Sony HCD-DP700 - Panel Board Components (Cont.); Resistors; Switches; Vibrator

84
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-DP700
R1160 1-249-419-11 CARBON 1.5K 5% 1/4W F
R1161 1-249-421-11 CARBON 2.2K 5% 1/4W F
R1162 1-249-422-11 CARBON 2.7K 5% 1/4W F
R1163 1-249-424-11 CARBON 3.9K 5% 1/4W F
R1164 1-249-426-11 CARBON 5.6K 5% 1/4W
R1165 1-249-428-11 CARBON 8.2K 5% 1/4W F
R1166 1-249-431-11 CARBON 15K 5% 1/4W
R1167 1-249-413-11 CARBON 470 5% 1/4W F
R1168 1-249-414-11 CARBON 560 5% 1/4W F
R1169 1-249-416-11 CARBON 820 5% 1/4W F
R1170 1-249-417-11 CARBON 1K 5% 1/4W F
R1171 1-249-418-11 CARBON 1.2K 5% 1/4W F
R1172 1-249-413-11 CARBON 470 5% 1/4W F
R1173 1-249-414-11 CARBON 560 5% 1/4W F
R1174 1-249-419-11 CARBON 1.5K 5% 1/4W F
R1175 1-249-416-11 CARBON 820 5% 1/4W F
R1176 1-249-417-11 CARBON 1K 5% 1/4W F
R1177 1-249-418-11 CARBON 1.2K 5% 1/4W F
R1178 1-249-419-11 CARBON 1.5K 5% 1/4W F
R1179 1-249-421-11 CARBON 2.2K 5% 1/4W F
R1180 1-249-422-11 CARBON 2.7K 5% 1/4W F
R1181 1-249-424-11 CARBON 3.9K 5% 1/4W F
R1182 1-249-426-11 CARBON 5.6K 5% 1/4W
R1185 1-249-401-11 CARBON 47 5% 1/4W F
R1186 1-249-401-11 CARBON 47 5% 1/4W F
R1189 1-249-441-11 CARBON 100K 5% 1/4W
R1190 1-249-441-11 CARBON 100K 5% 1/4W
R1191 1-260-083-11 CARBON 47 5% 1/2W
R1192 1-260-083-11 CARBON 47 5% 1/2W
R1197 1-249-429-11 CARBON 10K 5% 1/4W
R1198 1-249-441-11 CARBON 100K 5% 1/4W
R1199 1-249-406-11 CARBON 120 5% 1/4W F
R1203 1-249-429-11 CARBON 10K 5% 1/4W
(MX,E51)
R1204 1-249-417-11 CARBON 1K 5% 1/4W F
(MX,E51)
R1205 1-249-441-11 CARBON 100K 5% 1/4W
(MX,E51)
R1206 1-249-417-11 CARBON 1K 5% 1/4W F
(MX,E51)
R1207 1-249-433-11 CARBON 22K 5% 1/4W
(MX,E51)
R1208 1-247-807-31 CARBON 100 5% 1/4W
(MX,E51)
R1209 1-249-429-11 CARBON 10K 5% 1/4W
(MX,E51)
R1210 1-247-883-00 CARBON 150K 5% 1/4W
(MX,E51)
R1211 1-247-807-31 CARBON 100 5% 1/4W
(MX,E51)
R1212 1-249-417-11 CARBON 1K 5% 1/4W F
(MX,E51)
R1213 1-249-429-11 CARBON 10K 5% 1/4W
(MX,E51)
R1214 1-249-431-11 CARBON 15K 5% 1/4W
(MX,E51)
R1215 1-249-441-11 CARBON 100K 5% 1/4W
(MX,E51)
R1280 1-249-417-11 CARBON 1K 5% 1/4W F
R1281 1-249-417-11 CARBON 1K 5% 1/4W F
R1282 1-249-417-11 CARBON 1K 5% 1/4W F
R1283 1-249-417-11 CARBON 1K 5% 1/4W F
R1285 1-249-417-11 CARBON 1K 5% 1/4W F
