HCD-EP707
( ): AEP, UK models
AM IF ADJUSTMENT
Adjust for a maximum reading on level meter
IFT205 450 kHz
AM FREQUENCY COVERAGE ADJUSTMENT
Adjustment Part Frequency Display Reading on Digital Voltmeter
IFT201
530 kHz
1.3 ± 0.1 V
(531 kHz)
Confirmation
1,710 kHz 7.8 ± 0.5 V
(1,602 kHz) (7.1 ± 0.5 V)
AM TRACKING ADJUSTMENT
Adjust for a maximum reading on level meter
IFT202 603 kHz
VC205 1,404 kHz
FM FREQUENCY COVERAGE CONFIRMATION
Adjustment Part Frequency Display Reading on Digital Voltmeter
L204 87.5 MHz 2.3 to 2.5 V (1.4 to 1.6 V)
Confirmation 108 MHz 6.3 to 7.3 V (7.3 to 8.5 V)
FM TRACKING ADJUSTMENT
Adjust for a maximum reading on level meter
L203 90.1 MHz
VC202 106.1 MHz
TP
(FM ANT)
TP
(GND)
TP
(VT)
– MAIN BOARD (Conductor Side) –
– MAIN BOARD (Component Side) –
IFT205 AM IF Adjustment
L204 FM Frequency Coverage Adjustment
IFT201 AM Frequency Coverage Adjustment
L203
}
FM Tracking Adjustment
VC202
IFT202
}
AM Tracking Adjustment
VC205
Adjustment Location and Connecting Points
