Sony HCD-FX900W - 8-2. FRONT PANEL ASSY; Refer to “Precaution when replacing the BUTTON” when replacing the BUTTON (PLAY) or BUTTON (DISC) or BUTTON (POWER) or BUTTON (STOP). (See page 7)

93
HCD-FX900W
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
51 2-660-943-01 PANEL, FRONT
52 2-660-952-21 WINDOW
53 2-660-959-01 PROTECTOR, DUST
54 2-660-950-01 BUTTON (DISC)
55 2-660-951-01 BUTTON (PLAY)
56 2-660-949-01 BUTTON (POWER)
57 2-660-947-01 BASE, BUTTON (POWER)
58 2-660-948-01 BASE, BUTTON (PLAY)
59 A-1154-516-A FL BOARD, COMPLETE
60 A-1154-518-A KEY BOARD, COMPLETE
61 2-660-946-11 PANEL, BUTTON
62 2-660-958-01 FILTER, COLOR
63 3-077-331-21 +BV3 (3-CR)
64 2-660-960-02 BUTTON (STOP)
#6 7-685-504-19 SCREW +BTP 2X6 TYPE2 N-S
8-2. FRONT PANEL ASSY
not
supplied
not
supplied
#6
53
54
56
57
64
58
59
60
63
55
52
61
51
62
Refer to “Precaution when replacing the BUTTON” when
replacing the BUTTON (PLAY) or BUTTON (DISC) or
BUTTON (POWER) or BUTTON (STOP). (See page 7)
