55
HCD-CPX22/NXM3
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
BD
< IC >
IC101 8-752-425-12 IC CXD3059AR
IC251 6-705-808-01 IC BA5947FM
IC301 6-705-365-01 IC TC94A34FG-002
IC303 6-705-807-01 IC BH15FB1WG
< TRANSISTOR >
Q10 6-550-363-01 TRANSISTOR 2SB1690KT146
< RESISTOR >
R10 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R11 1-216-864-11 SHORT CHIP 0
R12 1-216-845-11 METAL CHIP 100K 5% 1/10W
R13 1-218-446-11 METAL CHIP 1 5% 1/10W
R111 1-216-821-11 METAL CHIP 1K 5% 1/10W
R112 1-216-835-11 METAL CHIP 15K 5% 1/10W
R113 1-216-821-11 METAL CHIP 1K 5% 1/10W
R114 1-216-835-11 METAL CHIP 15K 5% 1/10W
R121 1-216-835-11 METAL CHIP 15K 5% 1/10W
R131 1-216-857-11 METAL CHIP 1M 5% 1/10W
R132 1-216-833-11 METAL CHIP 10K 5% 1/10W
R133 1-216-848-11 METAL CHIP 180K 5% 1/10W
R141 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R142 1-216-821-11 METAL CHIP 1K 5% 1/10W
R143 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R151 1-216-864-11 SHORT CHIP 0
R161 1-216-809-11 METAL CHIP 100 5% 1/10W
R162 1-216-841-11 METAL CHIP 47K 5% 1/10W
R163 1-216-809-11 METAL CHIP 100 5% 1/10W
R165 1-216-864-11 SHORT CHIP 0
R171 1-216-817-11 METAL CHIP 470 5% 1/10W
R172 1-216-857-11 METAL CHIP 1M 5% 1/10W
R173 1-216-295-91 SHORT CHIP 0
R181 1-216-809-11 METAL CHIP 100 5% 1/10W
R182 1-216-809-11 METAL CHIP 100 5% 1/10W
R191 1-216-864-11 SHORT CHIP 0
R201 1-500-445-21 FERRITE, EMI (SMD) (2012)
R203 1-216-864-11 SHORT CHIP 0
R204 1-500-445-21 FERRITE, EMI (SMD) (2012)
R205 1-216-864-11 SHORT CHIP 0
R251 1-216-833-11 METAL CHIP 10K 5% 1/10W
R252 1-216-837-11 METAL CHIP 22K 5% 1/10W
R253 1-216-833-11 METAL CHIP 10K 5% 1/10W
R301 1-216-845-11 METAL CHIP 100K 5% 1/10W
R302 1-216-833-11 METAL CHIP 10K 5% 1/10W
R303 1-216-845-11 METAL CHIP 100K 5% 1/10W
R305 1-216-845-11 METAL CHIP 100K 5% 1/10W
R306 1-216-864-11 SHORT CHIP 0
R307 1-216-833-11 METAL CHIP 10K 5% 1/10W
R313 1-216-813-11 METAL CHIP 220 5% 1/10W
R351 1-216-809-11 METAL CHIP 100 5% 1/10W
R352 1-216-809-11 METAL CHIP 100 5% 1/10W
R353 1-216-809-11 METAL CHIP 100 5% 1/10W
R354 1-216-809-11 METAL CHIP 100 5% 1/10W
R401 1-216-809-11 METAL CHIP 100 5% 1/10W
R402 1-216-809-11 METAL CHIP 100 5% 1/10W
R403 1-216-809-11 METAL CHIP 100 5% 1/10W
R404 1-216-809-11 METAL CHIP 100 5% 1/10W
R405 1-216-809-11 METAL CHIP 100 5% 1/10W
R406 1-216-809-11 METAL CHIP 100 5% 1/10W
R407 1-216-809-11 METAL CHIP 100 5% 1/10W
R408 1-216-809-11 METAL CHIP 100 5% 1/10W
R409 1-216-809-11 METAL CHIP 100 5% 1/10W
R410 1-216-809-11 METAL CHIP 100 5% 1/10W
R411 1-216-809-11 METAL CHIP 100 5% 1/10W
R412 1-216-809-11 METAL CHIP 100 5% 1/10W
R419 1-216-809-11 METAL CHIP 100 5% 1/10W
< SWITCH >
S101 1-771-853-11 SWITCH, DETECTION (LIMIT)
< VIBRATOR >
X171 1-767-408-21 VIBRATOR, CRYSTAL (16.9MHz)
************************************************************
DISC SW BOARD
*************
< CAPACITOR >
C1009 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< DIODE >
D1001 8-719-058-64 DIODE SEL5823A-TP15 (DISC 1)
D1002 8-719-058-64 DIODE SEL5823A-TP15 (DISC 2)
D1003 8-719-058-64 DIODE SEL5823A-TP15 (DISC 3)
D1004 8-719-058-64 DIODE SEL5823A-TP15 (DISC 4)
D1005 8-719-058-64 DIODE SEL5823A-TP15 (DISC 5)
< TRANSISTOR >
Q1001 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q1002 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q1003 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q1004 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q1005 8-729-027-43 TRANSISTOR DTC114EKA-T146
< RESISTOR >
R1001 1-216-819-11 METAL CHIP 680 5% 1/10W
R1002 1-216-819-11 METAL CHIP 680 5% 1/10W
R1003 1-216-819-11 METAL CHIP 680 5% 1/10W
R1004 1-216-819-11 METAL CHIP 680 5% 1/10W
R1005 1-216-819-11 METAL CHIP 680 5% 1/10W
R1006 1-216-819-11 METAL CHIP 680 5% 1/10W
R1007 1-216-819-11 METAL CHIP 680 5% 1/10W
R1008 1-216-819-11 METAL CHIP 680 5% 1/10W
R1009 1-216-819-11 METAL CHIP 680 5% 1/10W
R1010 1-216-819-11 METAL CHIP 680 5% 1/10W
R1011 1-216-813-11 METAL CHIP 220 5% 1/10W
R1012 1-216-815-11 METAL CHIP 330 5% 1/10W
R1013 1-216-817-11 METAL CHIP 470 5% 1/10W
R1014 1-216-819-11 METAL CHIP 680 5% 1/10W
< SWITCH >
S1001 1-762-875-21 SWITCH, KEYBOARD (DISC 1)
S1002 1-762-875-21 SWITCH, KEYBOARD (DISC 2)
S1003 1-762-875-21 SWITCH, KEYBOARD (DISC 3)
S1004 1-762-875-21 SWITCH, KEYBOARD (DISC 4)
S1005 1-762-875-21 SWITCH, KEYBOARD (DISC 5)
************************************************************
DISC SW
