Sony HCD-GRX50 - Electrical Parts List - Multiple Boards; MAIN, Motor, Panel Board Components

– 91 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
RV351 1-238-600-11 RES, ADJ, CARBON 10K
< RELAY >
RY401 1-755-168-11 RELAY
< THERMISTOR >
TH831 1-807-796-11 THERMISTOR (EXCEPT RXD7: CND)
< TERMINAL >
TM401 1-694-302-11 TERMINAL BOARD (CHECKER PIN) (SPEAKER)
(R770/RXD7: AEP)
TM401 1-537-240-31 TERMINAL BOARD (CHECKER PIN) (SPEAKER)
(GRX50/RXD7: CND)
< VIBRATOR >
X601 1-567-098-41 VIBRATOR, CRYSTAL (32.768KHz)
X613 1-781-107-21 VIBRATOR, CERAMIC (16MHz)
************************************************************
* 1-658-578-11 MOTOR (SLIDE) BOARD
********************
< CAPACITOR >
C801 1-162-306-11 CERAMIC 0.01uF 20% 16V
C804 1-162-306-11 CERAMIC 0.01uF 20% 16V
C805 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
* CN801 1-568-947-11 PIN, CONNECTOR 9P
< DIODE >
D801 8-719-921-48 DIODE MTZJ-T-72-5.6C
D804 8-719-911-19 DIODE 1SS119
D805 8-719-911-19 DIODE 1SS119
< IC >
IC801 8-759-274-09 IC BA6286N
< RESISTOR >
R801 1-249-401-11 CARBON 47 5% 1/4W
< SWITCH >
S801 1-762-527-11 SWITCH, ROTARY (OPEN/CLOSE DET)
************************************************************
* 1-658-577-11 MOTOR (TURN) BOARD
*******************
< CAPACITOR >
C701 1-162-306-11 CERAMIC 0.01uF 20% 16V
C702 1-126-964-11 ELECT 10uF 20% 50V
C705 1-162-306-11 CERAMIC 0.01uF 20% 16V
< CONNECTOR >
CN703 1-750-413-11 CONNECTOR, FFC/FPC 8P
CN704 1-506-469-11 PIN, CONNECTOR 4P
< DIODE >
D701 8-719-983-66 DIODE MTZJ-T-72-3.6B
< IC >
IC701 8-759-633-65 IC M54641L
< RESISTOR >
R706 1-249-411-11 CARBON 330 5% 1/4W
R707 1-249-401-11 CARBON 47 5% 1/4W
************************************************************
* A-4417-722-A PANEL BOARD, COMPLETE
(EXCEPT GRX50: EA3)
* A-4419-727-A PANEL BOARD, COMPLETE (GRX50: EA3)
**********************
* 4-214-439-11 HOLDER, FL TUBE
< CAPACITOR >
C601 1-124-589-11 ELECT 47uF 20% 16V
C602 1-126-163-11 ELECT 4.7uF 20% 50V
C603 1-162-306-11 CERAMIC 0.01uF 20% 16V
C604 1-162-294-31 CERAMIC 0.001uF 10% 50V
C606 1-126-160-11 ELECT 1uF 20% 50V
C607 1-126-160-11 ELECT 1uF 20% 50V
C610 1-124-589-11 ELECT 47uF 20% 16V
C611 1-162-306-11 CERAMIC 0.01uF 20% 16V
C612 1-162-306-11 CERAMIC 0.01uF 20% 16V
C614 1-162-306-11 CERAMIC 0.01uF 20% 16V
C615 1-162-306-11 CERAMIC 0.01uF 20% 16V
C616 1-126-157-11 ELECT 10uF 20% 16V
C617 1-162-303-11 CERAMIC 0.0033uF 30% 16V
C618 1-126-157-11 ELECT 10uF 20% 16V
C619 1-126-157-11 ELECT 10uF 20% 16V
C620 1-126-163-11 ELECT 4.7uF 20% 50V
C625 1-126-157-11 ELECT 10uF 20% 16V
C627 1-162-306-11 CERAMIC 0.01uF 20% 16V
C628 1-126-157-11 ELECT 10uF 20% 16V
C630 1-162-306-11 CERAMIC 0.01uF 20% 16V
C651 1-162-282-31 CERAMIC 100PF 10% 50V
C652 1-162-282-31 CERAMIC 100PF 10% 50V
C653 1-162-282-31 CERAMIC 100PF 10% 50V
C654 1-162-282-31 CERAMIC 100PF 10% 50V
C655 1-162-282-31 CERAMIC 100PF 10% 50V
C656 1-162-282-31 CERAMIC 100PF 10% 50V
C657 1-162-282-31 CERAMIC 100PF 10% 50V
C658 1-162-282-31 CERAMIC 100PF 10% 50V
C659 1-162-282-31 CERAMIC 100PF 10% 50V
C660 1-162-282-31 CERAMIC 100PF 10% 50V
C661 1-162-282-31 CERAMIC 100PF 10% 50V
C662 1-162-282-31 CERAMIC 100PF 10% 50V
C663 1-162-282-31 CERAMIC 100PF 10% 50V
C664 1-162-282-31 CERAMIC 100PF 10% 50V
C665 1-162-282-31 CERAMIC 100PF 10% 50V
C666 1-162-282-31 CERAMIC 100PF 10% 50V
C667 1-162-282-31 CERAMIC 100PF 10% 50V
C668 1-162-282-31 CERAMIC 100PF 10% 50V
C701 1-162-294-31 CERAMIC 0.001uF 10% 50V
MAIN MOTOR (SLIDE) MOTOR (TURN) PANEL
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
