Sony HCD-GRX50 - Electrical Parts List - SUB TRANS & TRANS Boards; SUB TRANS & TRANS Board Components

– 95 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< TRANSISTOR >
Q11 8-729-119-78 TRANSISTOR 2SC403SP-51 (R770/RXD7)
Q12 8-729-040-19 TRANSISTOR RT1N137L-TP (R770/RXD7)
Q13 8-729-118-01 TRANSISTOR 2SB1116 (R770/RXD7)
Q14 8-729-048-13 TRANSISTOR 2SC3616-KLM-T1
(R770/RXD7)
Q15 8-729-048-13 TRANSISTOR 2SC3616-KLM-T1
(R770/RXD7)
Q16 8-729-900-63 TRANSISTOR DTA124ES (R770/RXD7)
Q17 8-729-900-63 TRANSISTOR DTA124ES (R770/RXD7)
< RESISTOR >
R11 1-249-429-11 CARBON 10K 5% 1/4W
(R770/RXD7)
R12 1-249-441-11 CARBON 100K 5% 1/4W
(R770/RXD7)
R13 1-249-417-11 CARBON 1K 5% 1/4W
(R770/RXD7)
R15 1-249-429-11 CARBON 10K 5% 1/4W
(R770/RXD7)
R16 1-247-807-31 CARBON 100 5% 1/4W
(R770/RXD7)
R17 1-247-807-31 CARBON 100 5% 1/4W
(R770/RXD7)
R18 1-247-807-31 CARBON 100 5% 1/4W
(R770/RXD7)
R19 1-249-427-11 CARBON 6.8K 5% 1/4W
(R770/RXD7)
R20 1-249-429-11 CARBON 10K 5% 1/4W
(R770/RXD7)
R23 1-249-427-11 CARBON 6.8K 5% 1/4W
(R770/RXD7)
< RELAY >
! RY11 1-755-276-11 RELAY, POWER (R770/RXD7)
< TRANSFORMER >
! T11 1-433-587-11 TRANSFORMER, POWER (RXD7: CND)
! T11 1-433-588-11 TRANSFORMER, POWER (R770/RXD7: AEP)
************************************************************
* 1-672-369-11 TRANS BOARD
************
1-533-217-31 HOLDER, FUSE
< CAPACITOR >
C971 1-128-563-11 ELECT 100uF 20% 100V
(GRX50)
C972 1-126-960-11 ELECT 1uF 20% 50V
(GRX50)
C973 1-126-948-11 ELECT 100uF 20% 35V
(GRX50)
< CONNECTOR >
CN951 1-564-321-00 PIN, CONNECTOR 2P (GRX50)
CN952 1-564-524-11 PLUG, CONNECTOR 9P (R770/RXD7)
* CN952 1-564-527-11 PLUG, CONNECTOR 12P (GRX50)
CN953 1-785-329-11 PIN, CONNECTOR (LIGHT ANGLE) 3P (GRX50)
< DIODE >
D971 8-719-024-99 DIODE 11ES2-NTA2B (GRX50)
D972 8-719-986-60 DIODE HZS27-3LTA (GRX50)
D973 8-719-109-63 DIODE RD3.0ESB2 (GRX50)
< FUSE >
! F951 1-532-420-11 FUSE GLASS TUBE 5A/125V (RXD7: CND)
! F951 1-532-506-31 FUSE T6.3AL/250V
(GRX50: E2, E3, EA3, SP, TW, AR)
! F961 1-532-505-31 FUSE T5AL/250V (GRX50)
! F962 1-532-505-31 FUSE T5AL/250V (GRX50)
! F963 1-532-506-31 FUSE T6.3AL/250V (EXCEPT RXD7: CND)
! F964 1-532-506-31 FUSE T6.3AL/250V (EXCEPT RXD7: CND)
< TRANSISTOR >
Q971 8-729-048-52 TRANSISTOR 2SA1932 (TP) (GRX50)
< RESISTOR >
! R951 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
(RXD7: CND)
! R951 1-219-122-91 FUSIBLE 0.33 5% 1/4W F
(EXCEPT RXD7: CND)
! R952 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
(RXD7: CND)
! R952 1-219-122-91 FUSIBLE 0.33 5% 1/4W F
(EXCEPT RXD7: CND)
! R953 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
(R770/RXD7)
! R953 1-219-119-81 FUSIBLE 0.1 5% 1/4W F
(GRX50)
! R961 1-202-725-00 SOLID 3.3M 10% 1/2W
(RXD7: CND)
! R971 1-216-456-00 METAL OXIDE 820 5% 2W F
(GRX50)
R972 1-249-429-11 CARBON 10K 5% 1/4W
(GRX50)
R973 1-249-429-11 CARBON 10K 5% 1/4W
(GRX50)
R974 1-247-807-31 CARBON 100 5% 1/4W
(GRX50)
R975 1-247-807-31 CARBON 100 5% 1/4W
(GRX50)
< SWITCH >
! S951 1-771-291-11 SWITCH, POWER (VOLTAGE SELECTOR)
(GRX50: E2, E3, EA3, SP, TW, AR)
< TRANSFORMER >
! T951 1-433-563-11 TRANSFORMER,POWER (RXD7:CND)
! T951 1-433-564-11 TRANSFORMER,POWER (R770/RXD7: AEP)
! T951 1-433-565-11 TRANSFORMER,POWER (GRX50)
************************************************************
SUB TRANS TRANS
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
