Sony HCD-EP707 - CD MECHANISM CARRIAGE ASSEMBLY

HCD-EP707
4
Note: Follow the assembly procedure in the numerical order given.
2. CARRIAGE
3. ASSEMBLY
• This set can be assembled in the order shown below.
1. ASSEMBLY FLOW
CARRIAGE
(Page 4)
DRAWER
(Page 8)
bevel gear
upper pinion
carriage
