90
HCD-FX900W
Pin No. Pin Name I/O Description
183 MUTE O MUTE signal output to Motor Driver (IC201)
184 MUTE123 O MUTE123 signal output to Motor Driver (IC201)
185 REW O REW signal output to Motor Driver (IC201)
186 FWD O FWD signal output to Motor Driver (IC201)
187 ADSD0 O Not used
188 XDACS O Not used
189 DAVCC — Power supply (+3.3V from IC105)
190 DACVDDC I Bandgap reference voltage (not used)
191 FS O Full scale adjustment (pull down)
192 CIN — Not used
193 DAVSS — Ground terminal
194 YUV1 O Y signal output to VIDEO AMP (IC201)
195 DAVDD — Power supply (+3.3V from IC105)
196 YUV2 O CHROMA signal output to VIDEO AMP (IC201)
197 DAVSS — Ground terminal
198 YUV3 O VIDEO signal output to VIDEO AMP (IC201)
199 DAVDD — Power supply (+3.3V from IC105)
200 YUV4 O Y signal output to VIDEO AMP (IC201)
201 DAVSS — Ground terminal
202 YUV5 O Cb signal output to VIDEO AMP (IC201)
203 YUV6 O Cr signal output to VIDEO AMP (IC201)
204 DVDD3 — Power supply (SW+3.3V)
205 VSYN O Active low vertical sync output to HDMI Driver (IC701)
206 YUV7 O Main audio mute signal
207 SMBSY O Active low horizontal sync output to HDMI Driver (IC701)
208 SMSCK O SMS clock output
209 SMSDI I Audio data of SPDIF input
210 SMSDO O SMS data output
211 XSMCS O SMS CS output
212 DVDD3 — Power supply (SW+3.3V)
213 ALRCK O Audio left/right channel clock
214 ABCK O Audio bit clock
215 ACLK O Audio DAC master clock
216 DVSS — Ground terminal
217 ASDATA0 O Audio serial data 0
218 ASDATA1 O Audio serial data 1
219 ASDATA2 O Audio serial data 2
220 SPDATA I Ex. analog audio data input
221 DVDD18 — Power supply (+1.8V)
222 ASDATA4 O Audio serial data 4
223 DVSS — Ground terminal
224 OPIO — Not used
225 SDPIF O SPDIF output (not used)
226 RFGND18 — Ground terminal
227 RFVDD18 — Power supply (RF+1.8V)
228 XTALO O Oscillator output signal (27MHz)(not used)
229 XTALI I Oscillator input signal (27MHz)
230 JITFO O RF jitter meter output (not used)
231 JITFN I Negative input of operation amplifier for RF jitter meter (not used)
