Sony HCD-DP700 - General Section; Location of Parts and Controls

4
HCD-DP700
SECTION 1
GENERAL
6
9
q;
qa
qf
qg
qh
qj
qk
ql
wa
1
2
3
45
7
8
qs
qd
w;
wd
ws
wf
wg
wh
wj
ef
eg
ek
wk
wl
e;
ea
es
ed
eh
ej
el
r;
ra
rg
rf
rd
rs
rj
rh
Location of Parts and Controls
1 @/1 (POWER) button
2 DISC 1-3 button
3 DISC SKIP EX-CHANGE button
4 Z OPEN/CLOSE (disc tray) button
5 DISC tray
6 bB (play) button
7 X (pause) button
8 x (stop) button
9 > (go forward) button
q; . (go back) button
qa M/+ (fast forward) button
qs m/– (rewind) button
qd VOLUME control knob
qf IR receptor
qg PHONES jack
qh REC PAUSE/START button
qj CD SYNC HI-DUB button
qk DECK B Z
ql DECK A Z
w; DIGITAL IN (OPTICAL)
wa GAME button
ws DIGITAL button
wd MD (VIDEO) button
wf TAPE A/B button
wg TUNER/BAND button
wh CD button
wj DISPLAY
wk SPECTRUM button (US and AEP model only) or
KARAOKE PON button (except for US, AEP model)
wl CLOCK/TIMER SET button
e; TIMER SELECT button
ea EDIT/DIRECTION/PTY (European model only) button
es DOLBY NR/FM MODE/REPEAT button
ed TUNER/MEMORY/PLAY MODE button
ef MOVIE MODE
eg DIGIPAD
eh ENTER
ej TOOL MODE
ek 2CH/MULTI
el EFFECT
r; GROOVE
ra P FILE
rs GAME MODE
rd DSP EDIT
rf MUSIC MODE
rg MULTI CHANNEL DECORDING indicator
rh MIC jack (except for US, AEP model)
rj MIC LEVEL control knob (except for US, AEP model)
