103
HCD-FX900W
SECTION 9
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS
uF: µF
• COILS
uH: µH
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. ., uPA. . : µPA. .,
uPB. . : µPB. ., uPC. . : µPC. .,
uPD. . : µPD. .
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque 0
sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant le
numéro spécifié.
When indicating parts by reference number,
please include the board name.
A-1152-010-A DIAT TX XM BOARD, COMPLETE
**************************
< CAPACITOR >
C101 1-104-658-91 ELECT 100uF 20% 10V
C103 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C104 1-126-964-11 ELECT 10uF 20% 50V
C105 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C108 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C110 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C112 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C114 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C116 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C121 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C123 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C124 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C126 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C127 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C131 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C132 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C133 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C134 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C136 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C138 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C140 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C141 1-162-910-11 CERAMIC CHIP 5PF 0.25PF 50V
C142 1-162-910-11 CERAMIC CHIP 5PF 0.25PF 50V
C153 1-126-964-11 ELECT 10uF 20% 50V
C154 1-104-658-91 ELECT 100uF 20% 10V
C156 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C157 1-126-923-91 ELECT 220uF 20% 10V
C1800 1-126-933-11 ELECT 100uF 20% 16V
C1801 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1805 1-126-933-11 ELECT 100uF 20% 16V
C1806 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1807 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1808 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1809 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1810 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1811 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1812 1-104-658-91 ELECT 100uF 20% 10V
C1813 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1814 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1815 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1816 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1817 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1818 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1819 1-162-916-11 CERAMIC CHIP 12PF 5% 50V
C1820 1-162-916-11 CERAMIC CHIP 12PF 5% 50V
C1821 1-104-658-91 ELECT 100uF 20% 10V
C1822 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1823 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C1824 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1825 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C1826 1-104-658-91 ELECT 100uF 20% 10V
C1827 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1828 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1829 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C1830 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1831 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1832 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C1833 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1834 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1835 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C1836 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1837 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1838 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1839 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1840 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1841 1-126-961-11 ELECT 2.2uF 20% 50V
C1842 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C1844 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1845 1-104-658-91 ELECT 100uF 20% 10V
C1846 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C1847 1-126-933-11 ELECT 100uF 20% 16V
C1848 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C1849 1-126-933-11 ELECT 100uF 20% 16V
C1850 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1851 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1860 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1861 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1863 1-126-933-11 ELECT 100uF 20% 16V
C1864 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C1865 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C1866 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN102 1-779-281-11 CONNECTOR, FFC (LIF (NON-ZIF)) 13P
CN1801 1-784-370-21 CONNECTOR, FFC/FPC 11P
DIAT TX XM
To Next Page
