Sony HCD-CP300 - Page 48

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
48
HCD-CP300
MAIN
LCD LED
< JACK >
PJ301 1-815-577-11 PIN JACK (PHONO) 2P(AUDIO IN MD)
< RESISTOR >
R116 1-216-834-11 METAL CHIP 12K 5% 1/16W
R117 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R216 1-216-834-11 METAL CHIP 12K 5% 1/16W
R217 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
************************************************************
1-681-011-11 LCD BOARD
**********
< CONNECTOR >
CN302 1-569-928-11 SOCKET, CONNECTOR 11P
CN304 1-569-937-11 SOCKET, CONNECTOR 21P
< DIODE >
D801 8-719-084-70 DIODE SY3318-VS1-T(LCD BACK LIGT)
D802 8-719-084-70 DIODE SY3318-VS1-T(LCD BACK LIGT)
D803 8-719-084-70 DIODE SY3318-VS1-T(LCD BACK LIGT)
D804 8-719-084-70 DIODE SY3318-VS1-T(LCD BACK LIGT)
************************************************************
1-681-016-11 LED BOARD
**********
< DIODE >
D811 8-719-056-12 DIODE SML79420C-TP15(CD3)
D812 8-719-056-12 DIODE SML79420C-TP15(CD2)
D813 8-719-056-12 DIODE SML79420C-TP15(CD1)
< TRANSISTOR >
Q809 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q810 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q811 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q812 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q813 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q814 8-729-900-53 TRANSISTOR DTC114EKA-T146
< RESISTOR >
R806 1-216-819-11 METAL CHIP 680 5% 1/16W
R807 1-216-821-11 METAL CHIP 1K 5% 1/16W
R808 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
R809 1-216-824-11 METAL CHIP 1.8K 5% 1/16W
R810 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R845 1-216-819-11 METAL CHIP 680 5% 1/16W
R846 1-216-819-11 METAL CHIP 680 5% 1/16W
R847 1-216-819-11 METAL CHIP 680 5% 1/16W
R848 1-216-819-11 METAL CHIP 680 5% 1/16W
R849 1-216-819-11 METAL CHIP 680 5% 1/16W
R850 1-216-819-11 METAL CHIP 680 5% 1/16W
< SWITCH >
S805 1-786-220-11 KEY BOARD SWITCH(CD3Z)
S806 1-786-220-11 KEY BOARD SWITCH(CD3)
S807 1-786-220-11 KEY BOARD SWITCH(CD2Z)
S808 1-786-220-11 KEY BOARD SWITCH(CD2)
S809 1-786-220-11 KEY BOARD SWITCH(CD1Z)
S810 1-786-220-11 KEY BOARD SWITCH(CD1)
************************************************************
A-2007-970-A MAIN BOARD, COMPLETE (AEP,UK)
*********************
A-4726-203-A MAIN BOARD, COMPLETE (CND,MX)
*********************
A-4726-205-A MAIN BOARD, COMPLETE (EA,SP,MY)
*********************
4-217-354-11 BUSHING, INSULATING
4-230-078-01 SCREW, +BV TAPPING
7-685-546-14 SCREW +BTP 3X8 TYPE2 N-S
7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
< CAPACITOR >
C101 1-126-963-11 ELECT 4.7uF 20.00% 50V
C102 1-126-963-11 ELECT 4.7uF 20.00% 50V
C103 1-126-963-11 ELECT 4.7uF 20.00% 50V
(CND,EA,MX,SP,MY)
C103 1-124-259-11 ELECT 4.7uF 20.00% 16V
(AEP,UK)
C104 1-126-963-11 ELECT 4.7uF 20.00% 50V
C105 1-126-963-11 ELECT 4.7uF 20.00% 50V
C106 1-126-963-11 ELECT 4.7uF 20.00% 50V
C107 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(CND,EA,MX,SP,MY)
C107 1-164-245-11 CERAMIC CHIP 0.015uF 10.00% 25V
(AEP,UK)
C108 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C110 1-126-963-11 ELECT 4.7uF 20.00% 50V
C111 1-164-245-11 CERAMIC CHIP 0.015uF 10.00% 25V
C112 1-164-245-11 CERAMIC CHIP 0.015uF 10.00% 25V
C113 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C114 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C115 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C118 1-126-963-11 ELECT 4.7uF 20.00% 50V
(CND,EA,MX,SP,MY)
C118 1-124-259-11 ELECT 4.7uF 20.00% 16V
(AEP,UK)
C119 1-126-963-11 ELECT 4.7uF 20.00% 50V
C121 1-126-963-11 ELECT 4.7uF 20.00% 50V
C122 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C126 1-126-965-11 ELECT 22uF 20.00% 50V
C127 1-130-495-00 MYLAR 0.1uF 5% 50V
C132 1-104-665-11 ELECT 100uF 20.00% 16V
C133 1-130-495-00 MYLAR 0.1uF 5% 50V
C150 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(CND,EA,MX,SP,MY)
C150 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(AEP,UK)
C151 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(CND,EA,MX,SP,MY)
C151 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(AEP,UK)
C201 1-126-964-11 ELECT 10uF 20.00% 50V
(CND,EA,MX,SP,MY)
C201 1-126-963-11 ELECT 4.7uF 20.00% 50V
(AEP,UK)
C202 1-126-963-11 ELECT 4.7uF 20.00% 50V
(CND,EA,MX,SP,MY)
JACK
