Sony HCD-DP700 - Main Board Components (R396-R512); Resistors R396-R512; Variable Resistors; Transformers and Terminals

81
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-DP700
R396 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R397 1-216-820-11 METAL CHIP 820 5% 1/16W
R398 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R400 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R401 1-216-809-11 METAL CHIP 100 5% 1/16W
R402 1-216-809-11 METAL CHIP 100 5% 1/16W
R403 1-216-809-11 METAL CHIP 100 5% 1/16W
R404 1-216-809-11 METAL CHIP 100 5% 1/16W
R405 1-216-809-11 METAL CHIP 100 5% 1/16W
R406 1-216-809-11 METAL CHIP 100 5% 1/16W
R407 1-216-809-11 METAL CHIP 100 5% 1/16W
R409 1-216-833-11 METAL CHIP 10K 5% 1/16W
R411 1-216-851-11 METAL CHIP 330K 5% 1/16W
R413 1-216-864-11 METAL CHIP 0 5% 1/16W
R417 1-216-833-11 METAL CHIP 10K 5% 1/16W
R419 1-216-809-11 METAL CHIP 100 5% 1/16W
R422 1-216-833-11 METAL CHIP 10K 5% 1/16W
R423 1-216-833-11 METAL CHIP 10K 5% 1/16W
R424 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R426 1-216-849-11 METAL CHIP 220K 5% 1/16W
R428 1-216-845-11 METAL CHIP 100K 5% 1/16W
R429 1-216-809-11 METAL CHIP 100 5% 1/16W
R430 1-216-809-11 METAL CHIP 100 5% 1/16W
R432 1-216-809-11 METAL CHIP 100 5% 1/16W
R433 1-216-809-11 METAL CHIP 100 5% 1/16W
R434 1-216-817-11 METAL CHIP 470 5% 1/16W
R435 1-216-817-11 METAL CHIP 470 5% 1/16W
R437 1-216-817-11 METAL CHIP 470 5% 1/16W
R438 1-216-809-11 METAL CHIP 100 5% 1/16W
R439 1-216-809-11 METAL CHIP 100 5% 1/16W
R440 1-216-809-11 METAL CHIP 100 5% 1/16W
R441 1-216-833-11 METAL CHIP 10K 5% 1/16W
R442 1-216-809-11 METAL CHIP 100 5% 1/16W
R443 1-216-809-11 METAL CHIP 100 5% 1/16W
R444 1-216-809-11 METAL CHIP 100 5% 1/16W
R445 1-216-809-11 METAL CHIP 100 5% 1/16W
R446 1-216-809-11 METAL CHIP 100 5% 1/16W
R447 1-216-809-11 METAL CHIP 100 5% 1/16W
R448 1-216-809-11 METAL CHIP 100 5% 1/16W
R449 1-216-809-11 METAL CHIP 100 5% 1/16W
R451 1-216-833-11 METAL CHIP 10K 5% 1/16W
R453 1-216-833-11 METAL CHIP 10K 5% 1/16W
R456 1-216-809-11 METAL CHIP 100 5% 1/16W
R457 1-216-809-11 METAL CHIP 100 5% 1/16W
R468 1-216-833-11 METAL CHIP 10K 5% 1/16W
R469 1-216-833-11 METAL CHIP 10K 5% 1/16W
R470 1-216-809-11 METAL CHIP 100 5% 1/16W
R471 1-216-809-11 METAL CHIP 100 5% 1/16W
R472 1-216-809-11 METAL CHIP 100 5% 1/16W
R473 1-216-809-11 METAL CHIP 100 5% 1/16W
R474 1-216-809-11 METAL CHIP 100 5% 1/16W
R475 1-216-809-11 METAL CHIP 100 5% 1/16W
R476 1-216-809-11 METAL CHIP 100 5% 1/16W
R477 1-216-809-11 METAL CHIP 100 5% 1/16W
