38
HCD-EP515
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
C318 1-130-483-91 FILM 0.01uF 5% 50V
C319 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C320 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C322 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C323 1-128-548-11 ELECT 4700uF 20.00% 25V
C324 1-126-934-11 ELECT 220uF 20.00% 16V
C326 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C327 1-126-947-11 ELECT 47uF 20.00% 25V
C328 1-126-933-11 ELECT 100uF 20.00% 16V
C329 1-126-933-11 ELECT 100uF 20.00% 16V
C330 1-126-934-11 ELECT 220uF 20.00% 10V
C331 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C332 1-126-933-11 ELECT 100uF 20.00% 16V
C333 1-126-935-11 ELECT 470uF 20.00% 16V
C335 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C336 1-126-965-91 ELECT 22uF 20.00% 50V
C343 1-126-947-11 ELECT 47uF 20.00% 25V
C344 1-126-947-11 ELECT 47uF 20.00% 25V
C345 1-126-933-11 ELECT 100uF 20.00% 16V
C346 1-126-935-11 ELECT 470uF 20.00% 16V
C347 1-164-156-91 CERAMIC CHIP 0.1uF 25V
C348 1-164-156-91 CERAMIC CHIP 0.1uF 25V
C349 1-104-662-91 ELECT 47uF 20% 10V
C350 1-127-884-21 CERAMIC 0.047uF 10% 50V
< CONNECTOR >
* CN301 1-564-709-11 PIN, CONNECTOR (SMALL TYPE) 7P
CN302 1-784-776-11 CONNECTOR, FFC 15P
CN303 1-784-781-11 CONNECTOR, FFC 20P
CN304 1-568-830-11 CONNECTOR, FFC 11P (US, CND, KR)
CN304 1-784-776-11 CONNECTOR, FFC 15P (AEP, UK)
CN307 1-564-506-11 PLUG, CONNECTOR 3P
< DIODE >
D301 8-719-991-33 DIODE 1SS133T-77
D302 8-719-991-33 DIODE 1SS133T-77
D303 8-719-109-89 DIODE MTZJ-T-77-5.6B
D304 8-719-109-89 DIODE MTZJ-T-77-5.6B
D305 8-719-109-85 DIODE MTZJ-T-77-5.1B
D306 8-719-109-85 DIODE MTZJ-T-77-5.1B
D310 8-719-109-89 DIODE MTZJ-T-77-5.6B
D311 8-719-109-89 DIODE MTZJ-T-77-5.6B
D312 8-719-063-79 DIODE 1N4002B
D313 8-719-063-79 DIODE 1N4002B
D317 8-719-991-33 DIODE 1SS133T-77
D319 8-719-063-79 DIODE 1N4002B
D320 8-719-063-79 DIODE 1N4002B
D321 8-719-063-79 DIODE 1N4002B
< IC >
IC302 6-702-895-01 IC BD3881FV
IC303 6-702-093-01 IC LA4663N
< JACK >
J302 1-536-708-81 TERMINAL BOARD, PUSH (4P) (SPEAKER)
* J303 1-750-178-31 JACK, PIN 2P (MD)
< COIL >
L101 1-422-009-13 COIL, AIR-CORE
L102 1-422-009-13 COIL, AIR-CORE
L201 1-422-009-13 COIL, AIR-CORE
L202 1-422-009-13 COIL, AIR-CORE
< TRANSISTOR >
Q305 8-729-036-86 TRANSISTOR KTC3203Y-AT
Q306 8-729-037-13 TRANSISTOR KTA1271Y-AT
Q307 8-729-028-54 TRANSISTOR KTC3205-Y-AT
Q308 8-729-037-13 TRANSISTOR KTA1271Y-AT
Q309 8-729-054-16 TRANSISTOR KRC402-RTK
Q310 8-729-028-54 TRANSISTOR KTC3205-Y-AT
Q311 8-729-037-13 TRANSISTOR KTA1271Y-AT
Q312 8-729-036-86 TRANSISTOR KTC3203Y-AT
Q313 8-729-036-86 TRANSISTOR KTC3203Y-AT
Q314 8-729-037-13 TRANSISTOR KTA1271Y-AT
Q315 8-729-054-16 TRANSISTOR KRC402-RTK
Q317 8-729-028-54 TRANSISTOR KTC3205-Y-AT
Q319 8-729-037-13 TRANSISTOR KTA1271Y-AT
Q320 8-729-054-16 TRANSISTOR KRC402-RTK
Q321 8-729-037-13 TRANSISTOR KTA1271Y-AT
Q322 8-729-054-16 TRANSISTOR KRC402-RTK
Q323 8-729-037-13 TRANSISTOR KTA1271Y-AT
Q325 8-729-054-16 TRANSISTOR KRC402-RTK
Q326 8-729-034-50 TRANSISTOR KTA1504
Q327 8-729-034-50 TRANSISTOR KTA1504
Q328 8-729-045-62 TRANSISTOR 2SK2158-T2B
Q329 8-729-045-62 TRANSISTOR 2SK2158-T2B
Q330 8-729-045-62 TRANSISTOR 2SK2158-T2B
Q331 8-729-054-33 TRANSISTOR FDS7764A (US, CND, KR)
Q331 8-729-054-03 TRANSISTOR KRA303-RTK (AEP, UK)
Q332 8-729-054-33 TRANSISTOR FDS7764A (US, CND, KR)
Q332 8-729-054-03 TRANSISTOR KRA303-RTK (AEP, UK)
Q333 8-729-054-16 TRANSISTOR KRC402-RTK
Q338 8-729-054-16 TRANSISTOR KRC402-RTK
Q339 8-729-036-86 TRANSISTOR KTC3203Y-AT
< RESISTOR >
R101 1-216-830-91 METAL CHIP 5.6K 5% 1/10W
R102 1-216-840-11 METAL CHIP 39K 5% 1/10W
R103 1-216-817-11 METAL CHIP 470 5% 1/10W
R104 1-216-808-11 METAL CHIP 82 5% 1/10W
R105 1-216-852-91 METAL CHIP 390K 5% 1/10W
R106 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R107 1-216-847-11 METAL CHIP 150K 5% 1/10W
R108 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R109 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R111 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R112 1-216-893-91 METAL 62 1% 0.6W
(US, CND, KR)
R112 1-216-839-11 METAL CHIP 33K 5% 1/10W
(AEP, UK)
R113 1-216-821-11 METAL CHIP 1K 5% 1/10W
R114 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
R115 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R116 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R117 1-216-821-11 METAL CHIP 1K 5% 1/10W
R118 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R119 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R120 1-216-833-11 METAL CHIP 10K 5% 1/10W
R121 1-216-821-11 METAL CHIP 1K 5% 1/10W
R122 1-216-843-11 METAL CHIP 68K 5% 1/10W
MAIN
