Sony HCD-DP700 - Trans Board Components; Resistors; Fuses and Fuse Holders; Transistors

86
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-DP700
R1072 1-249-441-11 CARBON 100K 5% 1/4W
(MX,E51)
**************************************************************
1-680-189-11 TRANS BOARD
*************
< CAPACITOR >
C911 1-128-576-11 ELECT 100uF 20% 63V
C912 1-126-960-11 ELECT 1uF 20% 50V
C913 1-126-968-11 ELECT 100uF 20% 50V
C915 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
* CN913 1-564-518-11 PLUG, CONNECTOR 3P (MX,E51)
* CN914 1-564-525-11 PLUG, CONNECTOR 10P
* CN915 1-564-519-11 PLUG, CONNECTOR 4P
< DIODE >
D911 8-719-024-99 DIODE 11ES2-NTA2B
D912 8-719-983-88 DIODE MTZJ-T-72-33C
D913 8-719-118-56 DIODE RD4.7F-T7B1
< FUSE >
0 F916 1-532-325-00 FUSE, GLASS TUBE (DIA. 5) 6.3A/250V
(E51,MX)
0 F917 1-532-325-00 FUSE, GLASS TUBE (DIA. 5) 6.3A/250V
(E51,MX)
0 F918 1-532-325-00 FUSE, GLASS TUBE (DIA. 5) 6.3A/250V
(E51,MX)
0 F918 1-532-299-00 FUSE, GLASS TUBE (DIA. 5) 5A/250V (AEP)
0 F918 1-576-193-21 FUSE, GLASS TUBE (DIA. 5) 6.3A/125V
(US,CND)
0 F919 1-532-299-00 FUSE, GLASS TUBE (DIA. 5) 5A/250V
(AEP,E51,MX)
0 F919 1-576-193-21 FUSE, GLASS TUBE (DIA. 5) 6.3A/125V
(US,CND)
< FUSE HOLDER >
FH921 1-533-217-41 HOLDER, FUSE (MX,E51)
FH922 1-533-217-41 HOLDER, FUSE (MX,E51)
FH923 1-533-217-41 HOLDER, FUSE (MX,E51)
FH924 1-533-217-41 HOLDER, FUSE (MX,E51)
FH925 1-533-217-41 HOLDER, FUSE
FH926 1-533-217-41 HOLDER, FUSE
FH927 1-533-217-41 HOLDER, FUSE
FH928 1-533-217-41 HOLDER, FUSE
< TRANSISTOR >
Q971 8-729-048-52 TRANSISTOR 2SA1932(TP)
< RESISTOR >
0 R911 1-217-637-00 FUSIBLE 1 5% 1/4W
R913 1-249-429-11 CARBON 10K 5% 1/4W
R914 1-249-429-11 CARBON 10K 5% 1/4W
R915 1-247-807-31 CARBON 100 5% 1/4W
R916 1-247-807-31 CARBON 100 5% 1/4W
R918 1-219-237-91 SOLID 3.3M 20% 1/2W
(US,CND)
R918 1-219-777-91 CARBON 3.3M 10% 1/2W
(US,CND)
**************************************************************
TRANS
MISCELLANEOUS
***************
0 M961 1-763-072-11 FAN. DC
68 1-796-001-11 TOUCH PAD
FL1101 1-518-722-11 INDICATOR TUBE, FLUORESCENT
102 1-773-042-11 WIRE (FLAT TYPE) (17 CORE)
103 1-757-418-11 WIRE (FLAT TYPE) (21 CORE)
104 1-757-420-11 WIRE (FLAT TYPE) (23 CORE)
105 1-757-419-11 WIRE (FLAT TYPE) (21 CORE)
0110 1-777-071-81 CORD, POWER (AEP, E51)
0 110 1-783-531-11 CORD, POWER (CND, US)
0 110 1-791-901-11 CORD, POWER (MX)
111 1-569-008-21 ADAPTOR, CONVERSION(E51)
0 F911 1-532-237-00 FUSE, GLASS TUBE (DIA. 5) 3.15A/250V (E51)
0 F912 1-533-471-11 FUSE, GLASS TUBE (DIA. 5) 4A/250V (E51)
0 F913 1-532-325-00 FUSE, GLASS TUBE (DIA. 5) 6.3A/250V
(E51,MX)
0 F913 1-533-468-11 FUSE, GLASS TUBE (DIA. 5) 2A/250V (AEP)
0 F913 1-576-109-11 FUSE, GLASS TUBE (DIA. 5) 5A/125V (US,CND)
0 F916 1-532-325-00 FUSE, GLASS TUBE (DIA. 5) 6.3A/250V
(E51,MX)
0 F917 1-532-325-00 FUSE, GLASS TUBE (DIA. 5) 6.3A/250V
(E51,MX)
0 F918 1-532-325-00 FUSE, GLASS TUBE (DIA. 5) 6.3A/250V
(E51,MX)
0 F918 1-532-299-00 FUSE, GLASS TUBE (DIA. 5) 5A/250V (AEP)
0 F918 1-576-193-21 FUSE, GLASS TUBE (DIA. 5) 6.3A/125V
(US,CND)
0 F919 1-532-299-00 FUSE, GLASS TUBE (DIA. 5) 5A/250V
(AEP,E51,MX)
0 F919 1-576-193-21 FUSE, GLASS TUBE (DIA. 5) 6.3A/125V
(US,CND)
0 T911 1-435-811-11 TRANSFORMER, POWER (US)
0 T911 1-435-812-11 TRANSFORMER, POWER (CND)
0 T911 1-435-813-11 TRANSFORMER, POWER (AEP)
0 T911 1-435-814-11 TRANSFORMER, POWER (E51, MX)
155 1-454-887-32 SOLENOID, PLUNGER
161 X-3378-241-1 MOTOR ASSY
205 1-454-887-32 SOLENOID, PLUNGER
211 X-3378-241-1 MOTOR ASSY
259 1-791-983-12 WIRE (FLAT TYPE) (8 CORE)
M721 A-4672-826-A MOTOR ASSY
306 1-757-710-11 WIRE (FLAT TYPE) (16 CORE)
0 307 A-4735-188-A BU-30 (60) ASSY
*************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
1-476-447-11 COMMANDER, STANDARD (RM-SR250) (AEP)
1-501-374-11 ANTENNA, LOOP (AEP)
1-501-594-71 ANTENNA (FM) (AEP)
4-210-254-01 CUSHION (FOOT) (AEP)
4-981-643-31 COVER, BATTERY (FOR RM-SR250) (AEP)
4-231-990-41 INSTRUCTION MANUAL (ENGLISH, FRENCH,
SPANISH) (AEP)
4-231-990-51 INSTRUCTION MANUAL (GERMAN, SWEDISH)
(AEP)
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part number
specified.
