Sony HCD-GRX50 - Page 67

– 92 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
C702 1-162-294-31 CERAMIC 0.001uF 10% 50V
C703 1-164-159-11 CERAMIC 0.1uF 50V
C711 1-162-294-31 CERAMIC 0.001uF 10% 50V
(GRX50: EA3)
C712 1-162-305-11 CERAMIC 0.0068uF 30% 16V
(GRX50: EA3)
C713 1-126-160-11 ELECT 1uF 20% 50V
(GRX50: EA3)
C714 1-136-495-11 FILM 0.068uF 5% 50V
(GRX50: EA3)
C715 1-124-465-00 ELECT 0.47uF 20% 50V
(GRX50: EA3)
C716 1-124-465-00 ELECT 0.47uF 20% 50V
(GRX50: EA3)
C717 1-136-167-00 FILM 0.15uF 5% 50V
(GRX50: EA3)
C718 1-162-294-31 CERAMIC 0.001uF 10% 50V
(GRX50: EA3)
C719 1-126-160-11 ELECT 1uF 20% 50V
(GRX50: EA3)
C720 1-161-494-00 CERAMIC 0.022uF 25V
(GRX50: EA3)
C721 1-162-305-11 CERAMIC 0.0068uF 30% 16V
(GRX50: EA3)
C722 1-136-495-11 FILM 0.068uF 5% 50V
(GRX50: EA3)
C723 1-124-589-11 ELECT 47uF 20% 16V
(GRX50: EA3)
C724 1-136-165-00 FILM 0.1uF 5% 50V
(GRX50: EA3)
C725 1-124-589-11 ELECT 47uF 20% 16V
(GRX50: EA3)
C731 1-162-306-11 CERAMIC 0.01uF 20% 16V
C732 1-124-257-00 ELECT 2.2uF 20% 50V
C733 1-162-294-31 CERAMIC 0.001uF 10% 50V
C734 1-162-215-31 CERAMIC 47PF 5% 50V
C735 1-124-261-00 ELECT 10uF 20% 50V
C736 1-162-290-31 CERAMIC 470PF 10% 50V
C737 1-124-463-00 ELECT 0.1uF 20% 50V
C738 1-124-257-00 ELECT 2.2uF 20% 50V
(GRX50: EA3)
C739 1-162-215-31 CERAMIC 47PF 5% 50V
C741 1-124-261-00 ELECT 10uF 20% 50V
C742 1-162-282-31 CERAMIC 100PF 10% 50V
C743 1-124-257-00 ELECT 2.2uF 20% 50V
C747 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN601 1-784-745-11 CONNECTOR, FFC 23P
< DIODE >
D610 8-719-050-84 DIODE RB441Q-40T-72
D611 8-719-073-47 LED SML72923C-TP15 (REC PAUSE/START)
D612 8-719-056-13 LED SML79423C-TP15 (^ CD)
D613 8-719-058-03 LED SEL5423E-TP15 (( TAPE B)
D614 8-719-058-03 LED SEL5423E-TP15 (9 TAPE B)
D615 8-719-058-03 LED SEL5423E-TP15 (( TAPE A)
D616 8-719-058-03 LED SEL5423E-TP15 (9 TAPE A)
D619 8-719-057-97 LED SEL5923A-TP15 (SYNC BASS)
D620 8-719-057-97 LED SEL5923A-TP15 (SYNC BASS H)
D621 8-719-057-97 LED SEL5923A-TP15 (SYNC EQ)
D622 8-719-063-93 LED SLR325VC-N-T32 (EFFECT)
D624 8-719-063-93 LED SLR325VC-N-T32 (NON-STOP)
D627 8-719-057-97 LED SEL5923A-TP15 (GROOVE)
D628 8-719-063-93 LED SLR325VC-N-T32 (ENTER/NEXT)
D629 8-719-063-93 LED SLR325VC-N-T32 (JOG DIAL)
D630 8-719-057-97 LED SEL5923A-TP15 (- ))
D631 8-719-057-97 LED SEL5923A-TP15 (+ 0)
D632 8-719-063-93 LED SLR325VC-N-T32 (TIMER SELECT)
D701 8-719-109-85 DIODE RD5.1ES-B2 (GRX50: EA3)
< EARTH TERMINAL >
* EP601 1-537-738-21 TERMINAL, EARTH
< FERRITE BEAD >
FB601 1-412-473-21 INDUCTOR 0uH
FB602 1-412-473-21 INDUCTOR 0uH
< FLUORESCENT INDICATOR TUBE >
FL601 1-517-831-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC601 8-759-589-13 IC TMP88CS76F-6004
IC602 8-749-011-05 IC GP1U28X
IC603 8-759-083-77 IC BA3830F
IC604 8-759-342-19 IC NJU3716M-T2
IC711 8-759-496-40 IC M65850FP (GRX50: EA3)
IC712 8-759-636-55 IC M5218AFP
< JACK >
J701 1-785-569-11 JACK (SMALL TYPE) (PHONES)
J711 1-785-569-11 JACK (SMALL TYPE) (MIX MIC)
< COIL >
L601 1-410-509-11 INDUCTOR 10uH
L602 1-410-517-11 INDUCTOR 47uH
< TRANSISTOR >
Q601 8-729-118-00 TRANSISTOR 2SB1116-L
Q602 8-729-118-00 TRANSISTOR 2SB1116-L
Q603 8-729-119-78 TRANSISTOR 2SC403SP-51
Q604 8-729-422-57 TRANSISTOR UN4111
Q605 8-729-422-57 TRANSISTOR UN4111
Q606 8-729-900-80 TRANSISTOR DTC114ES
Q607 8-729-900-74 TRANSISTOR DTC143TS
Q608 8-729-900-74 TRANSISTOR DTC143TS
Q609 8-729-900-74 TRANSISTOR DTC143TS
Q610 8-729-900-74 TRANSISTOR DTC143TS
Q611 8-729-900-74 TRANSISTOR DTC143TS
Q612 8-729-900-74 TRANSISTOR DTC143TS
Q613 8-729-900-74 TRANSISTOR DTC143TS
< RESISTOR >
R600 1-247-903-00 CARBON 1M 5% 1/4W
R601 1-247-807-31 CARBON 100 5% 1/4W
R602 1-249-429-11 CARBON 10K 5% 1/4W
PANEL
