Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-DJ2i
8383
R1433 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1434 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1435 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1436 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1437 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1438 1-216-864-11 SHORT CHIP 0
R1439 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1441 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1442 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1443 1-216-864-11 SHORT CHIP 0
R1444 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1445 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1447 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1448 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1451 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1460 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1461 1-216-809-11 METAL CHIP 100 5% 1/10W
R1462 1-216-864-11 SHORT CHIP 0
R1463 1-216-841-11 METAL CHIP 47K 5% 1/10W
< VIBRATOR >
X110 1-814-067-11 OSCILLATOR, CRYSTAL (32.768kHz)
X113 1-795-058-21 VIBRATOR, CERAMIC (5MHz)
X1420 1-781-282-51 VIBRATOR, CERAMIC (4MHz)
*************************************************************
MASTER VOL BOARD
*****************
< CAPACITOR >
C1026 1-126-176-11 ELECT 220uF 20% 10V
< CONNECTOR >
* CN1003 1-564-728-11 PIN, CONNECTOR (SMALL TYPE) 12P
< DIODE >
D1031 6-502-401-11 LED 1L434FA22E0TDT01
(POWER ILLUMINATOR 1)
D1032 6-502-401-11 LED 1L434FA22E0TDT01
(POWER ILLUMINATOR 2)
D1033 6-502-401-11 LED 1L434FA22E0TDT01
(POWER ILLUMINATOR 3)
D1034 6-502-401-11 LED 1L434FA22E0TDT01
(POWER ILLUMINATOR 4)
D1035 6-502-401-11 LED 1L434FA22E0TDT01
(POWER ILLUMINATOR 5)
D1036 6-502-401-11 LED 1L434FA22E0TDT01
(POWER ILLUMINATOR 6)
D1037 6-502-401-11 LED 1L434FA22E0TDT01
(POWER ILLUMINATOR 7)
D1038 6-502-401-11 LED 1L434FA22E0TDT01
(POWER ILLUMINATOR 8)
< IC >
IC1010 6-704-046-01 IC BU2099FV
< JUMPER RESISTOR >
JR1003 1-216-864-11 SHORT CHIP
0
JR1004 1-216-296-11 SHORT CHIP 0
< RESISTOR >
R1018 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R1029 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1031 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1033 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1035 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1037 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1040 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1042 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1043 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1045 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1210 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1211 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1212 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1213 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1214 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1215 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1216 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1217 1-216-821-11 METAL CHIP 1K 5% 1/10W
< SWITCH >
S1046 1-418-725-51 ENCODER, ROTARY (12 TYPE) (VOLUME)
*************************************************************
MOTOR BOARD
************
< CONNECTOR >
CN001 1-779-542-21 CONNECTOR, FFC (LIF(NON-ZIF)) 5P
< SWITCH >
S001 1-786-509-11 SWITCH, ROTARY
(DISC TRAY OPEN/CLOSE DETECT)
*************************************************************
POWER KEY BOARD
****************
< DIODE >
D1162 6-502-349-01 LED SLI-343U8RCT32 (\/1 (STANDBY))
D1163 6-502-347-01 LED SLI-343M8CT32 (\/1 (ON))
< TRANSISTOR >
Q1138 8-729-027-50 TRANSISTOR DTC123JKA-T146
Q1139 6-550-262-01 TRANSISTOR RT1P237C-TP-1
< RESISTOR >
R1165 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1167 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1242 1-216-809-11 METAL CHIP 100 5% 1/10W
< SWITCH >
S1162 1-771-410-21 SWITCH, TACTILE (\/1)
*************************************************************
MOTORMAIN DIGITAL MASTER VOL POWER KEY
