76
HCD-DX150/DX170/DX250
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R1168 1-216-817-11 METAL CHIP 470 5% 1/10W
R1502 1-216-864-11 SHORT CHIP 0
R1504 1-216-864-11 SHORT CHIP 0 (DMB10)
R1504 1-400-244-11 BEAD, FERRITE (CHIP) (1608) (DMB11)
R1527 1-216-864-11 SHORT CHIP 0
R1530 1-216-864-11 SHORT CHIP 0
R1531 1-216-864-11 SHORT CHIP 0
R1540 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1542 1-216-864-11 SHORT CHIP 0
R1543 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1544 1-216-864-11 SHORT CHIP 0
R1546 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R1547 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1548 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1549 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1550 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1551 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1553 1-216-864-11 SHORT CHIP 0
R1554 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1557 1-216-809-11 METAL CHIP 100 5% 1/10W
R2504 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R3601 1-216-809-11 METAL CHIP 100 5% 1/10W
R3602 1-216-809-11 METAL CHIP 100 5% 1/10W
R3603 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3605 1-216-864-11 SHORT CHIP 0
R3606 1-216-864-11 SHORT CHIP 0
R3607 1-216-864-11 SHORT CHIP 0
R3609 1-216-864-11 SHORT CHIP 0
R3611 1-216-809-11 METAL CHIP 100 5% 1/10W
R3621 1-216-809-11 METAL CHIP 100 5% 1/10W
R4501 1-216-864-11 SHORT CHIP 0
R4502 1-216-864-11 SHORT CHIP 0
R4510 1-216-805-11 METAL CHIP 47 5% 1/10W
R4511 1-216-809-11 METAL CHIP 100 5% 1/10W
R4512 1-400-244-11 BEAD, FERRITE (CHIP) (1608)
R4513 1-216-864-11 SHORT CHIP 0
R4514 1-216-864-11 SHORT CHIP 0
R4515 1-216-864-11 SHORT CHIP 0
R4516 1-216-864-11 SHORT CHIP 0
R4518 1-216-864-11 SHORT CHIP 0
R4520 1-216-864-11 SHORT CHIP 0
R4701 1-216-864-11 SHORT CHIP 0
R4702 1-216-864-11 SHORT CHIP 0
R4703 1-216-864-11 SHORT CHIP 0
R4704 1-216-864-11 SHORT CHIP 0
R4705 1-216-864-11 SHORT CHIP 0
R4706 1-216-864-11 SHORT CHIP 0
< COMPOSITION CIRCUIT BLOCK >
RB103 1-234-795-21 RES, NETWORK 0X4 (2010)
RB104 1-234-795-21 RES, NETWORK 0X4 (2010)
RB105 1-234-371-21 RES, NETWORK 47 (1005X4)
RB106 1-234-371-21 RES, NETWORK 47 (1005X4)
RB107 1-234-370-21 RES, NETWORK 22 (1005X4)
RB108 1-234-370-21 RES, NETWORK 22 (1005X4)
RB111 1-234-795-21 RES, NETWORK 0X4 (2010)
RB112 1-234-370-21 RES, NETWORK 22 (1005X4)
RB113 1-234-370-21 RES, NETWORK 22 (1005X4)
< VIBRATOR >
X101 1-781-867-21 VIBRATOR, CRYSTAL (27MHz)
************************************************************
ENCODER BOARD
**************
************************************************************
A-1088-090-A FL BOARD, COMPLETE
******************
< CAPACITOR >
C800 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C801 1-163-037-11 CERAMIC CHIP 0.022uF 10% 50V
C802 1-126-967-11 ELECT 47uF 20% 50V
C803 1-124-584-00 ELECT 100uF 20% 10V
C804 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C805 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C806 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C807 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C808 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C809 1-126-795-11 ELECT 10uF 20% 50V
C810 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C811 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C812 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C813 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C814 1-126-795-11 ELECT 10uF 20% 50V
C815 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C816 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C817 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C818 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C819 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C820 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C821 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C822 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C823 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C824 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C825 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C826 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
< CONNECTOR >
CN801 1-779-556-21 CONNECTOR, FFC (LIF (NON-ZIF)) 19P
CN802 1-779-546-11 CONNECTOR, FFC (LIF (NON-ZIF)) 9P
* CN805 1-568-941-11 PIN, CONNECTOR 3P
< DIODE >
D801 8-719-083-02 DIODE KDS160-RTK
D802 8-719-083-02 DIODE KDS160-RTK
D803 8-719-069-56 DIODE UDZSTE-176.2B
D804 8-719-083-02 DIODE KDS160-RTK
D805 8-719-083-02 DIODE KDS160-RTK
< FERRITE BEAD >
FB806 1-414-813-11 FERRITE, EMI (SMD) (2012)
< FLUORESCENT INDICATOR >
FL801 1-519-792-11 INDICATOR TUBE, FLUORESCENT
DMB10 ENCODER FL
Ver. 1.2
