61
HCD-CPX22/NXM3
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
MAIN
R451 1-216-809-11 METAL CHIP 100 5% 1/10W
R452 1-216-809-11 METAL CHIP 100 5% 1/10W
R453 1-216-809-11 METAL CHIP 100 5% 1/10W
R454 1-216-809-11 METAL CHIP 100 5% 1/10W
R455 1-216-809-11 METAL CHIP 100 5% 1/10W
R456 1-216-809-11 METAL CHIP 100 5% 1/10W
R457 1-216-809-11 METAL CHIP 100 5% 1/10W
R458 1-216-809-11 METAL CHIP 100 5% 1/10W
R459 1-216-809-11 METAL CHIP 100 5% 1/10W
R460 1-216-809-11 METAL CHIP 100 5% 1/10W
R461 1-216-809-11 METAL CHIP 100 5% 1/10W
R465 1-216-809-11 METAL CHIP 100 5% 1/10W
R466 1-216-833-11 METAL CHIP 10K 5% 1/10W
R467 1-216-833-11 METAL CHIP 10K 5% 1/10W
R468 1-216-833-11 METAL CHIP 10K 5% 1/10W
R469 1-216-833-11 METAL CHIP 10K 5% 1/10W
R470 1-216-809-11 METAL CHIP 100 5% 1/10W
R471 1-216-809-11 METAL CHIP 100 5% 1/10W
R472 1-216-809-11 METAL CHIP 100 5% 1/10W
R473 1-216-809-11 METAL CHIP 100 5% 1/10W
R474 1-216-809-11 METAL CHIP 100 5% 1/10W
R476 1-216-809-11 METAL CHIP 100 5% 1/10W
R477 1-216-809-11 METAL CHIP 100 5% 1/10W
R478 1-216-809-11 METAL CHIP 100 5% 1/10W
R479 1-216-809-11 METAL CHIP 100 5% 1/10W
R482 1-216-809-11 METAL CHIP 100 5% 1/10W
R483 1-216-809-11 METAL CHIP 100 5% 1/10W
R484 1-216-809-11 METAL CHIP 100 5% 1/10W
R485 1-216-809-11 METAL CHIP 100 5% 1/10W
R486 1-216-809-11 METAL CHIP 100 5% 1/10W
R489 1-216-809-11 METAL CHIP 100 5% 1/10W
R490 1-216-809-11 METAL CHIP 100 5% 1/10W
R492 1-216-811-11 METAL CHIP 150 5% 1/10W
(RU)
R492 1-216-821-11 METAL CHIP 1K 5% 1/10W
(E51)
R492 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(US)
R492 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(E3, EA)
R492 1-216-864-11 SHORT CHIP 0 (AEP, UK)
R493 1-216-809-11 METAL CHIP 100 5% 1/10W
R494 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R495 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R496 1-216-821-11 METAL CHIP 1K 5% 1/10W
(EA)
R496 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(EXCEPT E3, EA)
R496 1-216-864-11 SHORT CHIP 0 (E3)
R497 1-216-833-11 METAL CHIP 10K 5% 1/10W
R498 1-216-797-11 METAL CHIP 10 5% 1/10W
R499 1-216-797-11 METAL CHIP 10 5% 1/10W
R914 1-216-821-11 METAL CHIP 1K 5% 1/10W
R915 1-216-821-11 METAL CHIP 1K 5% 1/10W
R952 1-216-809-11 METAL CHIP 100 5% 1/10W
R953 1-216-809-11 METAL CHIP 100 5% 1/10W
R954 1-216-809-11 METAL CHIP 100 5% 1/10W
R955 1-216-809-11 METAL CHIP 100 5% 1/10W
R956 1-216-809-11 METAL CHIP 100 5% 1/10W
R957 1-216-809-11 METAL CHIP 100 5% 1/10W
R958 1-216-809-11 METAL CHIP 100 5% 1/10W
R959 1-216-809-11 METAL CHIP 100 5% 1/10W
R968 1-216-833-11 METAL CHIP 10K 5% 1/10W
R970 1-216-833-11 METAL CHIP 10K 5% 1/10W
R984 1-216-833-11 METAL CHIP 10K 5% 1/10W
< TRANSFORMER >
T301 1-433-372-11 TRANSFORMER, BIAS OSCILLATION
< VIBRATOR >
X401 1-567-098-41 VIBRATOR, CRYSTAL (32.768kHz)
X402 1-795-482-11 VIBRATOR, CERAMIC (16MHz)
************************************************************
MOTOR BOARD
***********
< SWITCH >
S761 1-786-704-11 SWITCH, LEVER (SUB TRAY OUT)
************************************************************
A-4750-849-A PANEL BOARD, COMPLETE
*******************
< CAPACITOR >
C1006 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1021 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C1025 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C1026 1-126-964-11 ELECT 10uF 20% 50V
C1028 1-126-964-11 ELECT 10uF 20% 50V
C1029 1-131-992-91 CERAMIC CHIP 100000PF 35V
C1048 1-131-992-91 CERAMIC CHIP 100000PF 35V
C1050 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1051 1-126-969-11 ELECT 220uF 20% 50V
C1052 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1053 1-126-965-91 ELECT 22uF 20% 50V
C1054 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
< CONNECTOR >
CN1021 1-784-774-11 CONNECTOR, FFC 13P
< DIODE >
D1021 8-719-058-03 DIODE SEL5423E-TP15 (n N)
D1022 8-719-059-18 DIODE RD6.2FM-T1
D1023 8-719-988-61 DIODE 1SS355TE-17
D1024 8-719-988-61 DIODE 1SS355TE-17
D1025 8-719-988-61 DIODE 1SS355TE-17
D1026 8-719-988-61 DIODE 1SS355TE-17
< FILTER >
FL1020 1-518-979-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC1020 6-705-745-01 IC M66005-0131AHPRB0T
MOTOR PANEL
