•Waveforms
– DMB12 Board –
1 IC101 6 (DVDRFIP)
800 mVp-p
200 mV/DIV, 100 ns/DIV
2 IC101 <xx. (XTALI)
37 ns
4.2 Vp-p
1 V/DIV, 10 ns/DIV
3 IC708 qg (X1)
100 ns
3.8 Vp-p
1 V/DIV, 40 ns/DIV
7 IC101 <x// (YUV4)
1 V/DIV, 20 µ s/DIV
8 IC101 <x/x (YUV5)
H
0.7 Vp-p
500 mV/DIV, 20
µ s/DIV
9 IC101 <x/c (YUV6)
H
0.6 Vp-p
500 mV/DIV, 20 µ s/DIV
4 IC101 <z., (YUV3)
H
1.1 Vp-p
500 mV/DIV, 20
µ s/DIV
5 IC101 <z.n (YUV2)
H
0.7 Vp-p
1 V/DIV, 20
µ s/DIV
6 IC101 <z.v (YUV1)
H
1.1 Vp-p
1 V/DIV, 20
µ s/DIV
H
1.1 Vp-p
– MAIN Board –
0 IC702 ws (XIN(I))
81.3 ns
3.6 Vp-p
1 V/DIV, 40 ns/DIV
qa IC2 <zvx (CLKIN)
40 ns
2.5 Vp-p
1 V/DIV, 20 ns/DIV
qs IC501 qg (Xin)
200 ns
2.7 Vp-p
1 V/DIV, 100 ns/DIV
qd IC3010 rk (XFSOIN)
20.3 ns
5.5 Vp-p
1 V/DIV, 10 ns/DIV
