Sony HCD-EP707 - 7 Electrical Parts List

38
HCD-EP707
SECTION 7
ELECTRICAL PARTS LIST
DISPLAY
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-4730-425-A DISPLAY BOARD, COMPLETE (US, CND)
A-4730-625-A DISPLAY BOARD, COMPLETE (AEP, UK)
A-4730-716-A DISPLAY BOARD, COMPLETE (AEP)
************************
< CAPACITOR >
C101 1-164-159-21 CERAMIC 0.1uF 50V
C103 1-162-208-31 CERAMIC 24PF 5% 50V
C104 1-128-802-21 CERAMIC 27PF 5% 50V
C105 1-127-880-21 CERAMIC 0.022uF 10% 50V
C106 1-164-159-21 CERAMIC 0.1uF 50V
C107 1-127-880-21 CERAMIC 0.022uF 10% 50V
C108 1-127-880-21 CERAMIC 0.022uF 10% 50V
C109 1-127-880-21 CERAMIC 0.022uF 10% 50V
C110 1-127-880-21 CERAMIC 0.022uF 10% 50V
C111 1-127-876-21 CERAMIC 0.01uF 10% 50V
C113 1-164-159-21 CERAMIC 0.1uF 50V
CE101 1-115-871-11 ELECT 1uF 20% 50V
CE102 1-126-382-11 ELECT 100uF 20% 10V
CE103 1-126-382-11 ELECT 100uF 20% 10V
CE104 1-126-514-11 ELECT 22uF 20% 10V
< DIODE >
D101 8-719-991-33 DIODE 1SS133T-77
D102 8-719-991-33 DIODE 1SS133T-77
D103 8-719-991-33 DIODE 1SS133T-77
D104 8-719-991-33 DIODE 1SS133T-77
D105 8-719-991-33 DIODE 1SS133T-77
D106 8-719-991-33 DIODE 1SS133T-77
D107 8-719-991-33 DIODE 1SS133T-77
D108 8-719-991-33 DIODE 1SS133T-77
D109 8-719-991-33 DIODE 1SS133T-77 (US, CND, AEP, UK)
D110 8-719-991-33 DIODE 1SS133T-77 (US, CND)
D111 8-719-991-33 DIODE 1SS133T-77 (US, CND)
D112 8-719-991-33 DIODE 1SS133T-77
D113 8-719-991-33 DIODE 1SS133T-77 (AEP, UK, AUS)
D114 8-719-991-33 DIODE 1SS133T-77
D120 8-719-991-33 DIODE 1SS133T-77
D121 8-719-991-33 DIODE 1SS133T-77 (US, CND)
D122 8-719-991-33 DIODE 1SS133T-77
D123 8-719-991-33 DIODE 1SS133T-77
D124 8-719-991-33 DIODE 1SS133T-77 (US, CND, AUS)
D125 8-719-991-33 DIODE 1SS133T-77
D126 8-719-991-33 DIODE 1SS133T-77
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
< IC >
IC101 6-802-208-01 IC uPD780206GF-127-3BA
IC102 8-759-251-04 IC ST24C02AB1
< LED >
LED102 8-719-301-42 LED SEL2410E (MD)
LED103 8-719-301-42 LED SEL2410E (CD/DISC SKIP)
LED104 8-719-301-42 LED SEL2410E (TAPE)
LED105 8-719-301-42 LED SEL2410E (TUNER/BAND)
< TRANSISTOR >
Q101 8-729-281-53 TRANSISTOR 2SC536NP-F
Q102 8-729-281-53 TRANSISTOR 2SC536NP-F
Q104 8-729-281-53 TRANSISTOR 2SC536NP-F
Q105 8-729-281-53 TRANSISTOR 2SC536NP-F
Q106 8-729-281-53 TRANSISTOR 2SC536NP-F
< RESISTOR >
R101 1-249-441-11 CARBON 100K 5% 1/4W
R102 1-249-441-11 CARBON 100K 5% 1/4W
R103 1-249-429-11 CARBON 10K 5% 1/4W
R105 1-249-433-11 CARBON 22K 5% 1/4W
R106 1-247-807-31 CARBON 100 5% 1/4W
R107 1-249-441-11 CARBON 100K 5% 1/4W
R108 1-249-437-11 CARBON 47K 5% 1/4W
R109 1-249-437-11 CARBON 47K 5% 1/4W
R113 1-249-417-11 CARBON 1K 5% 1/4W
R114 1-247-903-00 CARBON 1M 5% 1/4W
R115 1-249-429-11 CARBON 10K 5% 1/4W
R116 1-249-429-11 CARBON 10K 5% 1/4W
R118 1-249-429-11 CARBON 10K 5% 1/4W
R119 1-249-429-11 CARBON 10K 5% 1/4W
R126 1-249-437-11 CARBON 47K 5% 1/4W
R127 1-249-437-11 CARBON 47K 5% 1/4W
R128 1-247-887-00 CARBON 220K 5% 1/4W
R129 1-249-441-11 CARBON 100K 5% 1/4W
R130 1-249-437-11 CARBON 47K 5% 1/4W
R131 1-249-437-11 CARBON 47K 5% 1/4W
R132 1-249-437-11 CARBON 47K 5% 1/4W
R133 1-249-437-11 CARBON 47K 5% 1/4W
R134 1-249-437-11 CARBON 47K 5% 1/4W
R135 1-249-437-11 CARBON 47K 5% 1/4W
R136 1-249-437-11 CARBON 47K 5% 1/4W
When indicating parts by reference
number, please include the board.
•Abbreviation
AUS: Australian model
CND : Canadian model
Les composants identifiés par une
marque 0 sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
The components identified by mark
0 or dotted line with mark 0 are
critical for safety.
Replace only with part number
specified.
