S819 1-786-220-11 KEY BOARD SWITCH(TAPE B X)
S820 1-786-220-11 KEY BOARD SWITCH(?/1 POWER)
S821 1-786-220-11 KEY BOARD SWITCH(CD >/M)
S822 1-786-220-11 KEY BOARD SWITCH(CD x)
S823 1-786-220-11 KEY BOARD SWITCH(TUNING MODE)
S824 1-786-220-11 KEY BOARD SWITCH(TUNING +)
S825 1-786-220-11 KEY BOARD SWITCH(TUNING –)
S826 1-786-220-11 KEY BOARD SWITCH(TUNER BAND)
S827 1-786-220-11 KEY BOARD SWITCH(TAPE B m)
S828 1-786-220-11 KEY BOARD SWITCH(TAPE B M)
S829 1-786-220-11 KEY BOARD SWITCH(TAPE B x)
S830 1-786-220-11 KEY BOARD SWITCH(TAPE B Y)
************************************************************
1-678-463-11 DISK SENSOR BOARD
*****************
< IC >
IC751 8-749-924-30 PHOTO REFLECTOR GP2S28
< RESISTOR >
R751 1-249-407-11 CARBON 150 5% 1/4W F
************************************************************
1-678-460-11 DRIVER BOARD
************
< CAPACITOR >
C701 1-124-261-00 ELECT 10uF 20% 50V
C705 1-124-261-00 ELECT 10uF 20% 50V
C706 1-164-159-11 CERAMIC 0.1uF 50V
C707 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN701 1-785-324-11 PIN, CONNECTOR (STRAIGHT) 12P
CN702 1-785-328-11 PIN, CONNECTOR (LIGHT ANGRE)2P
CN703 1-785-331-11 PIN, CONNECTOR (LIGHT ANGLE)5P
CN704 1-785-329-11 PIN, CONNECTOR (LIGHT ANGLE)3P
CN705 1-785-329-21 PIN, CONNECTOR (LIGHT ANGLE)3P
< IC >
IC701 8-759-598-69 IC BA6956AN
< TRANSISTOR >
Q701 8-729-029-66 TRANSISTOR RT1N141S-TP
< RESISTOR >
R701 1-249-429-11 CARBON 10K 5% 1/4W
R702 1-249-401-11 CARBON 47 5% 1/4W F
R705 1-249-435-11 CARBON 33K 5% 1/4W
R706 1-249-417-11 CARBON 1K 5% 1/4W F
R707 1-249-429-11 CARBON 10K 5% 1/4W
***********************************************************
1-681-012-11 H/P BOARD
*********
< CAPACITOR >
C135 1-163-009-91 CERAMIC CHIP 0.001uF 10.00% 50V
C235 1-163-009-91 CERAMIC CHIP 0.001uF 10.00% 50V
< JACK >
J301 1-794-453-11 JACK(PHONES)
**********************************************************
1-678-462-11 IN OUT SW BOARD
***************
< SWITCH >
S741 1-771-821-11 SWITCH, PUSH (1 KEY)(IN)
S742 1-771-821-11 SWITCH, PUSH (1 KEY)(OUT)
**********************************************************
1-681-013-11 JACK BOARD
***********
< CONNECTOR >
CN305 1-506-468-11 PIN, CONNECTOR 3P
JACKIN OUT SW
