HCD-DX150/DX170/DX250
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< IC >
IC801 6-600-349-21 IC NJL23H400A ( )
IC802 8-759-643-83 IC uPD16315GB-3BS
< COIL >
L801 1-410-671-31 INDUCTOR 47uH
L802 1-410-671-31 INDUCTOR 47uH
L805 1-400-135-11 INDUCTOR 1uH
L806 1-400-135-11 INDUCTOR 1uH
L807 1-400-135-11 INDUCTOR 1uH
< TRANSISTOR >
Q801 6-550-065-01 TRANSISTOR CPH5504-TL-E
Q802 8-729-120-28 TRANSISTOR 2SC1623-L5L6
< RESISTOR >
R800 1-216-821-11 METAL CHIP 1K 5% 1/10W
R801 1-216-839-11 METAL CHIP 33K 5% 1/10W
R802 1-216-809-11 METAL CHIP 100 5% 1/10W
R804 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R805 1-216-295-91 SHORT CHIP 0
R810 1-216-864-11 SHORT CHIP 0
R811 1-216-844-11 METAL CHIP 82K 5% 1/10W
R812 1-216-845-11 METAL CHIP 100K 5% 1/10W
R813 1-216-845-11 METAL CHIP 100K 5% 1/10W
R814 1-216-809-11 METAL CHIP 100 5% 1/10W
R815 1-216-809-11 METAL CHIP 100 5% 1/10W
R816 1-216-809-11 METAL CHIP 100 5% 1/10W
R817 1-216-821-11 METAL CHIP 1K 5% 1/10W
R819 1-216-805-11 METAL CHIP 47 5% 1/10W
R820 1-216-845-11 METAL CHIP 100K 5% 1/10W
R825 1-216-864-11 SHORT CHIP 0
R826 1-216-864-11 SHORT CHIP 0
< SWITCH >
S800 1-418-632-11 ENCODER, ROTARY (VOLUME)
< TRANSFORMER >
T801 1-443-645-11 TRANSFORMER, DC CONVERTER
************************************************************
H/P BOARD
*********
< CAPACITOR >
C881 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C882 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C883 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C884 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C885 1-164-360-11 CERAMIC CHIP 0.1uF 16V
< DIODE >
D821 8-719-083-02 DIODE KDS160-RTK
D822 8-719-083-02 DIODE KDS160-RTK
< TERMINAL BOARD >
EB801 1-537-770-21 TERMINAL BOARD, GROUND
< FERRITE BEAD >
FB811 1-469-144-21 FERRITE, EMI (SMD) (2012)
FB812 1-500-284-21 INDUCTOR, FERRITE BEAD
FB813 1-469-144-21 FERRITE, EMI (SMD) (2012)
FB814 1-216-295-91 SHORT CHIP 0
< JACK >
J801 1-566-891-21 JACK (PHONES)
< COIL >
L811 1-216-864-11 SHORT CHIP 0
L812 1-469-144-21 FERRITE, EMI (SMD) (2012)
L813 1-216-864-11 SHORT CHIP 0
L814 1-469-144-21 FERRITE, EMI (SMD) (2012)
< TRANSISTOR >
Q806 6-550-889-01 TRANSISTOR 2SC5938-T112-1B
Q807 6-550-889-01 TRANSISTOR 2SC5938-T112-1B
Q808 6-550-889-01 TRANSISTOR 2SC5938-T112-1B
Q809 6-550-889-01 TRANSISTOR 2SC5938-T112-1B
< RESISTOR >
R861 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R862 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R863 1-216-801-11 METAL CHIP 22 5% 1/10W
R864 1-216-801-11 METAL CHIP 22 5% 1/10W
R865 1-216-805-11 METAL CHIP 47 5% 1/10W
R866 1-216-805-11 METAL CHIP 47 5% 1/10W
R867 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R868 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R869 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R870 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
************************************************************
A-1088-069-A IO BOARD, COMPLETE
******************
< CAPACITOR >
C102 1-126-933-11 ELECT 100uF 20% 16V
C103 1-104-662-91 ELECT 22uF 20% 25V
C104 1-104-662-91 ELECT 22uF 20% 25V
C200 1-216-864-11 SHORT CHIP 0
C201 1-126-964-11 ELECT 10uF 20% 50V
C202 1-115-156-11 CERAMIC CHIP 1uF 10V
C203 1-115-156-11 CERAMIC CHIP 1uF 10V
C204 1-115-156-11 CERAMIC CHIP 1uF 10V
C205 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C207 1-126-964-11 ELECT 10uF 20% 50V
C208 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C209 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C210 1-126-925-91 ELECT 470uF 20% 10V
C212 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C213 1-126-933-11 ELECT 100uF 20% 16V
C214 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C223 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C224 1-126-916-11 ELECT 1000uF 20% 6.3V
C225 1-126-916-11 ELECT 1000uF 20% 6.3V
C226 1-126-916-11 ELECT 1000uF 20% 6.3V
FL H/P IO
