Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
42
HCD-EP707
IC210 8-759-576-76 IC TDA2822D013TR
< TRANSFORMER >
IFT201 1-424-935-11 COIL (AM OSC)
IFT202 1-424-936-11 COIL (AM ANT)
IFT205 1-424-876-11 COIL (AM)
< COIL >
L202 1-249-399-11 CARBON 33 5% 1/4W
L203 1-424-880-11 COIL (FM)
L204 1-424-879-11 COIL (FM)
L205 1-410-521-11 INDUCTOR 100uH
L206 1-410-521-11 INDUCTOR 100uH
L207 1-410-093-11 INDUCTOR 39mH
L208 1-410-093-11 INDUCTOR 39mH
L209 1-410-521-11 INDUCTOR 100uH
L210 1-410-517-11 INDUCTOR 47uH
< DIODE/TRANSISTOR >
Q201 8-719-085-35 DIODE SVC348T
Q202 8-729-194-57 TRANSISTOR 2SC945TP-QP
Q204 8-729-194-57 TRANSISTOR 2SC945TP-QP
Q205 8-729-194-57 TRANSISTOR 2SC945TP-QP
Q206 8-729-119-76 TRANSISTOR 2SA733TP-P
Q207 8-729-194-57 TRANSISTOR 2SC945TP-QP
Q208 8-729-823-13 TRANSISTOR 2SC2999D-SPA-AC
(AEP, UK)
Q209 8-729-119-76 TRANSISTOR 2SA733TP-P (AEP, UK)
Q210 8-729-040-88 TRANSISTOR 2SB1240TV2QR
Q211 8-729-194-57 TRANSISTOR 2SC945TP-QP
Q215 8-729-194-57 TRANSISTOR 2SC945TP-QP
Q216 8-729-116-82 TRANSISTOR 2SD1616-L
Q217 8-729-194-57 TRANSISTOR 2SC945TP-QP
Q218 8-729-040-88 TRANSISTOR 2SB1240TV2QR
Q219 8-729-281-53 TRANSISTOR 2SC536NP-F
Q220 8-729-905-50 TRANSISTOR DTC343TS-TP
Q221 8-729-119-76 TRANSISTOR 2SA733TP-P
Q222 8-729-194-57 TRANSISTOR 2SC945TP-QP
Q223 8-729-119-76 TRANSISTOR 2SA733TP-P
Q224 8-729-194-57 TRANSISTOR 2SC945TP-QP
Q225 8-729-194-57 TRANSISTOR 2SC945TP-QP
Q226 8-729-194-57 TRANSISTOR 2SC945TP-QP
Q227 8-729-438-33 TRANSISTOR 2SC1383-R
Q228 8-729-281-53 TRANSISTOR 2SC536NP-F
Q229 8-729-905-50 TRANSISTOR DTC343TS-TP
Q230 8-729-905-50 TRANSISTOR DTC343TS-TP
Q231 8-729-905-50 TRANSISTOR DTC343TS-TP
Q232 8-729-905-50 TRANSISTOR DTC343TS-TP
Q234 8-729-905-50 TRANSISTOR DTC343TS-TP
Q235 8-729-905-50 TRANSISTOR DTC343TS-TP
Q236 8-729-905-50 TRANSISTOR DTC343TS-TP
Q237 8-729-194-57 TRANSISTOR 2SC945TP-QP
Q238 8-729-905-50 TRANSISTOR DTC343TS-TP
Q239 8-729-905-50 TRANSISTOR DTC343TS-TP
Q240 8-729-194-57 TRANSISTOR 2SC945TP-QP
Q241 8-729-905-50 TRANSISTOR DTC343TS-TP
Q242 8-729-905-50 TRANSISTOR DTC343TS-TP
Q243 8-729-905-50 TRANSISTOR DTC343TS-TP