R478 1-216-809-11 METAL CHIP 100 5% 1/16W
R479 1-216-809-11 METAL CHIP 100 5% 1/16W
R480 1-216-809-11 METAL CHIP 100 5% 1/16W
R481 1-216-809-11 METAL CHIP 100 5% 1/16W
R482 1-216-809-11 METAL CHIP 100 5% 1/16W
R483 1-216-809-11 METAL CHIP 100 5% 1/16W
R484 1-216-809-11 METAL CHIP 100 5% 1/16W
R486 1-216-809-11 METAL CHIP 100 5% 1/16W
R487 1-216-833-11 METAL CHIP 10K 5% 1/16W
R488 1-216-833-11 METAL CHIP 10K 5% 1/16W
R489 1-216-833-11 METAL CHIP 10K 5% 1/16W
R490 1-216-833-11 METAL CHIP 10K 5% 1/16W
R491 1-216-833-11 METAL CHIP 10K 5% 1/16W
R493 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
(US,CND)
R493 1-216-821-11 METAL CHIP 1K 5% 1/16W
(MX,E51)
R496 1-216-833-11 METAL CHIP 10K 5% 1/16W
R497 1-216-833-11 METAL CHIP 10K 5% 1/16W
R499 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
(US,CND,MX,E51)
R499 1-216-821-11 RES, CHIP 1K 5% 1/16W
(AEP, UK)
R501 1-216-821-11 METAL CHIP 1K 5% 1/16W
R502 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R503 1-216-841-11 METAL CHIP 47K 5% 1/16W
R504 1-216-841-11 METAL CHIP 47K 5% 1/16W
R505 1-216-833-11 METAL CHIP 10K 5% 1/16W
R506 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R507 1-216-845-11 METAL CHIP 100K 5% 1/16W
R508 1-216-837-11 METAL CHIP 22K 5% 1/16W
R509 1-216-821-11 METAL CHIP 1K 5% 1/16W
R510 1-216-841-11 METAL CHIP 47K 5% 1/16W
R511 1-216-833-11 METAL CHIP 10K 5% 1/16W
R512 1-216-821-11 METAL CHIP 1K 5% 1/16W
R514 1-216-821-11 METAL CHIP 1K 5% 1/16W
R546 1-216-833-11 METAL CHIP 10K 5% 1/16W
R547 1-216-833-11 METAL CHIP 10K 5% 1/16W
R548 1-216-833-11 METAL CHIP 10K 5% 1/16W
R551 1-216-809-11 METAL CHIP 100 5% 1/16W
R552 1-216-809-11 METAL CHIP 100 5% 1/16W
R553 1-216-809-11 METAL CHIP 100 5% 1/16W
R961 1-216-837-11 METAL CHIP 22K 5% 1/16W
R962 1-216-837-11 METAL CHIP 22K 5% 1/16W
R963 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
< ENCAPSULATED >
RB41 1-234-575-11 ENCAPSULATED COMPONENT
< VARIABLE RESISTOR >
RV11 1-241-765-11 RES, ADJ, CARBON 22K
RV301 1-241-764-11 RES, ADJ, CARBON 10K (REC LEVEL (L))
RV302 1-241-762-11 RES, ADJ, CARBON 2.2K (PB LEVEL)
RV303 1-241-762-11 RES, ADJ, CARBON 2.2K (PB LEVEL)
RV304 1-241-768-11 RES, ADJ, CARBON 220K (REC LEVEL (L))
RV351 1-241-764-11 RES, ADJ, CARBON 10K (REC LEVEL (R))
RV354 1-241-768-11 RES, ADJ, CARBON 220K (REC LEVEL (R))
< TRANSFORMER >
T11 1-435-792-11 TRANSFORMER, DISCRIMINATOR
T301 1-423-980-11 TRANSFORMER, BIAS OSCILLATION
< TERMINAL >
TM1 1-694-555-22 TERMINAL BOARD (4P) (US,CND,MX,E51)
TM1 1-694-556-22 TERMINAL BOARD (ANT.PAL) (AEP)
MAIN
