37
HCD-EP515
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
< ROTARY ENCODER >
RV801 1-418-632-11 ENCODER, ROTARY (12 TYPE) (VOLUME)
< SWITCH >
S801 1-786-050-21 SWITCH, KEY BOARD (X)
S802 1-786-050-21 SWITCH, KEY BOARD (x)
S803 1-786-050-21 SWITCH, KEY BOARD (PRESET-)
S804 1-786-050-21 SWITCH, KEY BOARD (PRESET+)
S805 1-786-050-21 SWITCH, KEY BOARD (TUNING+)
S806 1-786-050-21 SWITCH, KEY BOARD (TUNING-)
S807 1-786-050-21 SWITCH, KEY BOARD (CD SYNC)
S808 1-786-050-21 SWITCH, KEY BOARD (z REC PAUSE/START)
S809 1-786-050-21 SWITCH, KEY BOARD
(PLAY MODE DIRECTION)
S810 1-786-050-21 SWITCH, KEY BOARD (\/1)
S811 1-786-050-21 SWITCH, KEY BOARD (DISPLAY)
S812 1-786-050-21 SWITCH, KEY BOARD (CD N)
S813 1-786-050-21 SWITCH, KEY BOARD (TUNER BAND)
S814 1-786-050-21 SWITCH, KEY BOARD (TAPE bB)
S815 1-786-050-21 SWITCH, KEY BOARD (MD)
S816 1-786-050-21 SWITCH, KEY BOARD (BASS/TREBLE)
S817 1-786-050-21 SWITCH, KEY BOARD (DSG)
< VIBRATOR >
X801 1-567-098-41 VIBRATOR, CRYSTAL (32.768kHz)
X802 1-795-880-11 VIBRATOR, CERAMIC (8.64MHz)
************************************************************
HEADPHONE BOARD
*****************
< CONNECTOR >
CN307 1-564-723-11 PIN, CONNECTOR (SMALL TYPE) 7P
< JACK >
J301 1-816-219-11 JACK, HEADPHONE (PHONES)
************************************************************
A-4732-658-A MAIN BOARD, COMPLETE (AEP, UK)
A-4732-667-A MAIN BOARD, COMPLETE (US, CND, KR)
*********************
1-693-619-11 TUNER (FM/AM) (AEP, UK)
1-693-620-11 TUNER (FM/AM) (US, CND)
7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
< CONNECTOR >
C101 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C102 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C103 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C104 1-104-657-91 ELECT 47uF 20.00% 10V
C106 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C107 1-126-961-11 ELECT 2.2uF 20.00% 50V
C108 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C109 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C110 1-164-218-11 CERAMIC CHIP 180PF 0.25PF 50V
C111 1-164-172-11 CERAMIC CHIP 0.0056uF 10.00% 25V
C112 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C113 1-126-957-11 ELECT 0.22uF 20.00% 50V
C114 1-126-959-11 ELECT 0.47uF 20.00% 50V
C115 1-126-963-11 ELECT 4.7uF 20.00% 50V
C116 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C117 1-164-730-11 CERAMIC CHIP 0.0012uF 10.00% 50V
C118 1-164-677-11 CERAMIC CHIP 0.033uF 10.00% 16V
C119 1-126-963-11 ELECT 4.7uF 20.00% 50V
C120 1-130-495-00 MYLAR 0.1uF 5% 50V
C121 1-130-495-00 MYLAR 0.1uF 5% 50V
C123 1-126-767-11 ELECT 1000uF 20.00% 16V
C126 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C127 1-162-962-91 CERAMIC CHIP 470PF 10% 50V
C128 1-126-965-91 ELECT 22uF 20.00% 50V
C129 1-126-965-91 ELECT 22uF 20.00% 50V
C132 1-126-963-11 ELECT 4.7uF 20.00% 50V
C133 1-130-491-91 FILM 0.047uF 5% 50V
C134 1-162-966-91 CERAMIC CHIP 0.0022uF 10% 50V
C201 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C202 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C203 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C204 1-104-657-91 ELECT 47uF 20.00% 10V
C206 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C207 1-126-961-11 ELECT 2.2uF 20.00% 50V
C208 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C209 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C210 1-164-218-11 CERAMIC CHIP 180PF 0.25PF 50V
C211 1-164-172-11 CERAMIC CHIP 0.0056uF 10.00% 25V
C212 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C213 1-126-957-11 ELECT 0.22uF 20.00% 50V
C214 1-126-959-11 ELECT 0.47uF 20.00% 50V
C215 1-126-963-11 ELECT 4.7uF 20.00% 50V
C216 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C217 1-164-730-11 CERAMIC CHIP 0.0012uF 10.00% 50V
C218 1-164-677-11 CERAMIC CHIP 0.033uF 10.00% 16V
C219 1-126-963-11 ELECT 4.7uF 20.00% 50V
C220 1-130-495-00 MYLAR 0.1uF 5% 50V
C221 1-130-495-00 MYLAR 0.1uF 5% 50V
C223 1-126-767-11 ELECT 1000uF 20.00% 16V
C226 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C227 1-162-962-91 CERAMIC CHIP 470PF 10% 50V
C228 1-126-965-91 ELECT 22uF 20.00% 50V
C229 1-126-965-91 ELECT 22uF 20.00% 50V
C232 1-126-963-11 ELECT 4.7uF 20.00% 50V
C233 1-130-491-91 FILM 0.047uF 5% 50V
C234 1-162-966-91 CERAMIC CHIP 0.0022uF 10% 50V
C301 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C302 1-128-551-11 ELECT 22uF 20.00% 25V
C303 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C304 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C305 1-126-934-11 ELECT 220uF 20.00% 10V
C309 1-126-767-11 ELECT 1000uF 20.00% 16V
C310 1-126-947-11 ELECT 47uF 20.00% 25V
C311 1-126-964-11 ELECT 10uF 20.00% 50V
C312 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C313 1-126-933-11 ELECT 100uF 20.00% 16V
C314 1-136-967-11 MYLAR 0.012uF 5.00% 50V
C315 1-126-947-11 ELECT 47uF 20.00% 25V
C316 1-130-481-00 MYLAR 0.0068uF 5% 50V
C317 1-130-483-00 MYLAR 0.01uF 5% 50V
CONTROL HEADPHONE MAIN
Ver 1.2 2003. 07