Q245 8-729-905-50 TRANSISTOR DTC343TS-TP
Q246 8-729-905-50 TRANSISTOR DTC343TS-TP
Q247 8-729-905-50 TRANSISTOR DTC343TS-TP
Q248 8-729-194-57 TRANSISTOR 2SC945TP-QP
Q249 8-729-194-57 TRANSISTOR 2SC945TP-QP
Q250 8-729-194-57 TRANSISTOR 2SC945TP-QP
Q251 8-729-194-57 TRANSISTOR 2SC945TP-QP
Q252 8-729-823-13 TRANSISTOR 2SC2999D-SPA-AC
Q253 8-729-905-50 TRANSISTOR DTC343TS-TP
Q254 8-729-905-50 TRANSISTOR DTC343TS-TP
Q255 8-729-905-50 TRANSISTOR DTC343TS-TP
Q256 8-729-905-50 TRANSISTOR DTC343TS-TP
< RESISTOR >
R7 1-249-441-11 CARBON 100K 5% 1/4W
R200 1-249-426-11 CARBON 5.6K 5% 1/4W
R201 1-249-441-11 CARBON 100K 5% 1/4W
R202 1-249-393-11 CARBON 10 5% 1/4W
R203 1-249-441-11 CARBON 100K 5% 1/4W
R211 1-249-429-11 CARBON 10K 5% 1/4W
R214 1-249-429-11 CARBON 10K 5% 1/4W
R215 1-249-429-11 CARBON 10K 5% 1/4W
R217 1-249-441-11 CARBON 100K 5% 1/4W
R218 1-249-435-11 CARBON 33K 5% 1/4W
R219 1-249-429-11 CARBON 10K 5% 1/4W
R220 1-249-425-11 CARBON 4.7K 5% 1/4W
R221 1-249-393-11 CARBON 10 5% 1/4W
R222 1-247-791-11 CARBON 22 5% 1/4W
R223 1-249-431-11 CARBON 15K 5% 1/4W
R226 1-249-418-11 CARBON 1.2K 5% 1/4W
R227 1-249-437-11 CARBON 47K 5% 1/4W
R228 1-249-437-11 CARBON 47K 5% 1/4W
R229 1-247-883-00 CARBON 150K 5% 1/4W
R230 1-249-418-11 CARBON 1.2K 5% 1/4W
R231 1-249-425-11 CARBON 4.7K 5% 1/4W
R232 1-247-843-11 CARBON 3.3K 5% 1/4W
R233 1-249-426-11 CARBON 5.6K 5% 1/4W
R234 1-249-421-11 CARBON 2.2K 5% 1/4W
R235 1-247-899-11 CARBON 680K 5% 1/4W
(AEP, UK)
R236 1-247-807-31 CARBON 100 5% 1/4W
R237 1-249-429-11 CARBON 10K 5% 1/4W
R238 1-249-437-11 CARBON 47K 5% 1/4W
R239 1-249-417-11 CARBON 1K 5% 1/4W
R240 1-249-417-11 CARBON 1K 5% 1/4W
R241 1-247-862-11 CARBON 20K 5% 1/4W
R242 1-247-862-11 CARBON 20K 5% 1/4W
R243 1-249-437-11 CARBON 47K 5% 1/4W
R245 1-249-437-11 CARBON 47K 5% 1/4W
R247 1-247-843-11 CARBON 3.3K 5% 1/4W
R248 1-249-429-11 CARBON 10K 5% 1/4W
R249 1-249-429-11 CARBON 10K 5% 1/4W
R250 1-249-417-11 CARBON 1K 5% 1/4W
R251 1-249-429-11 CARBON 10K 5% 1/4W
R252 1-249-410-11 CARBON 270 5% 1/4W
R253 1-249-417-11 CARBON 1K 5% 1/4W
R254 1-249-429-11 CARBON 10K 5% 1/4W
R255 1-249-421-11 CARBON 2.2K 5% 1/4W
MAIN
