3-8. IR BOARD, MASTER VOL BOARD
3-7. USB BOARD
two screws
(+BVTP 2.6 (3CR))
two wire stoppers
CN903 (5P)
USB board
two screws
(+BVTP 2.6 (3CR))
three screws
(+BVTP 2.6 (3CR))
two screws
(+BVTP 2.6 (3CR))
two screws
(+BVTP 2.6 (3CR))
knob (rubber)
two wire stoppers
IR board
MASTER VOL board
CN1003 (12P)
