Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-DJ2i
80
A-1536-401-A MAIN DIGITAL BOARD, COMPLETE (MX)
A-1536-423-A MAIN DIGITAL BOARD, COMPLETE (AEP)
A-1536-424-A MAIN DIGITAL BOARD, COMPLETE (UK)
A-1536-425-A MAIN DIGITAL BOARD, COMPLETE (US,CND)
A-1536-426-A MAIN DIGITAL BOARD, COMPLETE (AUS)
A-1538-968-A MAIN DIGITAL BOARD, COMPLETE (E3)
A-1701-219-A MAIN DIGITAL BOARD, COMPLETE (EA)
****************************
< CAPACITOR >
C110 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C111 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C112 1-100-756-11 CERAMIC CHIP 0.047uF 50V
C114 1-100-597-11 CERAMIC CHIP 0.1uF 10% 25V
C116 1-104-656-11 ELECT 2200uF 20% 6.3V
C141 1-100-597-11 CERAMIC CHIP 0.1uF 10% 25V
C162 1-100-597-11 CERAMIC CHIP 0.1uF 10% 25V
C195 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C198 1-104-658-11 ELECT 100uF 20% 10V
C262 1-104-658-11 ELECT 100uF 20% 10V
C298 1-100-597-11 CERAMIC CHIP 0.1uF 10% 25V
C328 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C330 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C331 1-126-964-11 ELECT 10uF 20% 50V
C332 1-126-964-11 ELECT 10uF 20% 50V
C333 1-128-934-11 CERAMIC CHIP 0.33uF 20% 10V
C334 1-100-597-11 CERAMIC CHIP 0.1uF 10% 25V
C335 1-100-597-11 CERAMIC CHIP 0.1uF 10% 25V
C340 1-126-964-11 ELECT 10uF 20% 50V
C341 1-126-916-11 ELECT 1000uF 20% 6.3V
C342 1-126-960-11 ELECT 1uF 20% 50V
C343 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C344 1-126-933-11 ELECT 100uF 20% 16V
C345 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C351 1-126-964-11 ELECT 10uF 20% 50V
C364 1-100-597-11 CERAMIC CHIP 0.1uF 10% 25V
C365 1-126-964-11 ELECT 10uF 20% 50V
C367 1-100-597-11 CERAMIC CHIP 0.1uF 10% 25V
C368 1-126-926-11 ELECT 1000uF 20% 10V
C382 1-126-964-11 ELECT 10uF 20% 50V
C383 1-100-597-11 CERAMIC CHIP 0.1uF 10% 25V
C390 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C391 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C392 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C396 1-100-597-11 CERAMIC CHIP 0.1uF 10% 25V
C1401 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C1402 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C1403 1-104-658-11 ELECT 100uF 20% 10V
C1420 1-100-597-11 CERAMIC CHIP 0.1uF 10% 25V
C1421 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C1422 1-124-257-00 ELECT 2.2uF 20% 50V
C1425 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C1426 1-126-961-11 ELECT 2.2uF 20% 50V
C1427 1-164-388-11 CERAMIC CHIP 270PF 5% 50V
C1428 1-126-961-11 ELECT 2.2uF 20% 50V
C1429 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C1430 1-124-261-00 ELECT 10uF 20% 50V
C1431 1-126-933-11 ELECT 100uF 20% 16V
C1432 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C1433 1-124-257-00 ELECT 2.2uF 20% 50V
C1434 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C1435 1-124-257-00 ELECT 2.2uF 20% 50V
C1437 1-124-257-00 ELECT 2.2uF 20% 50V
C1438 1-126-961-11 ELECT 2.2uF 20% 50V
C1439 1-126-963-11 ELECT 4.7uF 20% 50V
C1443 1-162-922-11 CERAMIC CHIP 39PF 5% 50V
C1445 1-126-947-11 ELECT 47uF 20% 35V
C1446 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1447 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1448 1-104-662-11 ELECT 22uF 20% 25V
C1449 1-126-963-11 ELECT 4.7uF 20% 50V
C1451 1-104-658-11 ELECT 100uF 20% 10V
C1452 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1455 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1456 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1461 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C1463 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1464 1-100-597-11 CERAMIC CHIP 0.1uF 10% 25V
< CONNECTOR >
CN100 1-784-788-11 CONNECTOR, FFC 27P
* CN101 1-564-512-11 PLUG, CONNECTOR 9P
CN102 1-779-285-11 CONNECTOR, FFC (LIF(NON-ZIF)) 17P
CN103 1-779-293-11 CONNECTOR, FFC (LIF(NON-ZIF)) 25P
CN104 1-779-277-11 CONNECTOR, FFC (LIF(NON-ZIF)) 9P
CN350 1-779-299-11 CONNECTOR, FFC (LIF(NON-ZIF)) 31P
CN351 1-779-289-11 CONNECTOR, FFC (LIF(NON-ZIF)) 21P
CN353 1-779-273-11 CONNECTOR, FFC (LIF(NON-ZIF)) 5P
CN1420 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P
CN1461 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P
CN1462 1-564-706-11 PIN, CONNECTOR (SMALL TYPE) 4P
< DIODE >
D167 6-501-817-01 DIODE MA2J1110GLS0
D190 6-501-817-01 DIODE MA2J1110GLS0
D330 6-501-722-01 DIODE MAZ8043GMLS0
D331 6-500-334-01 DIODE MC2836-T112-1
D332 6-501-817-01 DIODE MA2J1110GLS0
D334 8-719-063-79 DIODE 1N4002B
D335 8-719-063-79 DIODE 1N4002B
D337 6-501-579-01 DIODE MC2837
D338 6-501-817-01 DIODE MA2J1110GLS0
D350 6-501-817-01 DIODE MA2J1110GLS0
D351 6-501-734-01 DIODE MAZ8056GMLS0
D1403 6-501-817-01 DIODE MA2J1110GLS0
D1421 6-501-715-01 DIODE MAZ8036G0LS0
< GROUND TERMINAL >
ET100 1-537-771-21 TERMINAL BOARD, GROUND
< IC >
IC100 A-1563-980-A IC R5F3640MDFAR (for SERVICE)
IC300 6-707-095-01 IC BH2210FV-E2
IC340 8-759-598-69 IC BA6956AN
IC350 8-759-523-03 IC TC74HC4066AFT(EL)
IC351 8-759-523-03 IC TC74HC4066AFT(EL)
IC352 6-707-870-01 IC TC74VHC157FT(EKJ)
IC390 6-704-004-01 IC BR24L16F-WE2
IC1420 8-759-278-58 IC NJM4558V-TE2
IC1421 8-759-278-58 IC NJM4558V-TE2
IC1422 6-808-290-01 IC ML2252-259GAZ03A
< JACK >
J1400 1-817-629-11 JACK (LARGE TYPE)
(i)
MAIN DIGITAL
Ver. 1.3
To Next Page
