Sony HCD-EP707 - SIDE PANEL DISASSEMBLY; TOP CABINET SECTION DISASSEMBLY

HCD-EP707
7
3-3. TOP CABINET SECTION
Note: Follow the disassembly procedure in the numerical order given.
3-2. SIDE (PANEL)
1 three screws
(KTP3
× 8)
5 three screws
(KTP3
× 8)
2 three screws
(KTP3
× 8)
3 screw
(BVTP3
× 10)
6 three screws
(KTP3
× 8)
4 side (panel) (L)
8 side (panel) (R)
7 screw
(BVTP3
× 10)
2 two claws
3 claw
5 connector
4
1
connector
(CON209)
6 top cabinet section