R1286 1-249-417-11 CARBON 1K 5% 1/4W F
R1287 1-249-417-11 CARBON 1K 5% 1/4W F
R1288 1-249-417-11 CARBON 1K 5% 1/4W F
R1289 1-249-417-11 CARBON 1K 5% 1/4W F
R1290 1-249-417-11 CARBON 1K 5% 1/4W F
R1291 1-249-415-11 CARBON 680 5% 1/4W F
R1292 1-249-419-11 CARBON 1.5K 5% 1/4W F
R1293 1-249-419-11 CARBON 1.5K 5% 1/4W F
R1294 1-249-419-11 CARBON 1.5K 5% 1/4W F
R1295 1-249-419-11 CARBON 1.5K 5% 1/4W F
R1296 1-249-419-11 CARBON 1.5K 5% 1/4W F
R1297 1-249-415-11 CARBON 680 5% 1/4W F
< VARIABLE RESISTOR >
RV1201 1-227-309-11 RES, VAR, CARBON 50K (MIC VOLUME)
(MX,E51)
< SWITCH >
S1101 1-418-725-11 ENCODER, ROTARY (12 TYPE)(VOLUME)
S1116 1-762-875-21 SWITCH, KEYBOARD (b B)
S1117 1-762-875-21 SWITCH, KEYBOARD (x)
S1118 1-762-875-21 SWITCH, KEYBOARD (X)
S1119 1-762-875-21 SWITCH, KEYBOARD (>)
S1120 1-762-875-21 SWITCH, KEYBOARD (.)
S1121 1-762-875-21 SWITCH, KEYBOARD (M/+)
S1122 1-762-875-21 SWITCH, KEYBOARD (m/–)
S1123 1-762-875-21 SWITCH, KEYBOARD (GAME)
S1124 1-762-875-21 SWITCH, KEYBOARD (MD (VIDEO))
S1125 1-762-875-21 SWITCH, KEYBOARD (DIGITAL)
S1126 1-762-875-21 SWITCH, KEYBOARD (TAPE A/B)
S1127 1-762-875-21 SWITCH, KEYBOARD (BAND)
S1128 1-762-875-21 SWITCH, KEYBOARD (CD)
S1129 1-762-875-21 SWITCH, KEYBOARD (EDIT)
S1130 1-762-875-21 SWITCH, KEYBOARD (REPEAT)
S1131 1-762-875-21 SWITCH, KEYBOARD (PLAY MODE)
S1132 1-762-875-21 SWITCH, KEYBOARD (TIMER SELECT)
S1133 1-762-875-21 SWITCH, KEYBOARD (CLOCK/TIMER SET)
S1134 1-762-875-21 SWITCH, KEYBOARD (SPECTRUM)
S1135 1-762-875-21 SWITCH, KEYBOARD (DISPLAY)
S1136 1-762-875-21 SWITCH, KEYBOARD (TOOL MODE)
S1137 1-762-875-21 SWITCH, KEYBOARD (ENTER)
S1138 1-762-875-21 SWITCH, KEYBOARD (MOIVE MODE)
S1139 1-762-875-21 SWITCH, KEYBOARD (MUSIC MODE)
S1140 1-762-875-21 SWITCH, KEYBOARD (DSP EDIT)
S1141 1-762-875-21 SWITCH, KEYBOARD (GAME MODE)
S1142 1-762-875-21 SWITCH, KEYBOARD (PFILE)
S1143 1-762-875-21 SWITCH, KEYBOARD (GROOVE)
S1144 1-762-875-21 SWITCH, KEYBOARD (EFFECT)
S1145 1-762-875-21 SWITCH, KEYBOARD (2CH/MULTI)
S1146 1-762-875-21 SWITCH, KEYBOARD (REC PAUSE/START)
S1147 1-762-875-21 SWITCH, KEYBOARD (CD SYNC HI-DUB)
< VIBRATOR >
X1101 1-577-101-11 VIBRATOR, CERAMIC (4MHz)
**************************************************************
PANEL
