Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
50
HCD-CP300
MAIN
C823 1-164-185-11 CERAMIC CHIP 13PF 5.00% 50V
(AEP,UK)
C824 1-164-739-11 CERAMIC CHIP 560PF 5.00% 50V
(AEP,UK)
C888 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN302 1-569-928-11 SOCKET, CONNECTOR 11P
CN303 1-569-928-11 SOCKET, CONNECTOR 11P
CN307 1-506-469-11 PIN, CONNECTOR 4P
* CN313 1-568-939-11 PIN, CONNECTOR 12P
CN801 1-793-600-11 CONNECTOR, FFC/FPC (ZIF) 17P
CN802 1-793-599-11 CONNECTOR, FFC/FPC (ZIF) 17P
CN803 1-793-602-11 CONNECTOR, FFC/FPC (ZIF) 21P
CN804 1-793-601-11 CONNECTOR, FFC/FPC (ZIF) 21P
CN805 1-568-834-11 SOCKET, CONNECTOR 15P
* CN806 1-569-934-11 SOCKET, CONNECTOR 17P
* CN809 1-506-984-11 PIN, CONNECTOR (PC BOARD) 2P
* CN810 1-506-984-11 PIN, CONNECTOR (PC BOARD) 2P
< DIODE >
D309 8-719-110-08 DIODE MTZJ-T-77-8.2B (CND,EA,MX,SP,MY)
D309 8-719-109-97 DIODE MTZJ-T-77-6.8C (AEP,UK)
D314 8-719-109-89 DIODE MTZJ-T-77-5.6B
D319 8-719-921-63 DIODE MTZJ-T-77-7.5B
D321 8-719-110-31 DIODE MTZJ-T-77-12B
D323 8-719-110-14 DIODE MTZJ-T-77-9.1C
D350 8-719-109-89 DIODE MTZJ-T-77-5.6B
D805 8-719-982-11 DIODE MTZJ-T-77-4.3B (AEP,UK)
D806 8-719-991-33 DIODE 1SS133T-77
D807 8-719-991-33 DIODE 1SS133T-77
D808 8-719-991-33 DIODE 1SS133T-77
D809 8-719-200-82 DIODE 11ES2-TA1B
D810 8-719-200-82 DIODE 11ES2-TA1B
D825 8-719-991-33 DIODE 1SS133T-77
D827 8-719-991-33 DIODE 1SS133T-77
<TERMINAL>
GP301 1-537-770-11 TERMINAL BOARD, GROUND
GP302 1-537-770-11 TERMINAL BOARD, GROUND
< IC >
IC101 8-759-584-38 IC TDA7296
IC201 8-759-584-38 IC TDA7296
IC301 6-700-261-01 IC BD3861FS
IC303 8-759-359-49 IC NJM3414AV(TE2)
IC304 8-759-646-54 IC KIA7808API
IC305 8-759-584-40 IC KA7908
IC308 8-749-016-00 IC HVE0024
IC311 8-759-646-54 IC KIA7808API
IC601 6-800-361-01 IC M30622MGA-A67FP
IC602 8-759-153-90 IC uPD7225GB-3B7
IC603 8-759-557-36 IC BU1924F-E2 (AEP,UK)
IC604 8-759-637-58 IC PST592C-T
IC606 6-700-176-01 IC MC74VHCT04ADTR2
< JUMPER RESISTOR >
JR304 1-216-295-00 SHORT 0 (AEP,UK)
JR307 1-216-295-00 SHORT 0 (AEP,UK)
JR308 1-216-295-00 SHORT 0 (AEP,UK)
< COIL >
L101 1-420-872-00 COIL, AIR-CORE
L102 1-410-750-11 MICCRO INDUCTOR (AEP,UK)
L201 1-420-872-00 COIL, AIR-CORE
< LIQUID CRYSTAL DISPLAY >
LCD801 1-803-542-11 DISPLAY PANEL, LIQUID CRYSTAL
< TRANSISTOR >
Q110 8-729-920-31 TRANSISTOR DTC343TK-T-146
Q150 8-729-920-31 TRANSISTOR DTC343TK-T-146
Q210 8-729-920-31 TRANSISTOR DTC343TK-T-146
Q250 8-729-920-31 TRANSISTOR DTC343TK-T-146
Q303 8-729-038-55 TRANSISTOR KRA103S
Q304 8-729-038-67 TRANSISTOR KRC102S
Q305 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q310 8-729-019-00 TRANSISTOR KTC2026
Q311 8-759-068-54 TRANSISTOR KRA102S
Q312 8-729-038-68 TRANSISTOR KRC103S
Q314 8-729-028-54 TRANSISTOR KTC3205-Y-AT
Q315 8-759-068-54 TRANSISTOR KRA102S
Q316 8-729-038-68 TRANSISTOR KRC103S
Q330 8-729-038-68 TRANSISTOR KRC103S
Q350 8-729-019-00 TRANSISTOR KTC2026
Q360 8-729-028-54 TRANSISTOR KTC3205-Y-AT
Q361 8-729-202-56 TRANSISTOR 2SA950-Y-TPE2
Q362 8-729-038-68 TRANSISTOR KRC103S
Q364 8-729-202-56 TRANSISTOR 2SA950-Y-TPE2
Q365 8-729-038-68 TRANSISTOR KRC103S
Q366 8-729-202-56 TRANSISTOR 2SA950-Y-TPE2
Q367 8-729-038-68 TRANSISTOR KRC103S
Q801 8-729-120-28 TRANSISTOR 2SC2412K-T-146-R (AEP,UK)
Q802 8-729-037-02 TRANSISTOR KTA1266Y-AT
Q803 8-729-038-67 TRANSISTOR KRC102S
Q804 8-729-038-67 TRANSISTOR KRC102S
Q805 8-729-037-02 TRANSISTOR KTA1266Y-AT
Q806 8-729-038-67 TRANSISTOR KRC102S
Q808 8-729-120-28 TRANSISTOR 2SC2412K-T-146-R
Q830 8-729-037-02 TRANSISTOR KTA1266Y-AT
Q831 8-729-038-67 TRANSISTOR KRC102S
< RESISTOR >
R101 1-216-821-11 METAL CHIP 1K 5% 1/16W
R102 1-216-821-11 METAL CHIP 1K 5% 1/16W
R104 1-216-833-11 METAL CHIP 10K 5% 1/16W
R105 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R106 1-216-833-11 METAL CHIP 10K 5% 1/16W
R107 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
R108 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R109 1-216-821-11 METAL CHIP 1K 5% 1/16W
R112 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R119 1-216-841-11 METAL CHIP 47K 5% 1/16W
R121 1-216-808-11 METAL CHIP 82 5% 1/16W
R123 1-216-817-11 METAL CHIP 470 5% 1/16W
To Next Page
